HP Kayak XA 05xx PC Workstation—

Technical Information

This section provides technical information about your PC Workstation
and includes details about the system board connectors and switches.

Advertisement

Table of Contents
loading

Related Manuals for HP Kayak XA 05xx

Summary of Contents for HP Kayak XA 05xx

  • Page 1: Technical Information

    HP Kayak XA 05xx PC Workstation— Technical Information This section provides technical information about your PC Workstation and includes details about the system board connectors and switches.
  • Page 2 HP Kayak XA 05xx PC Workstation — Technical Information Features Features Feature: Description: Processor (standard) Pentium II Cache Memory • Level-One: 16 KB code, 16 KB data (integrated in processor package) • Level-Two: 512 KB Main memory (size/speed) Upgradeable to 768 MB (SDRAM)
  • Page 3 HP Kayak XA 05xx PC Workstation — Technical Information Features Feature: Description: 9-pin serial connectors • Standard: Two UART 16550 buffered serial ports (both RS-232-C). • Serial Ports A and B: 2F8h (IRQ 3), 2E8h (IRQ 3), 3F8h (IRQ 4), 3E8h (IRQ 4), or Off—...

  • Page 4: System Specifications

    HP Kayak XA 05xx PC Workstation — Technical Information System Specifications System Specifications Power Consumption Information Maximum power consumption 200 W Operating 80 W (average) Idle 45 W (average) 2.5 W (average) The power supply in your PC Workstation continues to supply power to the CMOS memory, even when switched off.

  • Page 5: Irqs, Dmas, And I/O Addresses Used By Your Pc Workstation

    HP Kayak XA 05xx PC Workstation — Technical Information System Specifications IRQs, DMAs, and I/O Addresses Used by Your PC Workstation The IRQ, DMA, and I/O address mappings shown here are for a basic configuration. The resources used by your PC Workstation may vary, depending on which accessory boards are bundled with the PC Workstation.
  • Page 6 HP Kayak XA 05xx PC Workstation — Technical Information System Specifications I/O Addresses used by PC 0000 - 000F DMA controller 1 Workstation 0020 - 0021 Master interrupt controller 002E - 002F Configuration registers 0040 - 0043 Timer 1 0060, 0064...

  • Page 7: System Connectors And Switches

    HP Kayak XA 05xx PC Workstation — Technical Information System Connectors and Switches System Connectors and Switches System Board Connectors Power Supply Power Processor Fan MT Status Panel MT LCD Panel Disk Drive Fan External Battery Memory Modules Primary IDE...

  • Page 8: System Board Switches

    HP Kayak XA 05xx PC Workstation — Technical Information System Connectors and Switches System Board Switches The following diagram shows the position of the system board switches on a Desktop HP Kayak XA Workstation: System Board Switches Switch 1 is reserved and should not be used. Its default position is Up.
  • Page 9 HP Kayak XA 05xx PC Workstation — Technical Information System Connectors and Switches Switches 6 to 10 are used as shown in the following table: Switch Use Switch to: 1 - RESERVED Do not use. 6 - CLEAR CMOS Retain or clear CMOS memory: •...
