- Page 1 Gas built-in oven INSTRUCTION BOOKLET Please read this instruction booklet before using the appliance Models ESOGBR - ESOGWH - ESOGSS 35688-2801...
-
Page 3: Environmental Information
You MUST read these warnings carefully before installing or using the oven. If you need assistance, contact our Customer Care Department on 08705 950950 Installation • This appliance must be installed and serviced by a competent person as stated in the Gas Safety (Installation and Use) Regulations Current Editions and the IEE Wiring Regulations. -
Page 4: Table Of Contents
This appliance complies with the following E.E.C. Directives: * 90/396 (Gas Directive) * 73/23 - 90/683 (Low Voltage Directive); * 93/68 (General Directives); * 89/336 (Electromagnetical Compatibility Directive) . and subsequent modifications MANUFACTURER: ELECTROLUX HOME PRODUCTS ITALY S.p.A. Viale Bologna 298 47100 FORLI’ (Italia) -
Page 5: Oven Accessories
The minute minder will not affect in any way the oven operation, if it is in use. Mains on Light The mains on light will come on when the Gas Oven and Gas Grill Control Knob is set. 1. Control panel 2. -
Page 6: Condensation And Steam
The cooling fan may run on after the oven is switched off to keep the controls cool. This is quite normal. Before the First Use Remove all packaging, both inside and outside the oven, before using the appliance. -
Page 7: The Effects Of Dishes On Cooking Results
To ignite the oven gas burner: 1. Press the Gas Oven control knob, turn it to 240 and wait for the flame to come on. This may take 10-15 seconds. Do not release the knob until the burner ignites. -
Page 8: Using The Gas Grill
1. Release the Gas Oven control knob and turn it to the “Off position” 2. Open the oven door and wait for at least one minute before trying to light the gas grill burner again. If the gas grill burner accidentally goes out, turn the Gas Oven control knob to the “Off”... -
Page 9: Cleaning Materials
Models in stainless steel or aluminium We recommend to clean the oven door using only a wet sponge and dry it up after cleaning with a soft cloth. Never use steel wool, acids or abrasive products as they can damage the oven surface. -
Page 10: Replacing The Oven Light
Steam and condensation settle on the food and the oven cavity. If after all these checks, your hob still does not operate correctly, contact your local Electrolux Service Force Centre. Please note that it will be necessary to provide proof of purchase for any in-guarantee service calls. -
Page 11: Customer Care Department
5. The purchase date For general enquiries concerning your Electrolux appliance or for further information on Electrolux products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.electrolux.co.uk... -
Page 12: European Guarantee
Guarantee Conditions Electrolux Guarantee conditions We, Electrolux, undertake that if, within 12 months of the date of the purchase, this Electrolux appliance or any part thereof is proved to be defective by any reason only of faulty workmanship or materials, we will, at our... -
Page 13: Provision For Ventilation
NSAI- Domestic Gas Installation I.S 813 Current Edition Section 7- Permitted Locations of Appliance. This oven unit may be used in a Built-in or a Built-under situation (see relevant diagrams). If the appliance is to be built-under a hob, it is recommended that the hob be installed before the oven unit. -
Page 14: Securing The Oven To The Cabinet
Please ensure that when the oven is installed it is easily accessible for the engineer in the event of a breakdown. The surround or cabinet into which the oven will be built must comply with these specifications: the dimensions must be as shown in the relevant diagrams;... -
Page 15: Electrical Connection
Electrical Connection The oven is designed to be connected to 230V (50Hz) electricity supply. The oven has an easily accessible terminal block which is marked as follows: Letter L Live terminal Letter N Neutral terminal or E Earth terminal THIS OVEN MUST BE EARTHED The cable used to connect the oven to the electrical supply must comply to the specifications given below. -
Page 16: Gas Connection
To carry out the gas connection: 1. Partially insert the oven in the recess (about 30 cm) and operate on the connection ramp from above. The gas connection can be carried out... -
Page 17: Conversion From Natural To Lpg Gas
To replace the gas oven burner injector, follow this procedure: 1. Remove the bottom plate of the oven (“A”) to access the gas oven burner (“B”) 2. Undo the two fixing screws (“C”) which keep the gas oven burner in place 3. - Page 18 Replacement of Gas Type Sticker Once both the injectors for the gas oven burner and the gas grill burner have been replaced, take the Gas Type Sticker which is relevant to the new gas type and place it over the old one (it is located near the gas connection ramp).
- Page 19 9. Light the oven gas burner (see the relevant chapter), set the gas oven control knob on 240 and let the oven heat for 10 minutes at least. 10.Check that the oven gas burners does not come out when quickly turning the gas oven control knob from 240 to 150.
-
Page 20: Customer Care
The Electrolux Group. The world’s No.1 choice. The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
