Frigidaire FEB30T6DBC Parts Catalog

Frigidaire FEB30T6DBC Parts Catalog

30" double electric wall oven
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
U p p er O ven
Low er O ven
Speed Bake O vens
Speed
Speed
Bake
Cl ear
Speed
Speed
Bake
Cl ear
Bake
Bake
bake
cl ean
ti m e
/ Off
bake
cl ean
ti m e
/ Off
Control s
Control s
U PPER O VEN
LO W ER O VEN
Keep
Cl ean
Start
Oven
START
Ti m er
Keep
Cl ean
Start
Oven
START
Broi l
w arm
ti m e
l i ght
Cl ock
Broi l
w arm
ti m e
l i ght
On/Off
FEB30T6D.eps CGLEB27T9DSC.eps BUFEB30T6DSB.eps BLFEB30T6DSB.eps
DFEB30S5DSA.eps
318046121.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FEB30T6DBC
37054381E4063 37054381E4043 37054381E4013
Series
30" double
Color
black
Market
North America
Wiring Diagram
318046121
Owner's Guide
318200924
Installation Instructions 318201514
Service Data Sheet
318047306
Timer Guide
318200137
Publication No.
5995459400
06/01/24
(EN/SERVICE/ECL)
377
FEB30T6DQC
FEB30T6DSC
30" double
30" double
bisque
white
North America
North America
318046121
318046121
318200924
318200924
318201514
318201514
318047306
318047306
318200137
318200137
DOUBLE ELECTRIC

WALL OVEN

Model No.
FEB30T6D
©
Copyright
2006 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FEB30T6DBC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FEB30T6DBC

Summary of Contents for Frigidaire FEB30T6DBC

  • Page 1: Wall Oven

    U p p er O ven Low er O ven Speed Bake O vens Speed Speed Bake Cl ear Speed Speed Bake Cl ear Bake Bake bake cl ean ti m e / Off bake cl ean ti m e / Off Control s Control s...

  • Page 2: Control Panel

    Publication No: 5995459400 FEB30T6D CONTROL PANEL 01/06...
  • Page 3 FEB30T6D Publication No: 5995459400 CONTROL PANEL Model Index: A FEB30T6D (FEB30T6DSC) B FEB30T6D (FEB30T6DBC) C FEB30T6D (FEB30T6DQC) POS. NO PART NO. DESCRIPTION 318257300 A B C Shield, oven top 318260100 A B C Cover, box 318342903 A - - Control Panel Assembly, glass, white, w/touch pad 318342905 - B - Control Panel Assembly, glass, black, w/touch pad...

  • Page 4: Upper Oven

    Publication No: 5995459400 FEB30T6D UPPER OVEN 01/06...
  • Page 5 FEB30T6D Publication No: 5995459400 UPPER OVEN Model Index: A FEB30T6D (FEB30T6DSC) B FEB30T6D (FEB30T6DBC) C FEB30T6D (FEB30T6DQC) POS. NO PART NO. DESCRIPTION 318259202 A B C Back, main 318258902 A B C Shield, insulation, upper 318262502 A B C Rack, oven 5303317977 A B C Pan, broiler...
  • Page 6 Publication No: 5995459400 FEB30T6D UPPER OVEN 01/06...
  • Page 7 FEB30T6D Publication No: 5995459400 UPPER OVEN Model Index: A FEB30T6D (FEB30T6DSC) B FEB30T6D (FEB30T6DBC) C FEB30T6D (FEB30T6DQC) POS. NO PART NO. DESCRIPTION 318317100 A B C Adapter Assembly, vent tube, w/converter 318272900 A B C Box, vent 318003000 A B C Plate, shield 318123910 A B C...

  • Page 8: Lower Oven

    Publication No: 5995459400 FEB30T6D LOWER OVEN 01/06...
  • Page 9 FEB30T6D Publication No: 5995459400 LOWER OVEN Model Index: A FEB30T6D (FEB30T6DSC) B FEB30T6D (FEB30T6DBC) C FEB30T6D (FEB30T6DQC) POS. NO PART NO. DESCRIPTION 318259202 A B C Back, main 318258902 A B C Shield, insulation, upper 318262502 A B C Rack, oven 12 # 318089917 A B C...
  • Page 10 Publication No: 5995459400 FEB30T6D LOWER OVEN 01/06...
  • Page 11 FEB30T6D Publication No: 5995459400 LOWER OVEN Model Index: A FEB30T6D (FEB30T6DSC) B FEB30T6D (FEB30T6DBC) C FEB30T6D (FEB30T6DQC) POS. NO PART NO. DESCRIPTION 318259703 A - - Trim, oven front, white, bottom 318259704 - B - Trim, oven front, black, bottom 318259705 - - C Trim, oven front, bisque, bottom...
  • Page 12 Publication No: 5995459400 FEB30T6D DOORS 01/06...
  • Page 13 FEB30T6D Publication No: 5995459400 DOORS Model Index: A FEB30T6D (FEB30T6DSC) B FEB30T6D (FEB30T6DBC) C FEB30T6D (FEB30T6DQC) POS. NO PART NO. DESCRIPTION 318260201 A B C Trim, oven door, black, upper 318260401 A B C Trim, oven door, side, (2) 318261301 A - - Glass Assy., oven door, white, outer, w/trim 318261300...

  • Page 14: Wiring Diagram

    Publication No: 5995459400 FEB30T6D WIRING DIAGRAM OUTSIDE INTSIDE COLOR CODE/CODIGOS DE COLOR/CODE OVEN CIRCUIT // CIRCUITO DE HORNO // CIRCUIT DU FOUR INTERIOR EXTERIOR DE COULEUR INTERIEUR EXTERIEUR BK-7 G.-GREEN/VERDE/VERT OR/O/OU BK-8 CONVECTION FAN/VENTILADOR DE CONVECCION/ W.-WHITE/BLANCO/BLANC (BK-8)* CONVECTION VENTILATEUR R.-RED/ROJO/ROUGE OPTION BR-5...
