Your miter saw has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
10 in. Compound Miter Saw
TS1343L - Double Insulated
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ryobi TS1343L
Summary of Contents for Ryobi TS1343L
- Page 1 OPERATOR’S MANUAL 10 in. Compound Miter Saw TS1343L - Double Insulated Your miter saw has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
-
Page 2: Table Of Contents
The replacement power tool will be covered by the limited warranty for the balance of the two year period from the date of the original purchase. WHAT THIS WARRANTY COVERS: This warranty covers all defects in workmanship or materials in your RYOBI power ®... -
Page 3: General Safety Rules
GENERAL SAFETY RULES SECURE WORK. Use clamps or a vise to hold work WARNING: when practical, it is safer than using your hand and frees both hands to operate the tool. Read and understand all instructions. Failure to follow ... -
Page 4: Specific Safety Rules
GENERAL SAFETY RULES INSPECT TOOL CORDS PERIODICALLY. If incorrect size holes. Never use blade washers or blade damaged, have repaired by a qualified service technician at bolts that are defective or incorrect. The maximum blade an authorized service facility. Repair or replace a damaged capacity of your saw is 10 in. -
Page 5: Specific Safety Rules
SPECIFIC SAFETY RULES NEVER reach behind, under, or within three inches of the MAKE SURE THE WORK AREA HAS AMPLE LIGHTING blade and its cutting path with hands and fingers for any to see the work and that no obstructions will interfere with reason. -
Page 6: Symbols
SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING Indicates an imminently hazardous situation, which, if not avoided, will result DANGER: in death or serious injury. Indicates a potentially hazardous situation, which, if not avoided, could result WARNING: in death or serious injury. -
Page 7: Electrical
ELECTRICAL DOUBLE INSULATION EXTENSION CORDS Double insulation is a concept in safety in electric power When using a power tool at a considerable distance from tools, which eliminates the need for the usual three- a power source, be sure to use an extension cord that has wire grounded power cord. -
Page 8: Glossary Of Terms
GLOSSARY OF TERMS Anti-Kickback Pawls (radial arm and table saws) Push Blocks (for jointer planers) A device which, when properly installed and maintained, Device used to feed the workpiece over the jointer planer is designed to stop the workpiece from being kicked back cutterhead during any operation. -
Page 9: Features
FEATURES PRODUCT SPECIFICATIONS Blade Arbor ............. 5/8 in. Cutting Capacity with Miter at 0°/Bevel 0°: Maximum nominal lumber sizes: ....2 x 6, 4 x 4 Blade Diameter ............10 in. Cutting Capacity with Miter at 45°/Bevel 0°: No Load Speed ........5,500 r/min. (RPM) Maximum nominal lumber sizes: ......2 x 4 Input ........... - Page 10 FEATURES KNOW YOUR COMPOUND MITER SAW See Figure 1. The safe use of this product requires an understanding of the information on the tool and in this operator’s manual as well as a knowledge of the project you are attempting. Before use of this product, familiarize yourself with all operating features and safety rules.
-
Page 11: Tools Needed
FEATURES MITER LOCK HANDLE SPINDLE LOCK BUTTON See Figure 2. See Figure 3. The miter lock handle securely locks the saw at desired The spindle lock button locks the spindle stopping the blade miter angles. from rotating. Depress and hold the lock button while install- ing, changing, or removing blade. -
Page 12: Loose Parts
LOOSE PARTS The following items are included with the tool: Miter Lock Handle Blade Wrench Dust Bag AAA Batteries Work Clamp Operator’s Manual BATTERIES DUST BAG BLADE WRENCH WORK MITER LOCK HANDLE CLAMP Fig. 6 WARNING: The use of attachments or accessories not listed might be hazardous and could cause serious personal injury. -
Page 13: Assembly
ASSEMBLY UNPACKING WARNING: This product requires assembly. Do not connect to power supply until assembly is Carefully lift saw from the carton by the carrying handle and complete. Failure to comply could result in accidental start- the saw base, and place it on a level work surface. ing and possible serious personal injury. - Page 14 ASSEMBLY MITER LOCK HANDLE See Figure 8. To install the miter lock handle, place the threaded stud on the end of the miter lock handle into the threaded hole in TIGHTEN the control arm. Turn clockwise to tighten. DUST BAG See Figure 9.
- Page 15 ASSEMBLY INSTALLING BATTERIES IN LASER BATTERIES COMPARTMENT See Figure 11. COVER Remove screw from battery compartment cover using the Phillips end of the supplied blade wrench. Remove cover and set aside. Install two AAA batteries according to polarity indicators inside the battery compartment.
- Page 16 ASSEMBLY TO INSTALL / REPLACE THE BLADE See Figures 13 - 14. SPINDLE LOCK BUTTON WARNING: A 10 in. blade is the maximum blade capacity of the saw. Never use a blade that is too thick to allow laser guide washer to engage with the flats on the spindle.
- Page 17 ASSEMBLY MITER WARNING: FRAMING MITER FENCE SQUARE TABLE Make sure the spindle lock button is not engaged before reconnecting saw into power source. Never engage spindle lock button when blade is rotating. NOTE: Many of the illustrations in this manual show only portions of the compound miter saw.
- Page 18 ASSEMBLY SOCKET HEAD SCREW(S) MITER BLADE FENCE FRAMING FENCE SQUARE MITER MITER TABLE LOCK HANDLE VIEW OF BLADE SQUARE WITH FENCE Fig. 19 Fig. 18 SQUARING THE SAW BLADE TO THE FENCE See Figures 18 - 22 Unplug the saw. MITER ...
- Page 19 ASSEMBLY BLADE MITER SCALE INDICATOR SCREW SCALE BEVEL INDICATOR SCALE MITER COMBINATION Fig. 22 TABLE SQUARE MITER LOCK HANDLE SQUARING THE BLADE TO THE MITER TABLE See Figures 22 - 25. BEVEL Unplug the saw. LOCK Pull the saw arm all the way down and engage the lock KNOB pin to hold the saw arm in transport position.
-
Page 20: Operation
Ryobi dealer. Press the miter lock plate down with thumb and hold. WARNING:... - Page 21 OPERATION Rotate the control arm until the pointer aligns with the Loosen the bevel lock knob and move the saw arm to desired angle on the miter scale. the left to the desired bevel angle. Release the miter lock plate. ...
- Page 22 OPERATION Grasp the stock firmly with one hand and secure it against COMPOUND MITER CUT the fence. Use the optional work clamp or a C-clamp to secure the workpiece when possible. See Figure 26. Before turning on the saw, perform a dry run of the cutting operation just to make sure that no problems will occur when the cut is made.
- Page 23 OPERATION Grasp the stock firmly with one hand and secure it against the fence. Use the optional work clamp or a C-clamp to secure the workpiece when possible. Before turning on the saw, perform a dry run of the cutting operation just to make sure that no problems will occur when the cut is made.
- Page 24 OPERATION CUTTING COMPOUND MITERS To aid in making the correct settings, the compound angle setting chart below has been provided. Since compound cuts are the most difficult to accurately obtain, trial cuts should be made in scrap material, and much thought and planning made, prior to making the required cut.
-
Page 25: Cutting Crown Molding
OPERATION CUTTING CROWN MOLDING When setting the bevel and miter angles for compound miters, remember that the settings are interdependent; changing The compound miter saw does an excellent job of cutting one angle changes the other angle as well. crown molding. In general, compound miter saws do a bet- Keep in mind that the angles for crown moldings are very ter job of cutting crown molding than any other tool made. -
Page 26: Operation
OPERATION Bevel Angle Type of Cut Setting Left side, inside corner 1. Top edge of molding against fence 33.85 ° 2. Miter table set right 31.62 ° 3. Save left end of cut Right side, inside corner 1. Bottom edge of molding against fence 33.85 °... -
Page 27: Adjustments
The saw arm should rise completely to the up position by itself. If the saw arm does not raise by itself or if there is play in the pivot joints, have saw repaired at your nearest RYOBI AUTHORIZED SERVICE CENTER. POSITIVE STOP... -
Page 28: Adjustments
ADJUSTMENTS DANGER: Laser radiation. Avoid direct eye contact with light source. WARNING: LASER Use of controls or adjustments or performance of pro- ADJUSTMENT cedures other than those specified herein may result in SCREW hazardous radiation exposure. TO ADJUST THE LASER GUIDE See Figure 37. -
Page 29: Maintenance
MAINTENANCE WARNING: BRUSH When servicing, use only identical Ryobi replacement parts. Use of any other parts may create a hazard or cause product damage. BRUSH ASSEMBLY WARNING: Always wear eye protection with side shields marked to comply with ANSI Z87.1 during product operation. If BRUSH operation is dusty, also wear a dust mask. - Page 30 When ordering repair parts, always give the following information: TS1343L • MODEL NUMBER • SERIAL NUMBER Ryobi is a registered trademark of Ryobi Limited used under license. ® ® ONE WORLD TECHNOLOGIES, INC. 1428 Pearman Dairy Road, Anderson, SC 29625 Phone 1-800-525-2579 www.ryobitools.com...
Need help?
Do you have a question about the TS1343L and is the answer not in the manual?
Questions and answers
How do you undo the bolt? To remove the blade.
To undo the bolt and remove the blade on a Ryobi TS1343L:
1. Unplug the saw.
2. Raise the saw arm.
3. Rotate the lower blade guard up and remove the blade bolt cover screw.
4. Rotate the blade bolt cover up and back to expose the blade bolt.
5. Depress the spindle lock button and rotate the blade bolt until the spindle locks.
6. Using the provided wrench, loosen and remove the blade bolt.
Note: The blade bolt has left-hand threads, so turn it clockwise to loosen.
This answer is automatically generated
What is the maximum width of lumber that can be cut?
The maximum width of lumber that can be cut with the Ryobi TS1343L depends on the miter and bevel settings:
- Miter 0° / Bevel 0°: 2 x 6 (nominal size)
- Miter 45° / Bevel 0°: 2 x 4 (nominal size)
- Miter 0° / Bevel 45°: 2 x 6 (nominal size)
- Miter 45° / Bevel 45°: 2 x 4 (nominal size)
The widest lumber that can be cut is 2 x 6 nominal size when using either a 0° miter or a 45° bevel.
This answer is automatically generated
What is the replacement part # for the Royobi TS1343 brushes?
The replacement part number for Ryobi TS1343L brushes is 976683001.
This answer is automatically generated
