Frigidaire FEB30T7F Parts Catalog

Frigidaire FEB30T7F Parts Catalog

Double electric wall oven
Hide thumbs Also See for FEB30T7F:

Advertisement

FEB30T7FC.tif CPLEB30T9FCA.eps BUFEB30T6DSD.eps BLFEB30T6DSC.eps
DFEB30S7FCB.eps
318046123.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FEB30T7FCC
37054383F60S3
Series
30" double
Color
stainless
Market
North America
Wiring Diagram
318046123
Owner's Guide
318205119
Installation Instructions 318201514
Service Data Sheet
318047309
Timer Guide
318200129
Publication No.
5995490280
07/05/07
(EN/SERVICE/BJH)
377
DOUBLE ELECTRIC

WALL OVEN

Model No.
FEB30T7F
©
Copyright
2007 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

  Also See for Frigidaire FEB30T7F

  Related Manuals for Frigidaire FEB30T7F

  Summary of Contents for Frigidaire FEB30T7F

  • Page 1: Wall Oven

    Product No. FEB30T7FCC 37054383F60S3 Series 30" double Color stainless Market North America Wiring Diagram 318046123 Owner's Guide 318205119 Installation Instructions 318201514 Service Data Sheet 318047309 Timer Guide 318200129 DOUBLE ELECTRIC FEB30T7FC.tif CPLEB30T9FCA.eps BUFEB30T6DSD.eps BLFEB30T6DSC.eps WALL OVEN DFEB30S7FCB.eps 318046123.eps Electrolux Major Appliances Model No.
  • Page 2: Control Panel

    Publication No: 5995490280 FEB30T7FCC CONTROL PANEL 05/07...
  • Page 3 FEB30T7FCC Publication No: 5995490280 CONTROL PANEL POS. NO PART NO. DESCRIPTION 318257300 Shield, oven top 318260100 Cover, box 318271533 Control Panel Assembly, steel/glass, stainless/black, w/touch pad 20 # 316443834 Control, electronic, ES610W2, dual oven 316247900 Spacer, power board, (4) 316114100 Spacer, (2) 316443912 Board, relay, dual oven...
  • Page 4: Upper Oven

    Publication No: 5995490280 FEB30T7FCC UPPER OVEN 108A BUFEB30T6DSD 05/07...
  • Page 5 FEB30T7FCC Publication No: 5995490280 UPPER OVEN POS. NO PART NO. DESCRIPTION 318259205 Back, main 318258902 Shield, insulation, upper 318262502 Rack, oven 316445501 Switch, oven light, door frame 318224000 Receptacle, oven light 318268099 Insulation, oven light 5303013071 Bulb/Lamp, light 08011086 Lens, oven light, glass 5304400195 Retainer, light cover 318147411...
  • Page 6 Publication No: 5995490280 FEB30T7FCC UPPER OVEN 108A BUFEB30T6DSD 05/07...
  • Page 7 FEB30T7FCC Publication No: 5995490280 UPPER OVEN POS. NO PART NO. DESCRIPTION 316136500 Washer, flat 318257701 Trim, oven, black, front 318249401 Tube, protector 5304440067 Cabinet Mounting Kit 318246010 Bracket, cabinet mtg, (2) 311* 5304438005 Screw, 6 x 1, black 318246702 Tool, cabinet bracket, RH 318246703 Tool, cabinet bracket, LH 318165800...
  • Page 8: Lower Oven

    Publication No: 5995490280 FEB30T7FCC LOWER OVEN 108A BLFEB30T6DSC 05/07...
  • Page 9 FEB30T7FCC Publication No: 5995490280 LOWER OVEN POS. NO PART NO. DESCRIPTION 318259205 Back, main 318258902 Shield, insulation, upper 318345207 Rack, oven 316445501 Switch, oven light, door frame 318224000 Receptacle, oven light 318268099 Insulation, oven light 5303013071 Bulb/Lamp, light 08011086 Lens, oven light, glass 5304400195 Retainer, light cover 318147411...
  • Page 10 Publication No: 5995490280 FEB30T7FCC LOWER OVEN 108A BLFEB30T6DSC 05/07...
  • Page 11 FEB30T7FCC Publication No: 5995490280 LOWER OVEN POS. NO PART NO. DESCRIPTION 318317100 Adapter Assembly, vent tube, w/converter 318123910 Deflector 318172904 Support, wire 318014111 Spacer 318014700 Spacer, oven shield, (4) 316136500 Washer, flat 318257801 Trim, oven, black, front 318249401 Tube, protector 318078543 Box &...
  • Page 12 Publication No: 5995490280 FEB30T7FCC DOORS DFEB30S7FCB 05/07...
  • Page 13 FEB30T7FCC Publication No: 5995490280 DOORS POS. NO PART NO. DESCRIPTION 318260401 Trim, oven door, side, (2) 318262101 Cover, rear door, black, (2) 318260520 Baffle, door 318372000 Insulation, door, (2) 318372002 Insulation, door, (2) 316117500 Glass, oven door, heat barrier 318259605 Liner, door 5303325980 Screw, 10-32 x 0.437...
  • Page 14: Wiring Diagram

    Publication No: 5995490280 FEB30T7FCC WIRING DIAGRAM 05/07...
