Oracle 5.0 Reference Manual page 1850

• Column Details tab - a tab on bottom of the Table Designer. Use the Column Details tab to set
advanced column options.
• Properties window - a standard Visual Studio Properties window, where the properties of the edited
table are displayed. Use the Properties window to set the table properties.
Each of these areas is discussed in more detail in subsequent sections.
To save changes you have made in the Table Designer, use either Save or Save All button of the
Visual Studio main toolbar, or press Control+S. If you have not already named the table, you will be
prompted to do so.
Figure 20.6. Choose Table Name
Once the table is created, you can view it in the Server Explorer.
Figure 20.7. Newly Created Table
The Table Designer main menu lets you set a
keys, and create indexes.
Figure 20.8. Table Designer Main Menu
20.2.3.3.1. Column Editor
You can use the Column Editor to set or change the name, data type, default value, and other
properties of a table column. To set the focus to a needed cell of a grid, use the mouse click. Also you
can move through the grid using Tab and Shift+Tab keys.
Connector/Net Visual Studio Integration
primary key
1830
column, edit relationships such as foreign
