Frigidaire FRS26KR4D Factory Parts Catalog

Frigidaire FRS26KR4D Factory Parts Catalog

Side-by-side refrigerator
Hide thumbs Also See for FRS26KR4D:
Table of Contents

Advertisement

Quick Links

Product No.
FRS26KR4DB3 FRS26KR4DQ3 FRS26KR4DS3 FRS26KR4DS4 FRS26KR4DW3 FRS26KR4DW4 FRS26KR4DW5
Series
R134a
Color
black
Volts
115
Wiring Diagram
241526901
Owner's Guide
240581300
Market
North America
Energy Guide
241585909
Service Data Sheet 240389616
N58L00001.eps N58FACBBB4.eps N58RACBBB6.eps N58BAAAAA0.eps
N58SJCAAB1.eps N58TAAAAA6.eps N58CAAAAA4.eps N58XDAAAA1.eps
N58YBAAAA1.eps N58I115.eps W241526901A.eps S241526901A.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
R134a
R134a
R134a
bisque
stain/blk
stain/blk
115
115
115
241526901
241526901
241526901
240581300
240581300
240581300
North America
North America
North America
241585909
241585909
241585909
240389616
240389616
240389616
Publication No.
5995421061
04/11/04
(EN/SERVICE/DCS)
357
R134a
R134a
white
white
115
115
241526901
241526901
240581300
240581300
North America
North America
241585909
241585909
240389616
240389616
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS26KR4D
©
Copyright
All rights reserved.
R134a
white
115
241526901
240581300
North America
241585909
240389616

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS26KR4D and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS26KR4D

Summary of Contents for Frigidaire FRS26KR4D

  • Page 1 Product No. FRS26KR4DB3 FRS26KR4DQ3 FRS26KR4DS3 FRS26KR4DS4 FRS26KR4DW3 FRS26KR4DW4 FRS26KR4DW5 Series R134a R134a R134a R134a R134a R134a R134a Color black bisque stain/blk stain/blk white white white Volts Wiring Diagram 241526901 241526901 241526901 241526901 241526901 241526901 241526901 Owner's Guide 240581300 240581300 240581300 240581300 240581300 240581300...

  • Page 2: Freezer Door

    Publication No: 5995421061 FRS26KR4D FREEZER DOOR 11/04...
  • Page 3 FRS26KR4D Publication No: 5995421061 FREEZER DOOR Model Index: A FRS26KR4D (FRS26KR4DB3) B FRS26KR4D (FRS26KR4DQ3) C FRS26KR4D (FRS26KR4DS3) D FRS26KR4D (FRS26KR4DS4) E FRS26KR4D (FRS26KR4DW3) F FRS26KR4D (FRS26KR4DW4) G FRS26KR4D (FRS26KR4DW5) POS. NO PART NO. DESCRIPTION 241569806 A - C D - - - Gasket-frzr door, black, magnetic 241569802 - B - - E F G...

  • Page 4: Refrigerator Door

    Publication No: 5995421061 FRS26KR4D REFRIGERATOR DOOR 11/04...
  • Page 5 FRS26KR4D Publication No: 5995421061 REFRIGERATOR DOOR Model Index: A FRS26KR4D (FRS26KR4DB3) B FRS26KR4D (FRS26KR4DQ3) C FRS26KR4D (FRS26KR4DS3) D FRS26KR4D (FRS26KR4DS4) E FRS26KR4D (FRS26KR4DW3) F FRS26KR4D (FRS26KR4DW4) G FRS26KR4D (FRS26KR4DW5) POS. NO PART NO. DESCRIPTION 241569805 A - C D - - - Gasket-refr door, black, magnetic 241569801 - B - - E F G...
  • Page 6 Publication No: 5995421061 FRS26KR4D CABINET 11/04...
  • Page 7 FRS26KR4D Publication No: 5995421061 CABINET Model Index: A FRS26KR4D (FRS26KR4DB3) B FRS26KR4D (FRS26KR4DQ3) C FRS26KR4D (FRS26KR4DS3) D FRS26KR4D (FRS26KR4DS4) E FRS26KR4D (FRS26KR4DW3) F FRS26KR4D (FRS26KR4DW4) G FRS26KR4D (FRS26KR4DW5) POS. NO PART NO. DESCRIPTION 240435906 A B C D E F G Cover-air duct 240475907 A B C D E F G...
  • Page 8 Publication No: 5995421061 FRS26KR4D SHELVES 11/04...
  • Page 9 FRS26KR4D Publication No: 5995421061 SHELVES Model Index: A FRS26KR4D (FRS26KR4DB3) B FRS26KR4D (FRS26KR4DQ3) C FRS26KR4D (FRS26KR4DS3) D FRS26KR4D (FRS26KR4DS4) E FRS26KR4D (FRS26KR4DW3) F FRS26KR4D (FRS26KR4DW4) G FRS26KR4D (FRS26KR4DW5) POS. NO PART NO. DESCRIPTION 240338802 A B C D E F G Shelf-freezer, flip-up 240338702 A B C D E F G...
  • Page 10 Publication No: 5995421061 FRS26KR4D CONTROLS N58TAAAAA6 11/04...
  • Page 11 FRS26KR4D Publication No: 5995421061 CONTROLS Model Index: A FRS26KR4D (FRS26KR4DB3) B FRS26KR4D (FRS26KR4DQ3) C FRS26KR4D (FRS26KR4DS3) D FRS26KR4D (FRS26KR4DS4) E FRS26KR4D (FRS26KR4DW3) F FRS26KR4D (FRS26KR4DW4) G FRS26KR4D (FRS26KR4DW5) POS. NO PART NO. DESCRIPTION 5308000010 A B C D E F G Fan Blade, red, evaporator fan 215474201 A B C D E F G...
  • Page 12 Publication No: 5995421061 FRS26KR4D SYSTEM N58CAAAAA4 11/04...
  • Page 13 FRS26KR4D Publication No: 5995421061 SYSTEM Model Index: A FRS26KR4D (FRS26KR4DB3) B FRS26KR4D (FRS26KR4DQ3) C FRS26KR4D (FRS26KR4DS3) D FRS26KR4D (FRS26KR4DS4) E FRS26KR4D (FRS26KR4DW3) F FRS26KR4D (FRS26KR4DW4) G FRS26KR4D (FRS26KR4DW5) POS. NO PART NO. DESCRIPTION 240333603 A B C D E F G Condenser 218679607 A B C D E F G...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995421061 FRS26KR4D ICE & WATER DISPENSER 11/04...
  • Page 15 FRS26KR4D Publication No: 5995421061 ICE & WATER DISPENSER Model Index: A FRS26KR4D (FRS26KR4DB3) B FRS26KR4D (FRS26KR4DQ3) C FRS26KR4D (FRS26KR4DS3) D FRS26KR4D (FRS26KR4DS4) E FRS26KR4D (FRS26KR4DW3) F FRS26KR4D (FRS26KR4DW4) G FRS26KR4D (FRS26KR4DW5) POS. NO PART NO. DESCRIPTION 218976409 A B C D E F G Tube-water-DOOR 218976901 A B C D E F G...

  • Page 16: Ice Container

    Publication No: 5995421061 FRS26KR4D ICE CONTAINER 37A 34 34 33 N58YBAAAA1 11/04...
  • Page 17 FRS26KR4D Publication No: 5995421061 ICE CONTAINER Model Index: A FRS26KR4D (FRS26KR4DB3) B FRS26KR4D (FRS26KR4DQ3) C FRS26KR4D (FRS26KR4DS3) D FRS26KR4D (FRS26KR4DS4) E FRS26KR4D (FRS26KR4DW3) F FRS26KR4D (FRS26KR4DW4) G FRS26KR4D (FRS26KR4DW5) POS. NO PART NO. DESCRIPTION 5304428402 A B C D E F G Auger-ice 5304404343 A B C D E F G...

  • Page 18: Ice Maker

    Publication No: 5995421061 FRS26KR4D ICE MAKER 11/04...
  • Page 19 FRS26KR4D Publication No: 5995421061 ICE MAKER Model Index: A FRS26KR4D (FRS26KR4DB3) B FRS26KR4D (FRS26KR4DQ3) C FRS26KR4D (FRS26KR4DS3) D FRS26KR4D (FRS26KR4DS4) E FRS26KR4D (FRS26KR4DW3) F FRS26KR4D (FRS26KR4DW4) G FRS26KR4D (FRS26KR4DW5) POS. NO PART NO. DESCRIPTION 218976409 A B C D E F G Tube-water-DOOR 218976901 A B C D E F G...
  • Page 20 Publication No: 5995421061 FRS26KR4D ICE MAKER 11/04...
  • Page 21 FRS26KR4D Publication No: 5995421061 ICE MAKER Model Index: A FRS26KR4D (FRS26KR4DB3) B FRS26KR4D (FRS26KR4DQ3) C FRS26KR4D (FRS26KR4DS3) D FRS26KR4D (FRS26KR4DS4) E FRS26KR4D (FRS26KR4DW3) F FRS26KR4D (FRS26KR4DW4) G FRS26KR4D (FRS26KR4DW5) POS. NO PART NO. DESCRIPTION 5303001193 A B C D E F G Clamp, .50 ID, steel, water tube 5308000133 A B C D E F G...

  • Page 22: Wiring Schematic

    Publication No: 5995421061 FRS26KR4D WIRING SCHEMATIC 11/04...

  • Page 23: Wiring Diagram

    FRS26KR4D Publication No: 5995421061 WIRING DIAGRAM 11/04 # Functional Parts * Non-Illustrated Parts...
