Aube Technologies TI073-3W Specification

SwitcheS
TI073-3W
Do-it-yourself installation and both
the flexibility of 7-day programming
and the convenience of automatic
sunset / sunrise activation
MODEL & RATINGS
TI073-3W 500 W max./ 40 W min.
SPECIFICATIONS
PROGRAMMING
7-day programming, up to 42 events
Solar timetable can be used simultaneously
with daily programs
OPERATING MODES
Manual (conventional on/off switch)
Automatic
Random
CONNECTION
Single pole (2 wire) or multiswitch (3-way)
DIMENSIONS (H•W•D)
68 x 43 x 43 mm / 2.7 x 1.7 x 1.7 inches
INSTALLATION
N L
3-WAY SWITCH
Black
Red
Jumper
w w w . a u b e t e c h . c o m
120 V, 60 Hz
*
3-Way (Yellow)
Load (Black)
Ground (Green)
Line (Black)
L
3-way installation shown
3
warranty
4 A (R)
FEATURES
Sleek design mounts flush with wallplate
Works with incandescent, halogen and
fluorescent lighting (compatible with
electronic ballasts)
Large white backlit display with a night light
mode option for easy reading in dark areas
Confirmation LED for at-a-glance load status
(on or off)
Random mode activates lights randomly to
simulate a presence when away from home
Easy intuitive 3-button interface – no door to open
Automatic daylight savings – no need to
reprogram
Hidden lock feature prevents tampering without
requiring costly security cover
PROGRAMMING
Up to 21 programs (21 on/off times) per week.
A program can apply to a single day or repeat
every day. Sunset/sunrise times are calculated
automatically every day.
week, the user can choose: sunset /sunrise
year
programming or their own on/off time, or one
of each (e.g. sunset and midnight).
1 - 8 0 0 - 8 3 1 - A U B E
For Lights
* For each day of the
