OWNER'S MANUAL
19" CLASS WIDE LCD TV
HDLCD185W
If you purchase a universal remote control from your local retailer, please contact the remote manufac-
turer for the required programming code.
When shipped from the factory, the Signal Type option is set to the "Cable" (Cable Television) mode. If
not using Cable TV, set this menu option to the "Air" position.
PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL
FOR INFORMATION ON OUR OTHER PRODUCTS AND RECYCLING INFORMATION,
Before operating the unit, please read this manual thoroughly.
ATTENTION
AIR/CABLE MODE SELECTION
IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED
CUSTOMER SERVICE – 1-800-289-0980
ORION WEBSITE
PLEASE VISIT OUR WEBSITE AT
www.orionsalesinc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDLCD185W and is the answer not in the manual?

Questions and answers

Nancy Ryder
March 23, 2025

Can I use a Roku stick

Subscribe to Our Youtube Channel

Summary of Contents for Sansui HDLCD185W

  • Page 1 OWNER’S MANUAL 19” CLASS WIDE LCD TV HDLCD185W ATTENTION If you purchase a universal remote control from your local retailer, please contact the remote manufac- turer for the required programming code. AIR/CABLE MODE SELECTION When shipped from the factory, the Signal Type option is set to the “Cable” (Cable Television) mode. If not using Cable TV, set this menu option to the “Air”...
  • Page 2: Location Of The Required Marking

    ENGLISH The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock. CAUTION: TO REDUCE THE RISK OF ELECTRIC The exclamation point within an...
  • Page 3 15) Apparatus should not be exposed to dripping or splashing, and objects filled with liquids, such as vases, should not be placed on the apparatus. 16) An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits.
  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 20) When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer or those that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards. 21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to determine that the unit is in proper operating condition.
  • Page 5: Safety Precautions

    IMPORTANT SAFETY INSTRUCTIONS CONDENSATION Moisture will form in the operating section of the unit if the unit is brought from cool surroundings into a warm room or if the temperature of the room rises suddenly. When this happens, unit's performance will be impaired. To prevent this, let the unit stand in its new surroundings for about an hour before switching it on, or make sure that the room temperature rises gradually.
  • Page 6: How To Attach The Stand

    How to attach the stand NOTE: • Unplug the AC cord from the AC INPUT terminal. • Before beginning this process, assure that the TV is laid on a clean, safe, and cushioned surface to avoid any damage to the unit. •...
  • Page 7: Features

    Features • Integrated Digital Tuner - You can view digital broadcasts without using a Digital TV Set-Top Box. • Closed Caption Decoder With Full Text Mode - Displays text captions or full screen text on the screen for hearing impaired viewers. •...
  • Page 8: Table Of Contents

    Contents Before using your unit IMPORTANT SAFETY INSTRUCTIONS ...3 SAFETY PRECAUTIONS .........5 How to attach the stand ........6 How to remove the stand ........6 Features ............7 Power source ............7 Contents ............8 Parts and functions ...........9 Remote control ..........10 Antenna connections ........11 Cable TV connections ........11 Connections to other equipment .....12 TV operation...
  • Page 9: Parts And Functions

    Parts and functions Front Right side VOLUME +/– buttons CHANNEL buttons MENU button INPUT/ENTER button POWER button Press MENU button to display the menu Remote sensor screen. CHANNEL buttons, VOLUME Power indicator +/– buttons and INPUT/ENTER button Red: Standby can be used to select the desired setting during the menu screen operations.
  • Page 10: Remote Control

    Remote control 6.MENU Button - Use to display the On-Screen menu function. 7.SLEEP Button - To set the LCD TV to turn off after a preset amount of time, use the SLEEP button on the remote control. 8.CCD Button - Used to display the Closed Caption menu screen.
  • Page 11: Antenna Connections

    Antenna connections If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you are using a Cable TV service, see “Cable TV connections”. Combination VHF/UHF Antenna (Single 75-ohm cable) Connect the 75-ohm cable from the combination Antenna Jack VHF/UHF antenna to the Antenna Jack.
  • Page 12: Connections To Other Equipment

    Connections to other equipment The exact arrangement you use to interconnect various video and audio components to this unit is dependent on the model and features of each component. Check the Owner’s Manual provided with each component for the location of video and audio inputs and outputs. To connect the unit to a VCR Rear of the unit To VIDEO/AUDIO IN...
  • Page 13: Using Av Amplifier With Built-In Surround

    Connections to other equipment (continued) Using an AV Amplifier with built-in digital surround If you are using an AV Amplifier with built-in digital surround sound, you can enjoy various audio systems including Dolby Digital Surround audio that sounds just like the movie. Connect an AV amplifier with built-in Dolby Digital decoder, etc.
  • Page 14 Connections to other equipment (continued) To connect a HDMI or a DVI device to the unit The HDMI input receives digital audio and uncompressed video from a HDMI device or uncompressed digital video from a DVI device. When you connect to a DVI device with a HDMI-to-DVI adapter cable, it transfers only video signal. Separate analog audio cords required.
  • Page 15: Tv Operation

    Starting setup Set the Signal Type option to the appropriate position (see “Air/Cable selection” on page 18). Press the Direct Channel Selection (0-9, –) The Auto Setup menu appears the first time you buttons to select the channel. turn on the TV, and assists you to specify the (If you press only channel number, channel Air/Cable setting, and program your channels selection will be delayed for a few seconds.)
  • Page 16: Quick Guide For Menu Operation

    time is programmed, the display will appear briefly every ten minutes to remind you that the sleep timer Press and release CH . The channel is operating. To confirm the sleep timer setting, press automatically stops at the next channel set into SLEEP and the remaining time will be displayed for a memory.
  • Page 17: Convenience Functions

    Convenience functions You can change the default settings by pressing the MENU button on your remote, then select the one of the icons at the left of the menu - follow the On-Screen prompts to set your preferences. Icon Selected Items Setup hint Picture Picture...
  • Page 18: Memorizing Channels

    Memorizing channels The TV will begin memorizing all the channels available in your area. • It may take from 15 minutes to 30 minutes to This TV is equipped with a channel memory complete memorizing digital cable channels. feature which allows channels to skip up or down Depending on the reception condition, a bar to the next channel set into memory, skipping display may not advance for several minutes,...
  • Page 19: Checking The Digital Signal Strength

    Clear All Ch Label All channels are deleted from the channel memory. Channel Number 15-1 Ch Label CH-1 Label Clear >> Select “Channel”, then press ▶ or ENTER. Press ▲ or ▼ to select “Add/Delete”, then press ▶ or ENTER. :Adjust :Select Press ◀...
  • Page 20: Setting The V-Chip

    Setting the V-Chip Genre: : Dialogue : Language An age limitation can be set to restrict children from : Sex viewing or hearing violent scenes or pictures that you : Violence : Fantasy Violence may choose to exclude. The restriction applies to “TV Rating”...
  • Page 21: Closed Caption

    Press ◀ or ▶ to set “CC Setting” to “On”. Press ◀ or ▶ to set “V-Chip” to “On”. On: Captions will be displayed on the screen. Press ▲ or ▼ to select “V-Chip Set (DTV)”, then Off: Captions will not be displayed on the screen. press ▶...
  • Page 22: Setting The Picture Size

    Press ▲ or ▼ to select “CC Advanced”, then press ▶ or ENTER. The CC Advanced menu will appear. Press ▲ or ▼ to select the desired item, then press ◀ or ▶ to change the setting. Cinema Wide1 (for 4:3 format programs) To fill the screen, the right and left edges are CC Advanced extended, however;...
  • Page 23: Reception Disturbances

    Reception disturbances Most types of television interference can be remedied by adjusting the height and position of the VHF/UHF antenna. Outdoor antennas are recommended for best results. The most common types of television interference are shown below. If one of these symptoms appear when the TV is connected to a Cable TV system, the disturbance may be caused by the local Cable TV company broadcast.
  • Page 24: Troubleshooting

    Troubleshooting Use the following checklist for troubleshooting if you have problems with your unit. Consult your local dealer or service outlet if problems persist. Be sure all connections are properly made when using with other units. SYMPTOMS POSSIBLE SOLUTIONS SYMPTOMS POSSIBLE SOLUTIONS Digital •...
  • Page 25: Specifications

    Specifications GENERAL Power supply: AC 120V, 60Hz Power consumption: Operation: 29W Stand by: 0.3W Weight: 3.2 kg (7.1 lbs) Dimensions: Width: 472 mm (18-9/16 inches) Height: 362 mm (14-1/4 inches) Depth: 174 mm (6-7/8 inches) Operating temperature: 5˚C - 40˚C Operating humidity: Less than 80% RH Type:...
  • Page 26: Limited Warranty

    limited WARRANTY 19” WIDE LCD TELEVISION ORION warrants this product to be free from manufacturing defects in material and workmanship under ORION warrants this product to be free from manufacturing defects in material and workmanship under normal use and conditions for a period of 1 year from date of original purchase in the United States. normal use and conditions for a period of 1 year from date of original purchase in the United States.
  • Page 27 Memo ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 28 J3EZ0601A SH 11/07 Printed in Thailand...
