Introduction
0.1 Defining the DriveRack ® PA .........................ii
0.2 Service Contact Info........................................iii
0.3 Warranty...........................................................iv
Section 1 - Getting Started
1.1 Rear Panel ......................................................2
1.2 Front Panel .....................................................2
1.3 Quick Start .....................................................3
Section 2 - Editing Functions
2.1 Basic Navigation Modes.................................12
2.2 Button Array Overview ..................................12
2.3 Navigating the EQ Section (GEQ/PEQ)........14
2.4 Navigating the Subharmonic Synthesizer Section....14
2.5 Navigating the Crossover Section..................14
2.6 Navigating the Feedback Suppression Section ..15
2.7 Navigating the Comp/Limiter Section ...........15
2.8 Navigating the Speaker Alignment Delay
Section..................................................................15
2.9 Navigating the Utility Section ........................16
2.10 Navigating the Wizard Section ....................16
Section 3 - Operating the
DriveRack PA
3.1 Program Definition.........................................18
3.2 Navigating Factory Programs.........................18
3.3 Editing Factory Programs...............................18
Section 4 - Detailed Parameters
4.1 Pre-Crossover Graphic EQ.............................22
4.2 Advanced Feedback Suppressor ...................22
4.3 Subharmonic Synthesizer...............................23
4.4 Crossover ........................................................24
4.5 Post-Crossover Parametric EQ .......................25
4.6 Compressor/Limiter ........................................25
4.7 Speaker Alignment Delay .............................27

Table of Contents

®
PA
DriveRack® User Manual
Table of Contents
Section 5 - Application Guide
5.1 2X6 Crossover.................................................30
5.2 2X5 Crossover.................................................31
5.3 2X4 Crossover.................................................32
5.4 2X3 Crossover.................................................33
Appendix
A.1 Factory Reset .................................................36
A.2 Quick Key Options........................................36
A.3 Specifications..................................................37
A.4 Auto EQ Optimization Tips ..........................37
A.5 Crossover Diagrams .......................................38
A.6 Block Diagram ...............................................39
A.7 Prog List/Speaker Tunings/Amp Tunings ....40
A.8 System Setup and Gain Structure .................41
®
®
®
