Brother AX400 Parts Reference List page 7

REF.NO. CODE Q'TY
1-2 UC5242001 1PAPER METER ASSY
UC4899001 1PAPER METER SUB ASSY
1
2 UC5240001 2PW CASSETTE PAD RUBBER
UC5139001 2SCREW, PAN(WASHER) M4X6DA
3
REF.NO. CODE Q'TY
UR0007001 1PLATEN 12S MVO
1
UC4823019 1PLATEN KNOB L GRAY1109
2
2 UC4823023 1PLATEN KNOB L GRAY1267(PL100,RS150)
UC4823031 1PLATEN KNOB L WHITE1397
2
3 U22702001 1SCREW, PAN (S/P WASHER) M3X10
UC4824021 1PAPER RELEASE LEVER
4
UC5318001 1PAPER PAN ASSY TF
5
6 U05656001 4PAPER HOLD ROLLER
7 UC4828000 1PAPER PAN HOLD PLATE
UC4829001 1SPRING, EXTENSION
8
1 . PAPER METER ASSEMBLY
DESCRIPTION
2 . PLATEN MECHANISM
DESCRIPTION
-2-
REMARKS
MODEL AX410,100/GX100 51V-211-016
REMARKS
MODEL AX410,100/GX100 51V-211-031
