B. Configuring Sound Effect:
You may configure an audio environment on the Sound Effects tab.
C. Activating an AC'97 Front Panel Audio Module:
If your chassis provides an AC'97 front panel audio
module, to activate the AC'97 functionality, click the
tool icon on the Speaker Configuration tab. On the
Connector Settings dialog box, select the Disable
front panel jack detection check box. Click OK to
complete.
D. Muting the Back Panel Audio (For HD Audio Only):
Click Device advanced settings on the top right cor-
ner on the Speaker Configuration tab to open the
Device advanced settings dialog box. Select the Mute
the rear output device, when a front headphone
plugged in check box. Click OK to complete.
- 77 - Appendix
