- Page 1 PARTS REFERENCE LIST MODEL: P-touch BB4 REVISED...
- Page 2 NOTES FOR USING THIS PARTS REFERENCE LIST 1. In the case of ordering parts, it needs mentioning the following items: (1) Code (2) Q'ty (3) Description (4) Symbol (PCB No., Revision , and Parts location mounted on the PCB.) Note : No orders without Parts Code or Tool No. can be accepted. [ Example ] REF.
-
Page 3: Table Of Contents
CONTENTS 1 . PRINT MECHANISM ................1 2 . COVERS ....................3 3 . MAIN PCB ....................5 4 . RUBBER KEY...................7 5 . ATTACHMENTS..................7 6 . PRINTED MATTER ..................9 7 . PACKING MATERIALS................11... -
Page 4: Print Mechanism
1 . PRINT MECHANISM MODEL 8V2-U31-045... - Page 5 1 . PRINT MECHANISM REF.NO. CODE Q'TY DESCRIPTION REMARKS LA5531001 1 CHASSIS ASSY LA0123001 1 DC MOTOR ASSY NAPLES UN3640001 2 SCREW, PAN 1.7X2.5 LA5580001 1 CUTTER LEVER BB4, BLUE6357 LA3061001 1 HEAD ASSY KF2400-21 UB3941001 1 CUP SCREW, M2.6X4 LA3066001 1 ROLLER HOLDER ASSY LA3072001...
-
Page 6: Covers
2 . COVERS MODEL 8V2-U31-061... - Page 7 2 . COVERS REF.NO. CODE Q'TY DESCRIPTION REMARKS LA5533001 1 BODY COVER BB4, WHITE1598 LA5534001 1 LCD PANEL BB4 (USA/CAN/WALMART) LA5576001 1 LCD PANEL BB4 EC (DEU/GBR/FRA/IRL/NLD/CHE/DNK/SWE/ITA/BEL/NOR/ESP/ZAF) LA7449001 10 TAPTITE, BIND B M2.6X4 LA5535001 1 BOTTOM COVER BB4, WHITE1598 LA5536001 2 BATTERY TERMINAL P1 LA5537001 3 BATTERY TERMINAL P2...
-
Page 8: Main Pcb
3 . MAIN PCB Netherlands (Holland) 08 Spain 07 Italy Belgium 04 Switzerland 02 England/Ireland Spec. 03 France Destination Germany Solder Points Spec. Destination Solder Points 12 Sweden 11 Norway 10 U.S.A./Canada 09 Denmark Spec. Destination Spec. Solder Points Destination Solder Points H: Solder point opened L: Solder point closed... - Page 9 3 . MAIN PCB REF.NO. SYMBOL CODE Q'TY DESCRIPTION REMARKS B55L111-210C LA5546001 1 MAIN PCB ASSY BB4 US (USA/CAN/WALMART) B55L111-201 LA6541004 1 MAIN PCB ASSY BB4 EC (DEU) B55L111-202 LA6529003 1 MAIN PCB ASSY BB4 EC (GBR/IRL/ZAF) B55L111-203 LA6541005 1 MAIN PCB ASSY BB4 EC (FRA) B55L111-206 LA6541001 1 MAIN PCB ASSY BB4 EC (NLD)
-
Page 10: Rubber Key
4 . RUBBER KEY MODEL 8V2-U31-003 5 . ATTACHMENTS MODEL 8V2-U31-910... - Page 11 4 . RUBBER KEY REF.NO. CODE Q'TY DESCRIPTION REMARKS LA5530001 1 RUBBER 4 KEY BB4 MODEL 8V2-U31-003 5 . ATTACHMENTS REF.NO. SYMBOL CODE Q'TY DESCRIPTION REMARKS LA5558001 1 HOLDER BB4, BLUE6357 LA5560001 1 STAND BB4, WHITE1598 LA5561001 3 STOPPER BB4 LA6130001 1 FLAT HEAD WOOD SCREW SET 2P LA6131001...
-
Page 12: Printed Matter
6 . PRINTED MATTER MODEL 8V2-U31-920... - Page 13 6 . PRINTED MATTER PT2002017 REF.NO. SYMBOL CODE Q'TY DESCRIPTION REMARKS LA6022001 1 USER'S MANUAL BB4, USA.ENG (USA) LA6023001 1 USER'S MANUAL BB4, USA.SPA (USA) LA6046001 1 USER'S MANUAL BB4, GERMAN (DEU) LA6024001 1 USER'S MANUAL BB4, CA.ENG (CAN/WALMART) LA6025001 1 USER'S MANUAL BB4, CA.FR (CAN/WALMART) LA6033001 1 USER'S MANUAL BB4, UK (GBR/IRL/ZAF)
-
Page 14: Packing Materials
7 . PACKING MATERIALS MODEL 8V2-U31-930 -11-... - Page 15 7 . PACKING MATERIALS REF.NO. CODE Q'TY DESCRIPTION REMARKS LA5563000 1 UPPER PACK SHELL BB4US (USA/CAN/WALMART) LA5564000 1 LOWER PACK SHELL BB4US (USA/CAN/WALMART) LA6532000 1 UPPER PACK SHELL BB4EC (DEU/GBR/FRA/IRL/NLD/CHE/DNK/SWE/ITA/BEL /NOR/ESP/ZAF) LA6533000 1 LOWER PACK SHELL BB4EC (DEU/GBR/FRA/IRL/NLD/CHE/DNK/SWE/ITA/BEL /NOR/ESP/ZAF) LA6020001 1 COMMERCIAL SHEET BB4US (USA) LA6027001 1 COMMERCIAL SHEET BB4 WALMART (WALMART)
- Page 16 Apr., 2002 8V2017BE1...
