Sansui HDLCD1909A Owner's Manual

19” wide tft lcd television with digital tuner
Hide thumbs

Advertisement

OWNER'S MANUAL
19" WIDE TFT LCD TELEVISION WITH DIGITAL TUNER
HDLCD1909
HDLCD1909A
HDLCD1909B
If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for
the required programming code.
When shipped from the factory, the Signal Type option is set to the "Cable" (Cable Television) mode.
If not using Cable TV, set this menu option to the "Air" position.
PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL
FOR INFORMATION ON OUR OTHER PRODUCTS, PLEASE VISIT OUR WEBSITE AT
Before operating the unit, please read this manual thoroughly.
AIR/CABLE MODE SELECTION
IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED
CUSTOMER SERVICE – 1-800-289-0980
ORION WEBSITE
www.orionsalesinc.com
ATTENTION

Advertisement

loading

  Related Manuals for Sansui HDLCD1909A

  Summary of Contents for Sansui HDLCD1909A

  • Page 1 OWNER’S MANUAL 19” WIDE TFT LCD TELEVISION WITH DIGITAL TUNER HDLCD1909 HDLCD1909A HDLCD1909B ATTENTION If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the required programming code. AIR/CABLE MODE SELECTION When shipped from the factory, the Signal Type option is set to the “Cable” (Cable Television) mode. If not using Cable TV, set this menu option to the “Air”...
  • Page 2: Location Of The Required Marking

    The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock. CAUTION: TO REDUCE THE RISK OF ELECTRIC The exclamation point within an...
  • Page 3 15) Apparatus should not be exposed to dripping or splashing, and objects filled with liquids, such as vases, should not be placed on the apparatus. 16) An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits.
  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 20) When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer or those that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards. 21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to determine that the unit is in proper operating condition.
  • Page 5: Safety Precautions

    IMPORTANT SAFETY INSTRUCTIONS CONDENSATION Moisture will form in the operating section of the unit if the unit is brought from cool surroundings into a warm room or if the temperature of the room rises suddenly. When this happens, unit's performance will be impaired. To prevent this, let the unit stand in its new surroundings for about an hour before switching it on, or make sure that the room temperature rises gradually.
  • Page 6: How To Attach The Stand

    How to attach the stand NOTE: • Unplug the AC cord from the AC INPUT terminal. • Before beginning this process, assure that TV is laid on a clean, safe, and cushioned space to avoid any damage to the unit. •...
  • Page 7: Table Of Contents

    Contents Before using your unit IMPORTANT SAFETY INSTRUCTIONS ...3 SAFETY PRECAUTIONS .........5 IMPORTANT NOTICE ........5 How to attach the stand ........6 How to remove the stand ........6 Power source ............6 Contents ............7 Parts and functions ...........8 Remote control ..........9 Antenna connections ........10 Cable TV connections ........11 Connections to other equipment .....12 TV operation...
  • Page 8: Parts And Functions

    Parts and functions Front Left side VOLUME +/– buttons CHANNEL buttons MENU button INPUT/ENTER button POWER button To display the menu screen. Remote sensor Press MENU button to display the menu screen. CHANNEL buttons, VOLUME POWER indicator +/– buttons and INPUT/ENTER button Red: Standby can be used to select the desired setting Green: On...
  • Page 9: Remote Control

    Remote control 6.MENU Button - Use to display the On-Screen menu function. 7.EXIT Button - Press to remove setup menu. 8.SLEEP Button - To set the LCD TV to turn off after a preset amount of time, use the SLEEP button on the remote control.
  • Page 10: Antenna Connections

    Antenna connections If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you are using a Cable TV service, see page 11 for Cable TV connections. Combination VHF/UHF Antenna (Single 75 ohm cable or 300 ohm twin-lead wire) Connect the 75 ohm cable from the combination VHF/UHF antenna to the antenna jack.
  • Page 11: Cable Tv Connections

    Cable TV connections This TV has an extended tuning range and can tune most cable channels without using a Cable TV Converter box. Some cable companies offer “premium pay channels” where the signal is scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device which is generally provided by the Cable TV company.
  • Page 12: Connections To Other Equipment

    Connections to other equipment The exact arrangement you use to interconnect various video and audio components to this unit is dependent on the model and features of each component. Check the Owner’s Manual provided with each component for the location of video and audio inputs and outputs. To connect the LCD TV to a VCR Rear of the unit To VIDEO/AUDIO IN...
  • Page 13 Connections to other equipment (continued) Using an AV Amplifier with built-in digital surround If you are using an Amplifier with built-in digital surround sound, you can enjoy various audio systems including Dolby Digital Surround audio that sounds just like the movie. Connect an AV amplifier with built-in Dolby Digital decoder, etc.
  • Page 14: Tv Operation

    Starting setup TO SELECT ANALOG CHANNELS 1-9: Press 1-9 as needed. Example, to select channel 2, press 2, then press The Starting Setup menu appears the first time ENTER. you turn on the TV, and assists you to select the 10-99: Press the 2 digits in order.
  • Page 15: Quick Guide For Menu Operation

    Quick guide for menu DISPLAY Press DISPLAY to display the current information on operation the screen. When the TV receives a digital signal, the digital information will appear. Call menu and for example: Select Language. 62-001 HDTV Moving Picture1 Sleep Timer Press INPUT SELECT to select TV mode.
  • Page 16: Convenience Functions

    Convenience functions You can change the default settings to convenience use. Icon Selected Items Setup hint Picture Picture Brightness / You can adjust the picture quality to your preference. Setting Contrast / Sharpness / Color / Tint Color Bluish (Cool) / Neutral (Standard) / Reddish (Warm) Temperature Backlight The Backlight feature adjusts the screen brightness for improved picture...
  • Page 17: Memorizing Channels

    Memorizing channels The TV will begin memorizing all the channels available in your area. • It may take from 15 minutes to 30 minutes to This TV is equipped with a channel memory complete memorizing digital cable channels. feature which allows channels to skip up or down Depending on the reception condition, a bar to the next channel set into memory, skipping display may not advance for several minutes,...
  • Page 18: Checking The Digital-Signal Strength

    Clear All Ch Label Channel Number 15-1 All channels are deleted from the channel memory. Ch Label Label Clear >> Select “Channel”, then press ▶ or ENTER. Press ▲ or ▼ to select “Add/Delete”, then press ▶ : Adjust : Select or ENTER.
  • Page 19: Setting The V-Chip

    Setting the V-Chip Genre: : All : Dialogue An age limitation can be set to restrict children from : Language viewing or hearing violent scenes or pictures that you : Sex may choose to exclude. The restriction applies to “TV : Violence Rating”...
  • Page 20: Closed Caption

    Press ▲ or ▼ to select “V-Chip”, then press ◀ or Press ◀ or ▶ to set “CC Setting” to “On”. ▶ to select “On”. On: Captions will be displayed on the screen. Off: Captions will not be displayed on the screen. Press ▲...
  • Page 21: Setting The Picture Size

    Press ▲ or ▼ to select “CC Advanced”, then press ▶ or ENTER. The CC Advanced menu will appear. Press ▲ or ▼ to select the desired item, then press ◀ or ▶ to change the setting. Cinema Wide1 (for 4:3 format programs) To fill the screen, the right and left edges are CC Advanced Text Size...
  • Page 22: Troubleshooting

    Troubleshooting Use the following checklist for troubleshooting if you have problems with your LCD TV. Consult your local dealer or service outlet if problems persist. Be sure all connections are properly made when using with other units. SYMPTOMS POSSIBLE SOLUTIONS SYMPTOMS POSSIBLE SOLUTIONS Digital...
  • Page 23: Specifications

    Specifications GENERAL Power supply: AC 120V 60Hz Power consumption: Operation: 29W Stand by: 0.8W Weight: 3.8 kg (8.4 lbs) Dimensions: Width: 472 mm (18-9/16 inches) Height: 362 mm (14-1/4 inches) Depth: 174 mm (6-7/8 inches) Operating temperature: 5˚C - 40˚C Operating humidity: Less than 80% Type:...
  • Page 24: Limited Warranty

    limited WARRANTY 19” WIDE LCD TELEVISION ORION warrants this product to be free from manufacturing defects in material and workmanship under normal use and conditions for a period of 1 year from date of original purchase in the United States. Should service be necessary under this warranty for any reason due to a manufacturing defect or malfunction during the first 12 months from date of original purchase, ORION will provide carry-in service only by an ORION authorized Independent Service Center at no charge.

This manual is also suitable for:
