  • Page 1 Yamagata Printing Co., Ltd. 2-6-34, Takashima, Nishi-ku, Yokohama, Kanagawa, Japan CDA-7969R MIN. MIN. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. 6-8 Fiveways Boulevarde Keysborough, Victoria 3173, Australia Tel.: (03) 9769-0000 ALPINE ELECTRONICS GmbH Kreuzerkamp 7-11 40878 Ratingen, Germany Tel.: 02102-45 50 ALPINE ITALIA S.p.A.
  • Page 2 More musical selections, more versatility, more convenience. An Alpine CD Changer adds more musical choices to your sound system. All models can be controlled from Alpine head units and deliver excellent sound quality. The CHA-S624 is a high-performance 6-disc changer with a new M DAC, Ai-NET compatibility, Optical Digital Output, 150 Disc Title Memory and CD TEXT.

  • Page 3: Table Of Contents

    Contents Operating Instructions WARNING WARNING ... 2 CAUTION ... 2 PRECAUTIONS ... 2 Basic Operation Opening the Front Panel ... 4 Hiding the Front Panel ... 4 Initial System Start-Up ... 4 Turning Power On and Off ... 4 Display Angle Adjustment ... 5 Setting the Front Panel closing mode ...

  • Page 4: Warning

    HALT USE IMMEDIATELY IF A PROBLEM APPEARS. Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or the nearest Alpine Service Centre for repairing. DO NOT MIX NEW BATTERIES WITH OLD BATTERIES.
  • Page 5 Use of special shape discs may cause damage to the mechanism. Installation Location Make sure the CDA-7969R will not be installed in a location subjected to: • Direct sun and heat • High humidity and water •...

  • Page 6: Basic Operation

    • The power will turn off after the Front panel hiding. Connectable to Remote Control Interface Box You can operate this unit from the vehicle's control unit when an Alpine Remote Control Interface Box (optional) is connected. For details, contact your Alpine dealer.

  • Page 7: Display Angle Adjustment

    Display Angle Adjustment Movable display The movable display may be adjusted to 3 different angles depending upon user preference. Press the F button, and when the FUNC indicator blinks, adjust the movable display angle by pressing button F1 (DOWN) or F2 (UP). NOTES •...

  • Page 8: Changing Backlighting Colour

    Basic Operation Audio Control INTLZ MUTE TUNE Changing Backlighting Colour Press and hold the INTLZ button for at least 2 seconds. Press the f UP button repeatedly to select "AMBER". Each press of the f UP button changes the modes as shown: NOTE If you press the DN g button the display scrolls in reverse sequence.

  • Page 9: Subwoofer On And Off

    Subwoofer On and Off Press and hold the INTLZ button for at least 2 seconds. Press the f UP button repeatedly to select "SUB." Each press of the f UP button changes the modes as shown: → FM-LE → REG → PTY31 → AMBER → DIM → SUB → BEEP D-OUT ←...

  • Page 10: Setting The Aux Mode

    Basic Operation Audio Control INTLZ/DISP TUNE DN g BLACK OUT Setting the AUX Mode You can input TV/video sound by connecting an optional Ai-NET/RCA Interface cable (KCA-121B) to this component. Press and hold the INTLZ button for at least 2 seconds.

  • Page 11: Adjusting The Built-In Audio Processor

    Adjusting the built-in Audio Processor You can change High Pass Filter, Low Pass Filter, and Sub Woofer Phase on this unit, so that you can create your favorite sound effects. Press and hold the A. PROC button for at least 3 seconds to enter Adjust Mode.

  • Page 12: Equalizer Presets

    Basic Operation Digital Time Correction DN g Equalizer Presets Six typical equalizer settings are preset at the factory for a variety of musical source material. Press the 7-Band Graphic EQ button to switch to the EQ mode. Press the Preset buttons (F1 through F6) within 10 seconds to select the desired mode.

  • Page 13: Adjusting The Time Correction

    To correct this, the CDA-7969R is able to delay the audio signal to the speakers closest to the listener. This effectively creates a perception of increased distance for those speakers.

  • Page 14: Radio Operation

    Radio Operation BAND TUNE/A.ME DN g Manual Tuning Press the SOURCE button until a radio frequency appears in the display. Press the BAND button repeatedly until the desired radio band is displayed. Each press changes the band: → FM1 → FM2 → FM3 → MW → LW Press the TUNE button repeatedly until "DX SEEK"...

  • Page 15: Manual Storing Of Station Presets

    Manual Storing of Station Presets Select the radio band and tune in a desired radio station you wish to store in the preset memory. Press and hold any one of the Preset buttons (F1 through F6) for at least 2 seconds until the station frequency on the display blinks.

  • Page 16: Rds Operation

    RDS Operation INTLZ TUNE DN g Setting RDS Reception Mode and Receiving RDS Stations The RDS (Radio Data System) is a radio information system using the 57 kHz subcarrier of regular FM broadcast. The RDS allows you to receive a variety of information such as traffic information, station names, and to automatically re-tune to a stronger transmitter that is broadcasting the same programme.

  • Page 17: Receiving Rds Regional (Local) Stations

    Receiving RDS Regional (Local) Stations Press and hold the INTLZ button for at least 2 seconds to activate the setting mode. Press the f UP button repeatedly to select "REG. (REGIONAL)" Each press of the f UP button scrolls the modes as shown: →...

  • Page 18: Receiving Traffic Information While Playing Cd Or Radio

    RDS Operation INTLZ DN g TUNE Receiving Traffic Information While Playing CD or Radio Press the F button. The FUNC indicator will illuminator. Press the F2 (T.INF) button repeatedly until the T.INFO indicator appears in the display. Press the DN g and f UP buttons to select a traffic information station if necessary.

  • Page 19: Turning Emergency Alarm On Or Off

    Press the F4 button to activate the PRIORITY PTY mode again. • To change the programme category, perform the step 3. • To disable the PRIORITY PTY function, press the F4 button. NOTE In the PRIORITY PTY function, unlike in the T.INFO function, the volume does not increase during operation.

  • Page 20: Cd Player Operation

    CD Player Operation INTLZ TUNE/-/J DN g Opening and Closing the Movable display Press the c button. The movable display will open. To close the movable display, press the c button again. The movable display will close. NOTES • Do not apply shock to the movable display when it is open as it may result in malfunction of the unit.

  • Page 21: Music Sensor (Skip)

    To eject the disc, press the c button. NOTES • Three-inch (8cm) CD's can be used. • If the CD does not eject, press c button again for at least 3 seconds with the movable display open. • Only com.pact discs containing the mark shown can be used.

  • Page 22: Displaying The Title/Text

    CD Player Operation Audio Control DN g Displaying the Title/Text It is possible to display the CD title if the title has been previously inputted. For details, see Titling Discs (see this page). Text information, such as the disc name and the track name, will be displayed if playing a CD text compatible disc.

  • Page 23: Erasing Disc Title

    See the Multi-Changer Selection section on page 22 for selecting the CD Changers. NOTES • The controls on the CDA-7969R for CD Changer operation are operative only when a CD Changer is connected. • The "Changer" indicator illuminates in the CD Changer mode.

  • Page 24: Searching For Titled Discs/Cd Text

    CD TEXT disc at least once so that it is registered in the unit’s memory. Multi-Changer Selection Alpine's Ai-NET system will support up to 6 CD Changers. When operating two or more changers, the KCA-400C (Multi-Changer Switching device) must be used.

  • Page 25: Remote Control Operation

    Remote Control Operation Controls on Remote Control 1 Mute Button Press the button to lower the volume by 20 dB instantly. Press the button again to cancel. 2 Power Switch Press the switch to turn the power on/off. 3 -/J Button Press the button to switch between the Play and Pause modes for CD.

  • Page 26: Battery Replacement

    Battery Replacement Applicable battery: Use two "AAA" sized dry batteries or equivalent. Opening the battery cover Slide out the battery cover while firmly pressing outward. Replacing the battery Put the batteries in the case observing the polarities as illustrated. Closing the cover Push the cover as illustrated until a click is heard.

  • Page 27: Information

    - Clean the disc; damaged disc should be replaced. Error displays (built-in CD player only) • Mechanical error - Press the c button. After the error indication disappears, insert the disc again. If the above- mentioned solution does not solve the problem, consult your nearest ALPINE dealer.
  • Page 28 ERROR • Malfunction in the CD Changer. - Consult your Alpine dealer. Press the magazine eject button and pull out the magazine. Check the indication. Insert the magazine again. If the magazine cannot be pulled out, consult your Alpine dealer.

  • Page 29: Specifications

    Specifications FM TUNER SECTION Tuning Range 87.5 – 108.0 MHz Mono Usable Sensitivity 0.7 µV Alternate Channel Selectivity 80 dB Signal-to-Noise Ratio 65 dB Stereo Separation 35 dB MW TUNER SECTION Tuning Range 531 – 1,602 kHz Sensitivity (IEC Standard) 25.1 µV/28 dB LW TUNER SECTION Tuning Range...

  • Page 30: Installation And Connections

    (e.g. on-board computer). Do not tap into these leads to provide power for this unit. When connecting the CDA-7969R to the fuse box, make sure the fuse for the intended circuit of the CDA-7969R has the appropriate amperage. Failure to do so may result in damage to the unit and/or the vehicle.

  • Page 31: Installation

    When your vehicle has the Bracket, mount the long hex bolt onto the rear panel of the CDA-7969R and put the Rubber Cap on the hex bolt. If your vehicle does not have the Mounting Support, reinforce the head unit with the metal mounting strap (not supplied).

  • Page 32: Connection

    Installation and Connections Connection & NORM EQ/DIV " (Pink/Black) AUDIO INTERRUPT IN (Pink/Black) AUDIO INTERRUPT IN (Blue/White) REMOTE TURN-ON (Orange) DIMMER (Red) IGNITION (Black) GND (Blue) POWER ANT (Yellow) BATTERY For details on how to set the Subwoofer to ON/OFF, see "Subwoofer On and Off" on page 7. ISO Antenna Convertor Plug To vehicle phone...
  • Page 33 • Connect the ground lead securely to a bare metal spot (remove the coating if necessary) of the car chassis. • If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various Alpine noise suppressors, contact them for further information.
