Frigidaire FMV156E Parts Catalog

Over-range microwave
Hide thumbs

Advertisement

Quick Links

FMV156D.tif FMV156EMA Cabinet.eps FMV156D Controls.eps
wiring schematic.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FMV156EMA
Market
North America
Color
silver
Volts
120
Watts
950
Wiring Diagram
5995457826
Owner's Guide
TINSEB445MRR0
Installation Instructions 316137333
FMV156EMA
Publication No.
5995457826
06/01/10
(EN/SERVICE/KC)
099
OVER-RANGE
MICROWAVE
Model No.
FMV156E
©
Copyright
2006 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

  Related Manuals for Frigidaire FMV156E

  Summary of Contents for Frigidaire FMV156E

  • Page 1 Product No. FMV156EMA Market North America Color silver Volts Watts Wiring Diagram 5995457826 Owner's Guide TINSEB445MRR0 Installation Instructions 316137333 OVER-RANGE FMV156D.tif FMV156EMA Cabinet.eps FMV156D Controls.eps FMV156EMA MICROWAVE wiring schematic.eps Electrolux Major Appliances Model No. North & Latin America FMV156E P.O. BOX 212378 AUGUSTA, GA 30917 Publication No.
  • Page 2 Publication No: 5995457826 FMV156EMA OVEN,CABINET 01/06...
  • Page 3 FMV156EMA Publication No: 5995457826 OVEN,CABINET POS. NO PART NO. DESCRIPTION 5304441844 Rectifier, high voltage 5304440342 Capacitor, high voltage 5304448488 Motor, turntable 5304440032 Thermal Cutout, oven cavity 5304440023 Thermal Cutout, hood 5304453726 Transformer, power 5304441846 Magnetron 5304440026 Switch, interlock, door sensor 5303319559 Switch, monitor, with CT fuse 10 #...
  • Page 4 Publication No: 5995457826 FMV156EMA CONTROL PANEL,DOOR,MISC. 01/06...
  • Page 5 FMV156EMA Publication No: 5995457826 CONTROL PANEL,DOOR,MISC. POS. NO PART NO. DESCRIPTION 23 # 5304441863 Control Board, printed circuit 5304453719 Frame, control panel, silver 25 # 5304441868 Switch, touch pad, black 5304440281 Panel, control mount 5303319584 Screw, control panel, 3mm x 10mm 5304440282 Screw, control board, 3mm x 10mm 5304441871...
  • Page 6: Wiring Schematic

    Publication No: 5995457826 FMV156EMA WIRING SCHEMATIC 01/06...

This manual is also suitable for:

Fmv156ema
