- Page 1 EINBAU-BACKOFEN MIT DAMPFGARENRICHTUNG FOUR À VAPEUR STOOMOVEN BUILT-IN STEAM OVEN ZBS 862 GEBRAUCHSANLEITUNG NOTICE D'UTILISATION GEBRUIKSAANWIJZING INSTRUCTION BOOKLET...
-
Page 2: For Your Safety
Repairs carried out by This appliance complies with the following unexperienced persons may cause injury or serious E.E.C. Directives: malfunctioning. Refer to your local Zanussi Service 73/23 - 90/683 (Low Voltage Directive); Centre. Always insist on genuine Zanussi spare 89/336 (Electromagnetical Compatibility Directive);... -
Page 3: Table Of Contents
Contents For Your Safety ......... 61 Technical Data .......... 78 Description of the appliance ..... 63 Installation ..........78 Building In ............78 Oven Control Knobs ......... 64 Securing the Oven to the Cabinet ..... 79 Oven Function Control Knob ......64 Electric Connection ........... -
Page 4: Description Of The Appliance
Description of the appliance GREEN PILOT RED PILOT LIGHT LIGHT THERMOSTAT (TANK OUT OF (FULL TANK) WATER) CONTROL LIGHT COOKING THERMOSTAT FUNCTION CONTROL KNOB CONTROL KNOB RED PILOT LIGHT END OF COOKING (CLEANING PROGRAMMER NEEDED) WATER TANK FEEDING DRAWER GRILLELEMENT STEAM INJECTOR OVEN LAMP... -
Page 5: Oven Control Knobs
Oven Control Knobs Your new steam oven allows you to cook your favourite dishes without losing any nutrition property and keeping their original taste. You can choose both the traditional cooking systems or the steam cooking system. To obtain the best cooking results, it is necessary to get familiar with the oven controls. -
Page 6: End Of Cooking Programmer
If this happens, call your local Zanussi Service Centre. Under no circumstances should you attempt to repair the appliance yourself. The Cooling Fan for the Controls... -
Page 7: When The Oven Is First Installed
When the oven is first installed Once the oven has been installed: To open the oven door, always catch a) set the thermostat knob to MAX; the handle in its central part (Fig. 4). b) switch the oven function control knob to conventional cooking ( c) allow the oven to run empty for approximately 45 minutes;... -
Page 8: Water Tank Pilot Lamps
Water tank pilot lamps Red pilot lamp (full water tank) It indicates that the oven is ready to be used for a steam cooking. Red pilot lamp (tank out of water) It indicates that the oven cannot be used for a steam cooking and water should be poured into the water tank. -
Page 9: Hints And Tips About Steam Cooking
Cooking with steam 1 - Before any steam cooking, fill the water tank as described in the previous chapter. One liter of water allows about 1 hour of steam cooking. 2 - Place the food in suitable ovenproof pans or pots and place them on the oven shelf (Fig. -
Page 10: Accessories For Steam Cooking
Accessories for steam cooking A special accessory kit is available at your retailer's shop. This is meant to allow a wider range of steam cookings, especially for fish, vegetables, etc. The accessory kit includes: - a diet cooking double dish, provided with a special mould to allow a steam injector to be fitted to the dish (Fig. -
Page 11: Steam Cooking Chart
Steam cooking chart Cooking duration Weight Steam cooking Notes Food temp. Level minutes Cakes Whipped up kneading 30 ~ 45 Leavened kneading 30 ~ 45 Creme caramel 40 ~ 60 Butter-milk cheese cake 40 ~ 60 Apple cake 30 ~ 45 Strudel 45 ~ 60 Jam-tart... -
Page 12: Traditional, Fan And Grill Cookings
Traditional, fan and grill cookings Conventional cooking Hints and Tips on Cooking Fish and Meat Turn the oven function control knob to the relevant You can place meat in oven proof dishes, or directly on the oven shelf. In this case, remember to place the symbol ( ) and set the thermostat knob on the dripping pan in the first position from the bottom (see... -
Page 13: Cooking Charts (Traditional And Fan Oven, Grill)
Cooking charts (traditional and fan oven, grill) TRADITIONAL COOKING AND FAN DUCTED COOKING Cooking WEIGHT time Traditional Cooking Fan Oven NOTES TYPE OF DISH (GR.) temp. temp. Level Level minutes Cakes Whipped up kneading 2 (1 and 3)* 45 ~ 60 Leavened kneading 2 (1 and 3)* 20 ~ 35... -
Page 14: Cleaning And Maintenance
Never use harsh abrasives, steel wool or If the gasket shows to be damaged, call you cleaners with bleach, as they could damage local Zanussi Service Centre. Do not use the the enamel and the oven door glass. oven until it has been repaired. -
Page 15: Cleaning The Steam Generator
Replacing the Oven Light Ensure the electricity supply is switched off before carrying out this operation. The oven bulb has to comply to these features: a) resistant to temperatures of 300 C; b) electric rate: 230 V - 50 Hz; c) electric power rate: 15 W.;... -
Page 16: Cleaning The Exhaust Pipe
When water stops flowing out the water tank, turn the pipe connector clockwise to close the exhaust-valve. Warning! - The connector "A" has not a block fitting. Take care this connector doesn't slip off the pipe during the water tank exhaust procedure. After the water tank has been drained, melt two spoonful of citric acid (about 50-60 grams) into 800 cc. -
Page 17: What Happens If Something Goes Wrong
Cooking" function, that is on symbol Carefully close the oven door Fill the water tank Buy a new oven light bulb, asking for it to your local Zanussi THE OVEN LAMP DOES NOT COME ON Service Centre and replace it by following the instruction provided in this booklet. -
Page 18: Guarantee
If after the checks listed in the previous chapter, the appliance still does not work correctly, contact your locals Zanussi Service Centre, specifying the type of malfunctioning, the appliance model (Mod.), the product number (Prod. No.) and the serial number (Ser. -
Page 19: Technical Data
Technical Data Oven ratings Top + Bottom heating elements 1800 W Recess in coloumn: 580 mm Grill element 1750 W dimensions height undertop: 591 mm Fan oven element 2000 W width 560 mm Steam generator 735 W depth 550 mm Oven light 25 W Cooling fan... -
Page 20: Securing The Oven To The Cabinet
Securing the Oven to the Cabinet Fit the appliance into the cabinet recess. Open teh oven door and secure the oven to the kitchen cabinet with four wood screws, which fit the holes provided in the oven frame (Fig. 23-24). When installing an electric plate hob over the oven, the hob's electrical connection and the oven's one have to be carried out separately, for security reasons and to let...
