INSTALLATION INSTRUCTIONS
PACKAGE AIR CONDITIONERS
© Copyright 2008

WALL MOUNTED

MODELS
W18A1
W24A1
W30A1
W36A1
W42A1
W48A1
W60A1
W70A1
Bard Manufacturing Company, Inc.
Bryan, Ohio 43506
Since 1914...Moving ahead just as planned.
W18L1
W24L1
W30L1
W36L1
W42L1
W48L1
W60L1
W70L1
Manual :
Supersedes:
File:
Date:
2100-508A
2100-508
Volume III Tab 16
02-10-09
Manual
2100-508A
Page
1 of 25
