• Assemble the two 1/2 bases
• Insert the main body into the base and fix with screws.
How to extract the remote control:
1. Push the remote control toward the main body
2. Half of the remote control will be bounced out
3. Pull out the remote control as showed
How to insert the remote control
1. Place the remote control in front of its storage
2. Push the remote control on half
3. Push in the remote control
Replace the battery as showed.
NOTE : Before using the remote control, remove the battery protection. Pull out the remote control, open
the remote control, extract the battery, remove the film protection, replace the battery and close the
remote control.
16/01/07 10:39 Page 6

DESCRIPTION OF THE APPLIANCE

DESCRIPTION OF THE APPLIANCE
1. Remote control
2. Body fan
3. Control panel
4. 1/2 base
5. 1/2 base
6. Screws
7
7. Power cord
5
ASSEMBL Y OF THE APPLIANCE
ASSEMBL Y OF THE APPLIANCE
THE REMOTE CONTROL
THE REMOTE CONTROL
