Alarm Lock A-100IMWP Wiring & Programming Instructions Manual page 2

• Green LED turns OFF
• Each Output 1,2 & 3 activates for 1½ seconds
• Orange LED turns OFF
• Sounder beeps twice (memory resets and default
values enabled)
4. Close the "Request to Exit" button (short purple
and pink wires).
• Keypad backlight is OFF
• Press BELL
• Sounder beeps once
• Keypad blinks
5. Remove the jumper on the back of the keypad.
• Sounder beeps once
• Keypad backlight is OFF
• Red led is ON
6. Remove power to the power input terminals.
7. Apply power to the power input terminals.
• Sounder beeps once
If the keypad encounters a problem while memory is re-
setting at step 3, the sounder will beep continuously until
the jumper is removed and the procedure is repeated at
step 1. The factory default values are detailed below.
Default Values
No pre-configured user codes exist for new "out of the
box" keypads. Other default values include:
User Code length
Illumination Duration
Maximum Delay Between Key Presses
Auto Exit Program Mode
Factory Default Master Code
Output Activation Duration
Sounder
First Key Press Activates Output 3
Doorbell On Output 2
Enter Program Mode
The keypad software has only two "modes"--"Normal
Mode" and "Program Mode". When you want to make
changes to the keypad (enter new User Codes, etc.), you
enter "Program Mode". When you finish programming
and wish to put the keypad into use, you exit Program
Mode to enter "Normal Mode".
• Enter Program Mode: Press
Enter Program Mode by pressing
the Master Code of the lock that was set at the factory
1234
( ), followed by the
lights and the sounder beeps twice).
The factory Master Code (
cret passcode that allows you to enter Program Mode.
But since all keypads leave the factory with this same
Master Code, the factory Master Code is therefore not
very secret--and should be changed to your own personal
Master Code. This way, only YOU can enter Program
Mode and make changes to the keypad programming.
Change Factory Master Code
Although the factory Master Code can be changed at any
time, for highest security, follow the procedure below:
2
4 digits
10 seconds
10 seconds
120 seconds
1234
5 seconds
Always ON
Inactive
Inactive (if available)
55#1234*
55#
, then press
*
key (the orange LED
1234
) is basically a se-
Think of a new four-digit numeric Master Code and either
commit it to memory or write it here: ___ ___ ___ ___.
Note: Only numbers zero through 9 are valid digits for
either User Codes or the Master Code. Keys
are not allowed. In addition, the Master Code and all User
Codes must always be the same number of digits in
length (3-6 digits allowed). Therefore, if you enter Pro-
gram Mode and change this "Code Length" using Func-
tion 30, you must then remain in Program Mode and
change the Master Code to conform to the new "Code
Length". At this point, however, we recommend you do
not change the Code Length unless you are an advanced
user.
1. If not in already, enter Program Mode (press
55#1234*
• Orange LED lights - sounder beeps twice.
31#
2. Press
• Green LED blinks once - sounder beeps once.
3. Press new 4-digit Master Code and press
• Green LED blinks once - sounder beeps once.
4. Re-press new 4-digit Master Code and press
#*
.
• Green LED lights / sounder beeps for 1 second indi-
cating the Master Code was changed successfully.
The keypad remains in Program Mode while the orange
LED remains lit. Note: The keypad will automatically exit
Program Mode if no keys are pressed within 120 seconds
(2 minutes).
Adding User Codes
User Codes are 3-6 digit numbers the User presses into
the keypad keys to activate one or more Outputs. The A-
100IMWP keypad can hold up to 150 User Codes in its
memory, thus allowing up to 150 people to possess their
own individual User Codes. The keypad memory associ-
ates each User Code with a 3-digit User Number listed
from 000 to 149.
Codes, you must also select a 3-digit User Number be-
tween 000 and 149 that will be associated ("linked") with
the new User Code. As with the Master Code, only num-
bers zero through 9 are valid digits for User Codes (keys
* #
or are not allowed) and each User Code must be
.
unique.
1. If not in already, enter Program Mode.
• Orange LED lights - sounder beeps twice.
32#
2. Press
• Green LED blinks once - sounder beeps once.
3. Press new 3-digit User Number and press
• Green LED blinks once - sounder beeps once.
4. Press new 4-digit User Code and press
• Green LED blinks once - sounder beeps once.
5. Re-press new 4-digit User Code and press
• Green LED lights / sounder beeps for 1 second indi-
cating the User Code was added successfully.
Delete a User Code
1. If not in already, enter Program Mode.
).
Therefore, when adding new User
#
* #
or
#
.
#
.
.
#*
.
