Frigidaire FMV156D Factory Parts Catalog

Over-range microwave
Hide thumbs


Advertisement

Quick Links

Product No.
Market
Color
Volts
Watts
Wiring Diagram
Owner's Guide
Installation Instructions 316137333
FMV156D.tif FMV156D-B Cabinet.eps FMV156D Controls.eps
Wiring.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
FMV156DBB FMV156DCC FMV156DQB FMV156DSB
North America North America North America North America
black
stainless steel bisque
120
120
120
950
950
950
5995451720
5995451720
5995451720
316137230
316137230
316137230
316137333
316137333
FMV156D-B
Publication No.
5995465506
06/04/25
(EN/SERVICE/KC)
099
Copyright
white
120
950
5995451720
316137230
316137333
OVER-RANGE
MICROWAVE
Model No.
FMV156D
©
2006 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

  Related Manuals for Frigidaire FMV156D

  Summary of Contents for Frigidaire FMV156D

  • Page 1 Product No. FMV156DBB FMV156DCC FMV156DQB FMV156DSB Market North America North America North America North America Color black stainless steel bisque white Volts Watts Wiring Diagram 5995451720 5995451720 5995451720 5995451720 Owner's Guide 316137230 316137230 316137230 316137230 Installation Instructions 316137333 316137333 316137333 316137333 OVER-RANGE FMV156D.tif FMV156D-B Cabinet.eps FMV156D Controls.eps...
  • Page 2 Publication No: 5995465506 FMV156D OVEN,CABINET 04/06...
  • Page 3 FMV156D Publication No: 5995465506 OVEN,CABINET Model Index: A FMV156D (FMV156DBB) B FMV156D (FMV156DCC) C FMV156D (FMV156DQB) D FMV156D (FMV156DSB) POS. NO PART NO. DESCRIPTION 5304441844 A B C D Rectifier, high voltage 5304440342 A B C D Capacitor, high voltage 5304448488 A B C D Motor, turntable...
  • Page 4 Publication No: 5995465506 FMV156D OVEN,CABINET 04/06...
  • Page 5 FMV156D Publication No: 5995465506 OVEN,CABINET Model Index: A FMV156D (FMV156DBB) B FMV156D (FMV156DCC) C FMV156D (FMV156DQB) D FMV156D (FMV156DSB) POS. NO PART NO. DESCRIPTION 5304441878 A B C D Duct, hood intake, right side 5304441879 A B C D Duct, exhaust hood, left side 5304451819 A B C D Duct, cooling fan...
  • Page 6 Publication No: 5995465506 FMV156D CONTROL PANEL,DOOR,MISC. 04/06...
  • Page 7 FMV156D Publication No: 5995465506 CONTROL PANEL,DOOR,MISC. Model Index: A FMV156D (FMV156DBB) B FMV156D (FMV156DCC) C FMV156D (FMV156DQB) D FMV156D (FMV156DSB) POS. NO PART NO. DESCRIPTION 23 # 5304441863 A B C D Control Board, printed circuit 5304450254 A - - - Frame, control panel, black 5304448513 - B - -...
  • Page 8: Wiring Schematic

    Publication No: 5995465506 FMV156D WIRING SCHEMATIC 04/06...
