- Page 1 User information Ceramic glass ZVH 66 F...
-
Page 2: Table Of Contents
Thank you for selecting our appliance We wish you lots of enjoyment with your new appli- ance and we hope that you will consider our brand again when purchasing household appliances. Please read this user manual carefully and keep it throughout the product life cycle as a reference doc- ument. -
Page 3: Operating Instructions
Operating Instructions Safety instructions General safety Please comply with these instructions. If you do not, any damage resulting is not covered by the • The appliance may only be installed and warranty. connected by trained, registered service en- gineers. Correct use •... -
Page 4: Description Of The Appliance
How to avoid damage to the appli- • Objects that melt and things that boil over can burn onto the glass ceramic and should ance be removed straightaway. • The glass ceramic can be damaged by ob- • To avoid damaging cookware and glass ce- jects falling onto it. -
Page 5: Control Panel Layout
Control panel layout Cooking zone indicators Heat setting selection Lock Timer function with pilot light Display Timer display Double ring cooking zone switch Double ring Timer with pilot light cooking zone On/Off switch with pilot with power indicator Touch Control sensor fields The appliance is operated using Touch Control sensor fields. -
Page 6: Residual Heat Indicator
Displays Display Description Cooking zone is switched off Keep warm setting Keep warm setting is set Heat settings Heat setting is set Automatic warm up function Automatic warm-up function is activated Fault Malfunction has occurred Residual heat Cooking zone is still hot Child safety device Lock/child safety device is engaged Automatic switch off... -
Page 7: Operating The Appliance
Operating the appliance Switching the appliance on and Control panel Display Pilot light Switch on Touch for 2 seconds lights up Switch off Touch for 1 second / none goes out After switching on, within approx. 10 seconds a heat setting or a function must be set, otherwise the appliance auto- matically switches itself off. - Page 8 Locking/unlocking the control panel The control panel, with the exception of the “On/Off” sensor field, can be locked at any time in order to prevent the settings being changed e.g. by wiping over the panel with a cloth. Control panel Display Switch on Touch...
- Page 9 Using the automatic warm-up setting using , when starting from , the cooking zone switches to full power for a cer- function tain amount of time and then automatically All cooking zones are equpped with an auto- switches back to the heat setting set. matic warm up function When setting a heat Control possible heat...
-
Page 10: Using The Child Safety Device
Using the child safety device The child safety device prevents unintentional use of the appliance. Switching on the child safety device Step Control panel Display/Signal Switch on appliance. (Do not set a heat setting.) Touch for 4 seconds The child safety device is switched on. Switching off the child safety device Step Control panel... -
Page 11: Power Management
Power Management The appliance has a maximum power output. If this maximum power is exceeded, the Power Management automatically reduces the power of the last cooking zone to be switched on. This can happen by: • switching on another cooking zone •... -
Page 12: Using The Timer
Using the timer Function Condition Outcome after the time has elapsed Automatic cut-out a heat setting is set acoustic signal flashes Cooking zone switches off Countdown timer cooking zones not in use acoustic signal flashes If a heat setting is set on this cooking zone in addition to a countdown timer, the cook- ing zone is switched off after the time set has elapsed. - Page 13 Setting the time Step Control panel Indicator Select cooking zone Pilot light for the cooking zone selected flashes Touch minutes After a few seconds the pilot light flashes more slowly. The time is set. The time counts down. Switching off the timer function Step Control panel Indicator...
-
Page 14: Automatic Switch Off
Switching off the acoustic signal Step Control panel field Acoustic signal Touch Acoustic signal to acknowledge. Acoustic signal stops. Automatic switch off Cooking surface • If after switching on the cooking surface, a heat setting is not set for a cooking zone within approx. -
Page 15: Tips On Cooking And Frying
Tips on Cooking and Frying Information on acrylamides According to the latest scientific knowl- edge, intensive browning of food, especial- ly in products containing starch, can constitute a health risk due to acrylamides. Therefore we recommend cooking at the lowest possible temperatures and not browning foods too much. - Page 16 Examples of cooking applica- tions The information given in the following table is for guidance only. Heat Cooking- suitable for Cooking time Tips/Hints setting process Residual heat, Off position Keeping Keeping cooked foods warm as required Cover food warm Hollandaise sauce, Melting 5-25 mins.
-
Page 17: Cleaning And Care
Cleaning and Care Cleaning the appliance after each Take care! Risk of burns from residual heat. Warning! Sharp objects and abrasive 1.Wipe the appliance with a damp cloth and a cleaning materials will damage the appli- little washing up liquid. ance. -
Page 18: What To Do If
What to do if … Problem Possible cause Remedy The cooking zones will not switch on More than 10 seconds have passed Switch the appliance on again. or are not functioning since the appliance was switched on The child safety device is switched Deactivate the child safety device (See the section “Child safety de- vice”) -
Page 19: Disposal
Problem Possible cause Remedy and number are displayed Electronics fault Disconnect the appliance from the electrical supply for a few minutes (Take the fuse out of the house’s wiring system) If after switching on again, is dis- played again, call the customer service department If you are unable to remedy the If the appliance has been operated incor-... -
Page 20: Installation Instructions
Installation Instructions Safety instructions Risk of injury from electrical cur- rent. Warning! This must be read! • Loose and inappropriate plug and socket The laws, ordinances, directives and standards connections can make the terminal overheat. in force in the country of use are to be followed •... -
Page 21: Assembly
Assembly... -
Page 25: Rating Plate
Rating Plate ZVH 66 F 949 593 078 55HAD64AO 230 V 50 Hz 2,4 kW ZANUSSI... -
Page 27: Service
Service In the event of technical faults, please first check whether you can remedy the problem yourself with the help of the operating instruc- tions (section “What to do if…”). If you were not able to remedy the problem yourself, please contact the Customer Care Department or one of our service partners. - Page 28 867 202 414-A-040808-01 Subject to change without notice...
