Brother AX400 Parts Reference List page 9

REF.NO. CODE Q'TY
UC5026001 1HEAD GUIDE SHAFT
1
UA4215000 1CARRIER RAIL BEARING B
2
3 048070345 2RETAINING RING, E7
UC4830000 1RACK
4
U22702001 1SCREW, PAN (S/P WASHER) M3X10
5
UC4902001 1PLATE NUT 3
6
UC4833000 1GUIDE RAIL
7
085361015 1TAPTITE, BIND B M3.5X10
8
9 UC4834001 1LF GEAR HOLDER SUB ASSY
UC4837000 1PAPER FEED IDLE GEAR
10
UC4838001 1SPRING, EXTENSION
11
12 060260405 1SCREW, BIND M2.6X4
REF.NO. CODE Q'TY
UC5001001 1PAPER FEED MOTOR
1
3 . CHASSIS-ATTACHMENTS
DESCRIPTION
4 . MOTOR
DESCRIPTION
-4-
REMARKS
MODEL AX410,100/GX100 51V-211-034
REMARKS
MODEL AX410,100/GX100 51V-211-054
