Connection
Connection to your PC (NEC, IBM and compatibles)
The MultiSync XP-series colour monitor complements NEC or IBM
PC/XT, AT, 386, 486, PS/2 computer and compatibles.
Your System has one of two configurations:
1. The video controller is built into the computer.
2. The video controller is in the form of a video card (sometimes
referred to as a graphic card, video adapter, or graphics board.)
Both configurations have a video connector (or a CRT PORT on NEC
laptop computers). If you are not sure as to which connector is the video
connector, consult your computer or video card manual. To attach the
monitor to your system, follow the instructions below.
1. Turn off the power to the monitor and computer.
2. If necessary, install the video card. For more information,
refer to the manual accompanying the card.
3. Make sure the BNC/D-SUB Switch on the front of the monitor is
set to the D-SUB down (pushed in) position.
4. Connect the 15-pin mini D-SUB (the smaller connector) end
of the MultiCable to the video connector of your system.
5. Connect the 15-pin D-SUB (the larger connector) end of the
MultiCable to the monitor.
6. Connect one end of the power cable to the MultiSync
XP-series monitor and the other end to the power outlet.
7. Turn on the monitor and computer.
8. This completes the installation
If you have any problems, please refer to the section "Trouble Shooting".
