You can use the camera's built in monitor screen to play
back recorded images.
Basic Playback Operation
Use the following procedure to scroll through recorded im-
ages stored in the camera's memory.
1.
Align the power/function switch with
: PLAY mode for playing back images
2.
Rock the control button to the left or right, or
rotate the selector dial to scroll through im-
ages on the monitor screen.
If you want to do this:
Scroll forward
Scroll backward
PLAYBACK
.
Do this:
Rock the control button to the right.
Rock the control button to the left.
PLAYBACK
NOTES
• Keeping the control button pressed toward the left or
right scrolls through images at high speed.
• In order to allow for faster playback image scrolling,
the image that initially appears on the monitor screen
is a preview image, which is of somewhat lower quality
than the actual display image. The actual display im-
age appears about two seconds after the preview im-
age. Note that a fully detailed actual display image
may not be available in the case of some images cop-
ied from certain digital camera models.
E-109
