Frigidaire FRS26KR4J Factory Parts Catalog

Frigidaire FRS26KR4J Factory Parts Catalog

Side by side refrigerator
Hide thumbs
Table of Contents

Advertisement

Quick Links

PRODUCT NO.
BASE MODEL NO.
FRS26KR4JQ0
FRS26KR4J
FRS26KR4JW0
FRS26KR4J
MARKET
North American
WIRING DIAGRAM - # 218903201
OWNER'S GUIDE - # 218955100
SERVICE DATA SHEET - # 218909400
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995341277
000718
-EN/SERVICE/KHB
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26KR4J
©2000 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS26KR4J and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS26KR4J

Summary of Contents for Frigidaire FRS26KR4J

  • Page 1: Side By Side

    PRODUCT NO. BASE MODEL NO. FRS26KR4JQ0 FRS26KR4J FRS26KR4JW0 FRS26KR4J MARKET North American WIRING DIAGRAM - # 218903201 OWNER’S GUIDE - # 218955100 SERVICE DATA SHEET - # 218909400 101 Masters Blvd. Anderson, SC 29624 FACTORY PARTS CATALOG REFRIGERATOR SERIES COLOR...
