Aube Technologies TI-0723W Specification

SwitcheS
TI072-3W
This easy-to-install switch handles
motors, all types of lighting, and features
both the flexibility of 7-day programming
and the convenience of automatic
sunset / sunrise activation
MODEL & RATINGS
TI072-3W 1800 W max.
SPECIFICATIONS
PROGRAMMING
7-day programming, up to 42 events
Solar timetable can be used simultaenously
with daily programs
OPERATING MODES
Manual (conventional on/off switch)
Automatic
Random
CONNECTION
Single pole 3 wire (line, load, neutral) or
Multiswitch (3-way) 4 wire (line, load, 3-way, neutral)
DIMENSIONS (H•W•D)
68 x 43 x 43 mm / 2.7 x 1.7 x 1.7 inches
INSTALLATION
N L
Black
White
White
w w w . a u b e t e c h . c o m
120 V, 60 Hz 15 A (I,R)
*
Jumper
Line (Black)
Black
Red
3-way (Yellow)
3-WAY SWITCH
Neutral (white)
L Load (Blue)
Black
3-way installation shown
3
warranty
12 A tungsten
FEATURES
Sleek design mounts flush with wallplate
Works with motors and all types of lighting
(compatible with electronic ballasts, compact
fluorescent lights and tungsten lighting up to 12 A)
Large white backlit display with a night light
mode option for easy reading in dark areas
Confirmation LED for at-a-glance load status
(on or off)
Random mode activates lights randomly to
simulate a presence when away from home
Easy intuitive 3-button interface – no door to open
Automatic daylight savings – no need to
reprogram
Hidden lock feature prevents tampering without
requiring costly security cover
PROGRAMMING
Up to 21 programs (21 on / off times) per week.
A program can apply to a single day or repeat
every day. Sunset/sunrise times are calculated
automatically every day. * For each day of the
week, the user can choose: sunset /sunrise
year
programming or their own on/off time, or one
of each (e.g. sunset and midnight).
1 - 8 0 0 - 8 3 1 - A U B E
For Lights & Motors
1 HP
