Page 3 2g 1g Mission Statement Rega’s philosophy is to make high quality products at sensible prices, as a means of reproducing music as faithfully as possible. Rega is committed to the design and development of new and existing products, both in hi-fi and other areas, that will...
Page 4
P9 manual 2.qxd 26/02/2004 10:31 Page 4 Contents Introduction........1 Design Innovation......2-3 Caring for your P9......4 Power Supply.......5-6 Setup..........7 Hints and Tips........8...
Page 5
P9 manual 2.qxd 26/02/2004 10:31 Page 5 Your Rega P9 has been designed to be effective, easy to use and above all - to reproduce music better than any other turntable. We have omitted all the usual gimmicks genuinely concentrated manufacturing costs on the high quality components and design necessary to reproduce records accurately.
Page 6
P9 manual 2.qxd 26/02/2004 10:31 Page 6 Tonearm The New P9 has an extensively redesigned tonearm, the all new RB1000. Many changes have been made to improve the original RB900 even further. The aluminium tube has been polished rather than lacquered so as to reduce the weight.
Page 7
Motor The motor is a high specification, 24V twin phase synchronous unit controlled by Rega's unique and innovative power supply. The motor drives the computer-numerically-controlled (cnc) machined pulley and sub platter/hub-bearing assembly via a twin belt drive. Two belts are used so that any small inaccuracies in one belt will be cancelled out by the second, giving unusually low levels of wow and flutter.
Page 8
P9 manual 2.qxd 26/02/2004 10:31 Page 8 Interconnects We have used the highest quality XLR and phono connectors and low noise, wide bandwidth interconnect cable. These are genuine professional products and are the best available for the job. Do not attempt to fit any other wires or cables.
Page 9
P9 manual 2.qxd 26/02/2004 10:31 Page 9 Transporting your P9 Should you need to transport your P9, to avoid any possible transit damage, the following recommendations must be followed. 1. Remove tonearm balance weight and secure the arm in its rest with tape or covered wire.
P9 manual 2.qxd 26/02/2004 10:31 Page 10 Power Supply When the power supply is first switched on, the power L.E.D. in the power switch will flash. 33 rpm is selected by pressing the 33 rpm button. Once pressed 33 rpm is selected and the L.E.D will flash until the turntable has settled.
Page 11
P9 manual 2.qxd 26/02/2004 10:31 Page 11 down to feed generously rated, high current power fet amps. The output from these is very pure (<0.03 THD, this is a lower value than many power amplifiers output). The beauty of this power supply is that a...
2g 1g extended, bias tracking force dial i.e. 1.75g tracking adjustment is at 0g. Push force for Rega cartridges = 1.75g on in to the first mark for 1g and to the second for 2g. the bias shaft (see left).
Page 13
Should you experience playing or any cleaners that use any problem with your water or solvents. If you keep 6) Rega turntables are designed turntable wish your records stored in their to optimise performance for enquire about servicing...
