  • Page 1 Model EDOM...
  • Page 2: Important Safety Information

    They may explode if they are heated. Ensure that all control knobs are in the OFF position when not in use. Do not stand on the appliance or on the open oven doors. Do not hang towels, dishcloths or clothes from the appliance or its handles.
  • Page 3: Table Of Contents

    The Grill Pan and Handle Hints And Tips Grilling Chart The Top Oven Using The Top Oven Things To Note To Fit The Top Oven Shelf Hints And Tips Top Oven Cooking Chart The Main Oven Using The Main Oven Things To Note...
  • Page 4: Description Of The Appliance

    DESCRIPTION OF THE APPLIANCE BUILT-IN ELECTRIC DOUBLE OVEN Electronic Timer Control Panel Top Oven/Grill Main Oven Your built-in appliance comprises of a conventional oven and dual grill in the top compartment. The main oven can be automatically controlled by the electronic timer.
  • Page 5: Getting To Know Your Appliance

    GETTING TO KNOW YOUR APPLIANCE THE CONTROL PANEL - Main Oven Temperature Control - Main Oven Indicator Neon - Top Oven /Grill Temperature Control - Electronic Timer - Top Oven/Grill Function Selector - Top Oven/Grill Selector Indicator Neon...
  • Page 6: Grill And Oven Furniture

    GRILL AND OVEN FURNITURE The following items of oven furniture have been supplied with the appliance:- 1 grill pan 1 grill pan handle 1 grill pan grid 1 shelf for grilling and top oven cooking 2 shelves for main oven cooking...
  • Page 7: Before Using The Appliance

    WHEN FIRST SWITCHING ON The oven has a 24 hour clock. When the oven is first switched on at the wall the electronic display will automatically show 12.00 and the 'Time' ( will also flash.
  • Page 8: Electronic Timer

    DECREASE CONTROL SELECTOR CONTROL G INCREASE CONTROL NOTE: The time of day must be set before the main oven will operate manually. 1. HOW TO SET THE TIME OF DAY The oven has a 24 hour clock. When the electricity supply is first switched ON, the display will show 12.00 and the 'Time' (...
  • Page 9: Setting The Oven Timer

    The oven indicator neon should be OFF. NOTE: When the automatic timed period starts, the oven indicator neon will glow. It may turn on and off during use to show that the setting is being maintained. ) flashes and then Fig.5...
  • Page 10: Automatic Cooking

    7. AUTOMATIC COOKING It is advisable to leave food in the oven for as short a time as possible before automatic cooking. Always ensure commercially prepared food is well within its use by date and that home prepared food is fresh and of good quality.
  • Page 11: The Dual Grill

    USING THE DUAL GRILL · To operate the grill turn the top oven/grill function selector to full grill. · Turn the top oven/grill function selector to centre section only.
  • Page 12: Hints And Tips

    HINTS AND TIPS · Most foods should be placed on the grid in the grill pan to allow maximum circulation of air to lift the food out of the fats and juices. · Adjust the grid and grill pan runner position to allow for different thicknesses of food.
  • Page 13: The Top Oven

    THE TOP OVEN The top oven is the smaller of the two ovens. It is heated by elements in the top and bottom of the oven. It is designed for cooking smaller quantities of food. It gives especially good results if used to cook fruit cakes, sweet or savoury flans or quiche.
  • Page 14: Hints And Tips

    · Stand dishes on a suitably sized baking tray on the shelf to prevent spillage onto the oven base and to help reduce cleaning. · The material and finish of the baking tray and dishes used will affect the degree of base browning.
  • Page 15: Top Oven Cooking Chart

    TOP OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatures by 10°C to suit individual preferences and requirements. FOOD Biscuits Bread Bread rolls/buns Cakes: Small & Queen...
  • Page 16: The Main Oven

    The advantages of fan oven cooking are: PREHEATING The fan oven quickly reaches its temperature, so it is not usually necessary to preheat the oven. Without preheating however, you may find you need to add an extra 5 – 10 minutes on the recommended cooking times.
  • Page 17: Hints And Tips

    A slight increase in cooking time may be necessary. · Do not place baking trays directly on the oven base as it interferes with the oven air circulation and can lead to base burning; use the lower shelf position.
  • Page 18: Main Oven Cooking Chart

    MAIN OVEN COOKING CHART The oven temperatures are intended as a guide only. temperatures by a further 10°C to suit individual preferences and requirements. FOOD Biscuits Bread Bread rolls/buns Cakes: Small & Queen Sponges Victoria Sandwich Madeira Rich Fruit Christmas...
  • Page 19: Roasting Chart

    ROASTING CHART INTERNAL TEMPERATURES – Rare : 50-60°C; Medium : 60-70°C; Well done : 70-80°C MEAT Beef/ Beef boned Mutton/Lamb Pork/Veal/Ham Chicken Turkey/Goose Duck Pheasant Rabbit The roasting temperatures and times given in the chart should be adequate for most joints, but slight adjustments may be required to allow for personal requirements and the shape and texture of the meat.
  • Page 20: Defrost Feature

    · Turn the main oven temperature control to the defrost setting. THINGS TO NOTE · The oven fan and internal oven light will come · The cooling fan does not operate. HINTS AND TIPS · Place the frozen food in a single layer where possible and turn it over half way through the defrosting process.
  • Page 21: Care And Cleaning

    REMOVING AND REPLACING WIREWORK RUNNERS Remove all shelves and furniture from the oven. Hold the wirework at the bottom, unclip from the cavity side and gently pull towards the centre of the oven.
  • Page 22: Cleaning Inside The Ovens

    Stayclean surfaces destroy splashes of food and fats when the oven temperature is raised to around 220°C. It is a good idea to run the oven for an hour or two per week to ensure continued good performance from the Stayclean finish.
  • Page 23: Cleaning The Door(S)

    The outer oven door glass panels are removable for cleaning. TO REMOVE THE OUTER DOOR GLASS 1. Open the oven door slightly to gain access to the two cross head screws on the top of the oven door. 2. Loosen the two screws using a Pozidrive screwdriver.
  • Page 24: To Replace The Outer Glass Door

    All removable parts, except the grill pan handle can be washed in the dishwasher. The grill pan, grill pan grid and oven shelves may be cleaned using a soap impregnated steel wool pad. Soaking first in hot soapy water will make cleaning easier.
  • Page 25: Replacing An Oven Light Bulb

    4. Unscrew the bulb by turning it to the left. 5. Fit a new bulb and then replace the glass bulb cover. 4. Refit the wirework runners and replace the oven shelves. 5. Restore the electricity supply and reset the time of day.
  • Page 26: Something Not Working

    Check that the recommended temperatures and shelf positions are being used. The oven light bulb may need replacing. If the Main Oven is set for automatic cooking the light will illuminate when the cook time begins. Check that the oven is level.
  • Page 27: Service And Spare Parts

    Tel: +353 (0) 1 4090753 Email: service.eid@electrolux.ie CUSTOMER CARE DEPARTMENT For general enquires concerning your Electrolux appliance, or for further information on Electrolux products, please contact our Customer Care Department by letter or telephone at the address below:- Customer Care Department Electrolux 55 –...
  • Page 28: Guarantee Conditions

    Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: ·...
  • Page 29: Technical Details

    The Area of the largest Baking Sheet -cm² (3) Based on test results for a standard load in accordance with EN50304 Small:12l<35l Medium:35l<65l Large: 65l+ Surface Area of Shelf Conventional Function unless stated Forced Air Convection Function unless stated ELECTROLUX 0.74 Conventional Small Conventional 1470 Conventional 0.79...
  • Page 30: Installation Instructions

    (Fig.3). · If your cabinet interior dimension is between 565- 570mm the oven may still be fitted. However, a minor modification to the cabinet will be required to reduce the aperture size down to 560-565 mm, to allow the product to be securely screwed into the cabinet.
  • Page 31: Choice Of Electrical Connection

    3mm contact separation in all poles and neutral. c) If you wish to connect an oven and a hob to a cooker point you can by connecting the oven and hob separately to the cooker point. Oven and hob units should be separately connected to a cooker point.
  • Page 32: Recommended Cabinet Dimensions

    RECOMMENDED CABINET DIMENSIONS (IN MILLIMETRES) Cross section through cabinet showing oven positioned Fig. 3 Built In Installation...
  • Page 33: How To Finish Unpacking

    HOW TO FINISH UNPACKING · Place packed appliance next to the space in which it will be installed. · Remove the appliance packing except for bottom tray, which should be left in position until the appliance is ready to be fitted into its cabinet. NOTE: It is imperative that the appliance is left in the base to protect both the appliance and the floor.
  • Page 34: Connecting To The Mains Terminal

    CONNECTING TO THE MAINS TERMINAL Warning: This appliance must be earthed. · We recommend you use a new length of 6mm twin core and earthed cable to ensure your safety. · Make connection as shown in Fig. 7 by proceeding as follows:- ·...
  • Page 35: Fitting Into The Cabinet

    See Fig. 8. · Take out all oven furniture before installation to reduce the weight you need to lift. The oven door should be taped up to keep it closed whilst lifting. · To place the appliance into the cabinetry follow the procedure below: ·...
  • Page 36 This instruction booklet is accurate at the date of printing, but will be superseded if specifications or appearance are changed. ELECTROLUX 55 – 77 HIGH STREET, SLOUGH, BERKSHIRE, SL1 1DZ. TELEPHONE 0870 5 950950 www.electrolux.co.uk Part Number: 311728901 © Electrolux plc 2005...
