Technical Information

Pin Assignment

Digital Video Input Connector : DVI – D (option)
TX2-
1
TX2+
2
Shield (TX2 / TX4)
3
NC
4
NC
5
6
DDC-Serial Clock
DDC-Serial Data
7
8
NC
Signal
PIN
Description
1
Red
2
Green
3
Blue
4
N.C.
5
GND
6
Red_GND
7
Green_GND
8
Blue_GND
9
TX1-
10
TX1+
Shield (TX1 / TX3)
11
12
NC
13
NC
+5V power
14
Ground (+5V)
15
16
Hot plug detect
9
Signal
PIN
Description
9
+5V
10
N.C.
11
N.C.
12
DDC_SDA
13
HSYNC
14
VSYNC.
15
DDC_SCL
17
TX0-
18
TX0+
Shield (TX0 / TX5)
19
NC
20
NC
21
22
Shield (TXC)
23
TXC+
TXC-
24
