Frigidaire FGMV185K Factory Parts Catalog

Over-range microwave
Hide thumbs


Advertisement

Product No.
Market
Color
Volts
Watts
Wiring Diagram
Owner's Guide
Installation Instructions 316495060
FGMV185K Cover.eps FGMV185K Cabinet.eps FGMV185K Controls.eps
FGMV185K Wiring.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
FGMV185KBA FGMV185KFA FGMV185KWA FPMV189KFA
North America North America North America North America
black
stainless
white
120
120
120
1000
1000
1000
5995536520
5995536520
5995536520
316495055en 316495055en 316495055en
316495060
316495060
FGMV185K / FPMV189K
Publication No.
5995536520
09/03/26
(EN/SERVICE/KC)
099
Copyright
stainless
120
1000
5995536520
316495055en
316495060
OVER-RANGE
MICROWAVE
Model No.
©
2009 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

  Also See for Frigidaire FGMV185K

  Related Manuals for Frigidaire FGMV185K

  Summary of Contents for Frigidaire FGMV185K

  • Page 1 Product No. FGMV185KBA FGMV185KFA FGMV185KWA FPMV189KFA Market North America North America North America North America Color black stainless white stainless Volts Watts 1000 1000 1000 1000 Wiring Diagram 5995536520 5995536520 5995536520 5995536520 Owner's Guide 316495055en 316495055en 316495055en 316495055en Installation Instructions 316495060 316495060 316495060 316495060...
  • Page 2 Publication No: 5995536520 FGMV185K / FPMV189K OVEN,CABINET FGMV185K Cabinet 03/09...
  • Page 3 FGMV185K / FPMV189K Publication No: 5995536520 OVEN,CABINET Model Index: A FGMV185K (FGMV185KBA) B FGMV185K (FGMV185KFA) C FGMV185K (FGMV185KWA) D FPMV189K (FPMV189KFA) POS. NO PART NO. DESCRIPTION 5304467670 A B C D Rectifier, high voltage 5304467671 A B C D Capacitor, high voltage 5304467690 A B C D Motor, turntable...
  • Page 4 Publication No: 5995536520 FGMV185K / FPMV189K OVEN,CABINET FGMV185K Cabinet 03/09...
  • Page 5 FGMV185K / FPMV189K Publication No: 5995536520 OVEN,CABINET Model Index: A FGMV185K (FGMV185KBA) B FGMV185K (FGMV185KFA) C FGMV185K (FGMV185KWA) D FPMV189K (FPMV189KFA) POS. NO PART NO. DESCRIPTION 5304467726 A B C D Gasket, hood fan motor, cushion 5304467727 A B C D Lens, lamp filter 5304467728 A B C D...
  • Page 6 Publication No: 5995536520 FGMV185K / FPMV189K CONTROL PANEL,DOOR,MISC. FGMV185K Controls 03/09...
  • Page 7 FGMV185K / FPMV189K Publication No: 5995536520 CONTROL PANEL,DOOR,MISC. Model Index: A FGMV185K (FGMV185KBA) B FGMV185K (FGMV185KFA) C FGMV185K (FGMV185KWA) D FPMV189K (FPMV189KFA) POS. NO PART NO. DESCRIPTION 30 # 5304472034 A B C D Control Board, printed circuit 5304472038 A - - - Cover, control panel, black 5304472036 - B - -...
  • Page 8: Wiring Schematic

    Publication No: 5995536520 FGMV185K / FPMV189K WIRING SCHEMATIC 03/09...
