Specifications - Behringer B-CONTROL FADER BCF2000 User Manual

22
B-CONTROL FADER BCF2000/ROTARY BCR2000 User Manual

6. Specifications

USB Interface
Type Full-speed 12 MBit/sec. USB MIDI
class-compliant
MIDI Interface
Type 5-pin DIN connectors IN, OUT A, OUT B / THRU
Control Elements
BCF2000
Controls 8 motorized 100-mm faders
8 infinitely variable push encoders with
LED rings
Keys 20 keys 10 system keys (4x Encoder Group,
4x programming, 2x Preset)
BCR2000
Controls 4 infinitely variable encoders with LED rings
8 infinitely variable push encoders with
LED rings
Keys 20 keys 10 system keys (4x Encoder Group,
4x programming, 2x Preset)
Display
Type 4-digit 7-segment LED display
Switched Inputs
BCF2000
Footswitch 1 x 1/4" TS connector with automatic
polarity detection
Foot pedal 1 x 1/4" TRS connector
BCR2000
Footswitch
Input 1 1/4" TRS stereo connector for dual-footswitch
Input 2 1/4" TS connector both with automatic
polarity detection
Power Supply
Voltage 100 to 240 V~, 50/60 Hz
Power Consumption max. 10 W
Fuse T 1 A H 250 V
Mains Connection Standard IEC receptacle
Dimensions / Weight
BCF2000
Dimensions (H x W x D) approx. 13 x 4 x 11 4/5" / 330 x 100 x 300 mm
Weight approx. 5.9 lbs / 2.7 kg
BCR2000
Dimensions (H x W x D) approx. 13 x 4 x 11 4/5" / 330 x 100 x 300 mm
Weight approx. 5.1 lbs / 2.3 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts,
modifications may be made from time to time to existing products without prior notice. Specifications and
appearance may differ from those listed or illustrated.
