MAZDA 323/PROTEGE 1995-98
LIFTGATE Cont'd
GLASS & PARTS Cont'd
¶Included w/Glass Bracket Assy
10 Dam, Lower Glass N.A.
11 Blade Assy, Wiper N.A.
12 Insert, Blade¶ N.A.
¶Included w/Wiper Blade Assy
13 Arm, Wiper N.A.
14 Cover, Wiper Arm N.A.
15 Nut, Upper N.A.
16 Cap, Seal N.A.
17 Nut, Lower N.A.
18 Bushing, Outer N.A.
19 Motor, Wiper N.A.
20 Tank Assy, Washer N.A.
21 Tank, Washer¶ N.A.
22 Cap, Tank¶ N.A.
23 Pump, Washer¶ N.A.
¶Included w/Washer Tank Assy
24 Valve, Washer Tank N.A.
25 Joint, Hose N.A.
26 Protector, Pipe N.A.
27 Nozzle, Spray N.A.

REAR SUSPENSION

1 Rotor, Brake 95-96 R/L BB4C-26-251C
97-98 R/L BB4C-26-251C
2 Drum, Brake 95 R/L D102-26-251
96-98 R/L B596-26-251D
3 Bearing & Hub Assy
w/ABS R/L B603-26-15XC
w/o ABS R/L B455-26-15XA
4 Bolt, Hub¶ (4/Side) 95 R/L B01Y-33-062
96-98 R/L B455-33-062
5 Rotor, ABS Sensor¶ R/L B603-26-471A
¶Included w/Bearing & Hub Assy
Sensor, ABS-See ABS/Brakes Section
6 Caliper, Brake¶ 95-96 R BCYF-26-98ZR
L BCYF-26-99ZR
97-98 R BCYF-26-98ZR
L BCYF-26-99ZR
¶"R" Suffix Indicates Remanufactured Part. Contact Dealer for Core
Charge & Exchange Information
7 Pad Set, Brake BCYF-26-43ZB
8 Shoe Set, Brake BCYD-26-38ZA
9 Hose, Brake
1.5L Eng R/L BC1D-43-810
1.8L Eng R/L BC1F-43-980
10 Plate, Backing
318
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax 1-888-256-7969 or 858-549-0629.
Page 318—April 22, 2004—15:28:49—Version
Drum Brakes
w/ABS
w/o ABS
11 Shield, Splash
Disc Brakes
12 Spindle, Hub
Drum Brakes
w/ABS
w/o ABS
Disc Brakes
w/ABS
w/o ABS
13 Strut
1.5L Eng
1995
w/ABS
w/o ABS
1996
1997-98
1.8L Eng
1995
w/ABS
w/o ABS
1996
1997-98
14 Bolt, Strut (2/Side)
15 Spring, Coil¶
1.5L Eng
1.8L Eng
¶Order by Application
16 Seat, Rubber
17 Stopper, Bumper
18 Boot, Dust
19 Seat, Spring
20 Insulator Assy, Mounting
21 Seat, Rubber¶
¶Included w/Mounting Insulator Assy
22 Bushing
23 Stopper, Damper
24 Plate, Adjust
25 Cap, Mount
26 Link, Lateral
Front
Rear
27 Bolt, Adjust
28 Bolt, Lateral Link
29 Plate, Cam
30 Washer, Spindle
31 Link, Trailing
1.5L Eng
1.8L Eng
32 Bolt, Lateral Link Frt
33 Bolt, Lateral Link Rear
Labor Times Shown are for Replacement with New OEM Undamaged Parts on New Undamaged Vehicles.
R BC1M-26-280B
L BC1M-26-290B
R BC1D-26-280A
L BC1D-26-290A
R/L B613-26-261A
R BC1E-26-111C
L BC1E-26-115C
R B455-26-111D
L B455-26-115D
R B603-26-111B
L B603-26-115B
R B461-26-111B
L B461-26-115B
R BC1D-28-700C
L BC1D-28-900C
R BC1E-28-700C-9U
L BC1E-28-900C-9U
R BC1E-28-700C-9U
L BC1E-28-900C-9U
R BC1H-28-700B
L BC1H-28-900B
R BC1F-28-700B
L BC1F-28-900B
R BC1G-28-700B
L BC1G-28-900B
R BC1G-28-700B
L BC1G-28-900B
R/L BC1G-28-900D
R/L 9YA0-21-231C
R/L BC1C-28-011
R/L BC1E-28-011
R/L B455-28-0A3
95 R/L B01C-28-111A
96-98 R/L B25D-28-111
R/L B01C-28-0A5A
R/L B01C-28-340A
R BC1D-28-380B
L BC1D-28-390B
R/L B01C-28-012
R/L BC1D-28-343A
95 R/L BC1D-28-019D
96-98 R/L B455-28-019
95-96 R/L BC1D-28-0A1A
97-98 R/L B21H-28-0A1
95-96 R/L BC1D-28-01YD
97-98 R/L B455-28-019
R/L B02A-28-620A
R/L BC1D-28-600B
95-96 R/L BC1D-28-664
97-98 R/L BC1F-28-66Z
R/L GA2A-28-113A
95-96 R/L BCY9-28-6AZ
97-98 R/L BC1F-28-473A
R/L 0193-34-662A
95-96 R BC1D-28-200
L BC1D-28-250
97-98 R/L BC5A-28-200A
95-96 R BC1F-28-200
L BC1F-28-250
97-98 R/L BC5B-28-200A
R/L B455-28-114A
1995 R/L 9YA0-21-207
1996-98 R/L B455-28-116
34 Bar, Stabilizer
1.8L Eng BC1D-28-151
35 Link, Stabilizer R/L BC1D-28-170A
36 Bushing, Stabilizer R/L G564-28-156A
37 Bracket, Stabilizer R/L GA2A-28-155A
38 Crossmember, Susp BC1D-28-800B
39 Cover, Crossmember (2) GA2A-28-831A
40 Bolt, Crossmember Outer
(2/Side) R/L GA2A-28-89X
41 Bolt, Crossmember Inner R/L 9YA0-21-009

FUEL TANK

1 Cap Assy, Filler
To 3-97 UE54-42-250
From 3-97 to 5-97 BJ0E-42-250B
From 5-97 BE5M-42-250
2 Gasket, Cap¶ BF67-42-252
¶Included w/Filler Cap Assy
3 Cover Assy, Dust
To 5-97 B01W-42-240A
From 5-97 BE5M-42-240
4 Gasket, Dust Cover Upr¶ BC1D-42-244
5 Cover, Lever¶ B455-42-242A
6 Gasket, Dust Cover Lwr¶ B01W-42-243
¶Included w/Dust Cover Assy
7 Pipe Assy, Filler
1995
w/Calif Emission BC1M-42-210C
w/o Calif Emission BC5A-42-210C
1996-98 BC4C-42-210B
8 Gasket, Filler Pipe¶ B455-42-366
¶Included w/Filler Pipe Assy
9 Protector, Filler Pipe BC1M-42-298B
10 Hose, Joint
Hatchback N.A.
Sedan
1995
w/Calif Emission BC1M-42-231
w/o Calif Emission B01A-42-231
1996 BC1M-42-231
1997-98 BG1N-42-231B
11 Hose, Filler BC1M-42-11X
12 Hose, Breather BC1M-42-232
13 Valve, Check
1995
w/Calif Emission BC1M-42-950
w/o Calif Emission B01A-42-910
1996-98 BC4C-42-950A
14 Bracket, Check Valve
1995-96
w/Calif Emission-Serviced w/Check Valve
