Frigidaire FMV145K Factory Parts Catalog

Over-range microwave
Hide thumbs

Advertisement

Quick Links

Download this manual See also: Use and Care Manual, Instruction and Installation Manual
Table of Contents
FMV145K.eps L937D0002.eps L937C0002.eps L937F0002.eps L937B0002.eps
L937I0001.eps
FMV145-3s.eps FMV145-3d.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FMV145KB2 FMV145KS2
Color
black
Market
North America North America
Owner's Guide
316137205
Installation Instructions 316137211
Mini Service Manual
5304409006
Wiring Diagram
5304409006
Volts
120
Watts
950
Publication No.
5995416566
04/09/17
(EN/SERVICE/KC)
099
white
316137205
316137211
5304409006
5304409006
120
950
OVER-RANGE
MICROWAVE
Model No.
FMV145K
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

  Also See for Frigidaire FMV145K

Frigidaire CFMV145 Use & Care Manual
Frigidaire CFMV145 Use & Care Manual 36 pages
Frigidaire FMV145K Installation Instructions Manual
Frigidaire FMV145K Installation Instructions Manual 24 pages
Frigidaire CFMV145BC Factory Parts Catalog
Frigidaire CFMV145BC Factory Parts Catalog 15 pages

  Related Manuals for Frigidaire FMV145K

  Summary of Contents for Frigidaire FMV145K

  • Page 1 Product No. FMV145KB2 FMV145KS2 Color black white Market North America North America Owner's Guide 316137205 316137205 Installation Instructions 316137211 316137211 Mini Service Manual 5304409006 5304409006 Wiring Diagram 5304409006 5304409006 Volts Watts OVER-RANGE FMV145K.eps L937D0002.eps L937C0002.eps L937F0002.eps L937B0002.eps MICROWAVE L937I0001.eps FMV145-3s.eps FMV145-3d.eps ELECTROLUX HOME PRODUCTS, INC.
  • Page 2 Publication No: 5995416566 FMV145K DOOR 09/04...
  • Page 3 FMV145K Publication No: 5995416566 DOOR Model Index: A FMV145K (FMV145KB2) B FMV145K (FMV145KS2) POS. NO PART NO. DESCRIPTION 5304424542 Door, black, complete assy 5304424543 Door, white, complete assy 5304408529 Screen, door, glass, front 5304408523 Handle, door, black 5304408524 Handle, door, white 5304423509 Frame, door, black, outer 5304423510...

  • Page 4: Control Panel

    Publication No: 5995416566 FMV145K CONTROL PANEL 09/04...
  • Page 5 FMV145K Publication No: 5995416566 CONTROL PANEL Model Index: A FMV145K (FMV145KB2) B FMV145K (FMV145KS2) POS. NO PART NO. DESCRIPTION 12 # 5304423362 Control Board, printed circuit 5304408514 Bracket, control mtg 5304408512 Window, control display 15 # 5304423515 Switch, touch control, membrane, black 15 # 5304423516 Switch, touch control, membrane, white...

  • Page 6: Functional Parts

    Publication No: 5995416566 FMV145K FUNCTIONAL PARTS 09/04...
  • Page 7 FMV145K Publication No: 5995416566 FUNCTIONAL PARTS Model Index: A FMV145K (FMV145KB2) B FMV145K (FMV145KS2) POS. NO PART NO. DESCRIPTION 5304408954 Bracket, lamp mtg, bottom 18 # 5304408948 Receptacle, lamp 5304408949 Lamp, incandescent 24 # 5304436713 Wiring Harness, D 26 # 5304408941 Capacitor, motor 27 #...
  • Page 8 Publication No: 5995416566 FMV145K BODY 09/04...
  • Page 9 FMV145K Publication No: 5995416566 BODY Model Index: A FMV145K (FMV145KB2) B FMV145K (FMV145KS2) POS. NO PART NO. DESCRIPTION 5304408972 Plate, oven base, black, bottom cover 5304417436 Plate, oven base, white, bottom cover 5304408977 Filter, air, (2) 5304408988 Lens, cooktop lamp, glass, (2) 5304408973 Cover, lens frame, black, lamp 5304408974...

  • Page 10: Installation

    Publication No: 5995416566 FMV145K INSTALLATION 09/04...
  • Page 11 FMV145K Publication No: 5995416566 INSTALLATION Model Index: A FMV145K (FMV145KB2) B FMV145K (FMV145KS2) POS. NO PART NO. DESCRIPTION 5304408998 Cover, exhaust damper 5304408953 Damper, main exhaust, frame 5304408997 Bracket, power cord 5304429479 Panel, mounting plate, rear 5304411140 Installation Kit, mtg hardware 9999 316137211 Instructions, installation...

  • Page 12: Wiring Diagram

    Publication No: 5995416566 FMV145K WIRING DIAGRAM MODULARITY-OTR-FRIGIDAIRE MODEL NO. : PLMV168KC4, GLMV168KB4, GLMV168KQ4, GLMV168KS4, FMV145 09/04...

  • Page 13: Wiring Schematic

    FMV145K Publication No: 5995416566 WIRING SCHEMATIC MODULARITY-OTR-FRIGIDAIRE MODEL NO. : PLMV168KC4, GLMV168KB4, GLMV168KQ4, GLMV168KS4, FMV145 09/04 # Functional Parts * Non-Illustrated Parts...
