4.3.2 Programming in EDIT mode
Various types of MIDI commands (Pitchbend, After Touch, MMC etc.) are assigned
to the individual control elements in EDIT mode.
• To activate the EDIT mode, press and hold the EDIT button and operate
a control element. This can be a fader, sustain pedal (BCF2000 only),
an encoder (BCR2000 only), a push encoder, a button or footswitch.
The control element is indicated in the display (e.g. E 24 or Fd 8)
◊
When using push encoders, select an encoder group beforehand.
In addition, you have to differentiate between turn and push function.
• Release EDIT; you are now in the EDIT mode
• Using the push encoders, you can now assign MIDI commands to the selected
control element. You will find all possible MIDI function in tables 4.1 and 4.2,
including all accompanying explanations
CONTINUOUS TYPE CONTROLLERS (encoders, turn function of Push Encoders, faders, foot controller)
1 2
MIDI Data Type MIDI Send Channel
PROGRAM CHANGE 1-16
CC
1-16
(Control Change)
NRPN
(Non Registered 1-16
Parameter Number)
PITCH BEND 1-16
AFTER TOUCH 1-16
GS/XG 1-16
1*) Controller option:
a) Push Encoders LED behaviour: Off, 1d (1 LED on), 1d- (1 LED on, but value 0 = LED off), 2d, 2d-, Bar, Bar-, Spread, Pan, Qual(ity 'Q'), Cut(off), Damp(ing)
b) Faders: Move, Pick-Up, Motor (only BCF2000)
c) Foot controller: Move, Pick-Up (only BCF2000)
Tab. 4.1: Assignment of the push encoders in EDIT mode (CONTINUOUS types)
PUSH ENCODER
3 4
Parameter Value 1
Off, Bank Select MSB Off, Bank Select LSB
Min. value:
CC-0-127
0-127/16383
NRPN Parameter Min. value:
Number 0-127/16383
— Range 0-127
Key number
0-127, ALL Min. value:
(All = Channel 0-127
Aftertouch)
Select GS/XG-Main
Control-parameter Min. value:
with clear text 0-127"
indication
• If you want to assign MIDI data to additional control elements, just press
and hold the EDIT button and move one of the control elements. Now, let go
of both controls and use the push encoders to assign a function to it
(see tables 4.1 and 4.2)
To leave the EDIT mode, press EXIT
•
◊ Initially, all settings made here are stored temporarily! If you intend to
store them in a preset, please see chapter 4.2.2.
The detailed EDIT functions are described in the following two tables.
With the assignable control elements, we differentiate between CONTINUOUS
and SWITCH types.
• CONTINUOUS-type control elements (table 4.1) include the eight BCF2000
faders and sustain pedal, the 24 encoders of the BCR2000, the turn function
of the push encoders
SWITCH-type control elements (table 4.2) are buttons, press functions for
•
push encoders and footswitches
5 6
Value 2 Controller MODE
— —
Absolute
Absolute (14-Bit)
Relative 1
Max. value: Relative 2
0-127/16383 Relative 3
Relative 1 (14-Bit)
Relative 2 (14-Bit)
Relative 3 (14-Bit)
Absolute
Absolute (14-Bit)
Relative 1
Relative 2
Max. value:
Relative 3
0-127/16383
Relative 1 (14-Bit)
Relative 2 (14-Bit)
Relative 3 (14-Bit)
Inc/Dec
— —
Max. value:
—
0-127
Max. value:
—
0-127"
7 8
Controller Option Display Value
Value indication:
See below 1*
On/Off
Value indication:
See below 1*
On/Off
Value indication:
See below 1*
On/Off
Value indication:
See below 1*
On/Off
Value indication:
See below 1*
On/Off
Value indication:
See below 1*
On/Off
