- Page 1 DVI-9990 DVD-Audio/Video Tuner Guide for Installation and Connections Guide d’installation et de connexions Guía de instalación y conexiones English Français Español Español Italiano Svenska...
- Page 2 ALPINE ELECTRONICS MARKETING, INC. ALPINE ELECTRONICS OF AMERICA, INC. ALPINE ELECTRONICS OF CANADA, INC. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. ALPINE ELECTRONICS FRANCE S.A.R.L. ALPINE ELECTRONICS DE ESPAÑA, S.A. Sankei Kikaku Co., Ltd. 1-13-38, Hinodai, Hino, Tokyo, Japan 1-1-8 Nishi Gotanda,...
-
Page 3: Precautions
GUIDE FOR INSTALLATION AND CONNECTIONS • Please read this GUIDE FOR INSTALLATION AND CONNECTIONS and the OWNER’S MANUAL thoroughly to familiarize yourself with each control and function. We at ALPINE hope that your new DVI-9990 will give you many years of listening enjoyment. - Page 4 Precautions • Be sure to disconnect the cable from the (–) battery post before installing your DVI-9990. This will reduce any chance of damage to the unit in case of a short-circuit. • Be sure to connect the color coded leads according to the diagram. Incorrect connections may cause the unit to malfunction or damage to the vehicle’s electrical system.
-
Page 5: Table Of Contents
• If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors. Contact them for further information. • Your Alpine dealer knows best about noise prevention measures so consult your dealer for further information. -
Page 6: Accessories
Accessories Power cable RCA Extension S video cable Flat screw Front frame cable (video) (M5 x 6) Parts for remote control Remote control Battery (AAA) Reinforcement screw Remote control holder (M3 x 12) Double-sided adhesive tape... -
Page 7: Installation
Connect each input lead coming from the product you are connecting with to the correspond- ing output lead coming from the left rear of the DVI-9990. Connect all other leads of the DVI- 9990 according to details described in the “Connections” section. - Page 8 Slide the DVI-9990 into the dashboard. When the unit is in place, make sure the locking pins are fully seated in the down position. This can be done by pressing firmly in on the unit while pushing the locking pin down with a small screwdriver. This ensures that the unit is properly locked and will not accidentally come out from the dashboard.
- Page 9 Mounting the remote control holder • If the remote control is in direct sunlight, remove it from the holder and keep it in the glove box. • When the holder cannot be mounted securely with Velcro tape, mount it by using screws. Protective paper Reinforcement Screws Remote Control...
-
Page 10: Connections
Connect this lead to the +B terminal of your power antenna, if applicable. • Illumination Lead This lead may be connected to the vehicle’s instrument cluster illumination lead. This will allow the backlighting of the DVI-9990 to dim whenever the vehicle’s lights are turned on. • Ground Lead Connect this lead to a good chassis ground on the vehicle. -
Page 11: Connections With Other Equipments
IONBUS terminal IONBUS compatible monitor box Antenna Receptacle Blue Orange <DVI-9990> Black Yellow Power supply unit Fuse (7.5A) NOTES • Do not install the power supply unit where it will be exposed to moisture such as under the floor mat or near the air conditioner. - Page 12 • System Connection <Example 2> Connectable system products Multimedia Manager or DAC unit External TV monitor Video output connector DVD Audio Link cable (Included with the PXI-H990 or DAI-C990) IONBUS cable (Included with the PXI-H990 or DAI-C990) Antenna Receptacle Blue Orange Black Yellow...
