Summary of Contents for Akura AHLTV15DVD
-
Page 1: Instruction Manual
AHLTV15DVD Instruction Manual LCD TV/DVD Combo Customer Help Line 01422 263313. www.ekey.co.uk 24Hr Opening hours Mon-Fri 8 am – 8pm. Sat 9 am – 4pm. Sun 11am – 4pm “Bank holidays as Sun”... -
Page 2: Table Of Contents
Dear Customer. Thank you for purchasing this 15.4″, (15.25”viewable) LCD/DVD-TV After unpacking, please check that you have the following items:- Operating instructions, Remote control, 2 x “AAA” batteries, AC adapter, VGA lead, Stereo Audio lead. Power Consumption Reduction. To enable the user to reduce the “carbon footprint” of the Tv, it is suggested that the Tv is turned off completely at the mains supply, rather than be left in standby when not in use. -
Page 3: Important Safety Precautions
1- Important Safety Instructions The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un-insulated “dangerous voltage” within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to the persons. The exclamation point within an equilateral triangle is intend to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. - Page 4 CAUTION. PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS USER MANUAL AND MARKED ON THE APPLIANCE. RETAIN THIS BOOKLET FOR FUTURE USE. This set has been designed and manufactured to assure your personal safety. Improper use can result in Electric shock or Fire hazard.
-
Page 5: Features
2. Features 1- Multi band Tv reception. 2- Full function Infra-red remote control. 3- Scart Input. 4- Analog RGB input (PC VGA) 5- CVBS and S-VIDEO input. 6- PC and CVBS Audio inputs. 7- Coaxial Audio output. 8- 2 x 3W internal speakers. 9 Plays DVD, CD, Digital Audio, WAV, VCD discs. -
Page 6: Remote Control
5 – Remote Control Page 5... -
Page 7: Remote Control Batteries
6 Remote Control Batteries The remote unit is operated with 2 AAA size batteries. 1. Push and hold the hook, the battery cover is opened 2. Insert batteries according to the polarity marks. 3. Replace the cover. Remarks: Battery replacement is necessary when the remote control fails to operate the TV set. Warnings Incorrect use of batteries can cause chemical leakage which will corrode the Remote Control Unit or cause the batteries to burst. -
Page 8: Connectors Input/Output
7. Connectors (Input / Output) Connectors descriptions: ① ：Audio Coaxial Output, connecting to Coaxial input of your Audio Amplifier. ② ：DC 12v power input for the LCD TV, connect power supply adaptor here. ③ ：Scart input interface, connect your AV system/DVB “freeview” to the Tv. ④... -
Page 9: Scart Input
SCART input. 1. Scart input. 2. DC 12V power input. Connection steps： Read the user guide supplied with your AV devices and ensure that it has a scart connector; Make sure that the power of the LCD/DVD-TV is off; Connect a SCART cable to the corresponding interface connector on the back of the LCD/DVD-TV;(1) Turn on the power of the LCD/DVD-TV;... -
Page 10: Basic Operating Instructions
Connection steps： Read the user guide supplied with your computer and ensure that it has a VGA connector; Make sure that the power of the LCD/DVD-TV and the PC are off; Connect a D type 15-pin VGA interface cable (not supplied) to the VGA video interface connector on the PC. -
Page 11: Menu Operations
Selecting a TV channel. TV Menu.jpg You can use the number keys on the remote control to directly select TV channels. The LCD/DVD-TV can store up to 99 channels (1 to99), and you can press the keys on the remote control or on the panel to make a selection. 1- Press the relevant key on the remote control if you want to choose any channel from 1 to 9.（for example: if you want to choose channel 8, just press the key number... -
Page 12: Search Tuning
1 Volume: Adjust the volume. 2 Balance: Adjust the balance of the audio output from left to right. 3 Audio Preset: Four different settings: Personal, Voice, Music and Theatre. 4 Treble: Adjust the treble of the sound, this can only be adjusted in Personal mode 5 Bass: Adjust the bass of the sound, can only be adjusted in Personal mode... -
Page 13: Manual Tuning
Manual Tuning. If you need to add another station or signal from a Tv game or other source, rather than “Autosearch” you may manually add another station. Ensure the additional apparatus is connected and turned on. Press the LCD-Menu button 3 times to select the TV Menu. Select CHANNEL and using the buttons to select a free location. -
Page 14: Teletext
10 Teletext. Teletext is a digital data system that allows hundreds of pages of information to be transmitted. This data is combined with the normal Tv signal. Not all Tv stations transmit teletext all the time. To select Teletext use the Teletext buttons located in the lower section of the Remote control. -
Page 15: Basic Dvd Operation
1 DVD BASIC OPEPERATING INSTRUCTIONS 1. DVD on Turn on the LCD/DVD TV, switch to the DVD mode for DVD operation. 2．(1) Control DVD Illustration: DVD Control Panel Functions: 1- PREV -- DVD Previous Chapter 2- NEXT -- DVD Next Chapter 3- STOP -- DVD Stop button 4- PAUSE -- DVD Pause button... - Page 16 2. Title Playback (For DVD Disc only) • Press TITLE button , there will be an on screen indication “TITLE”. • Press the direction or numeric buttons to select your favorite title. • Then it will play from the first chapter of the selected title.
-
Page 17: Function Operating Instructions
2 Function Operating Instructions 1. Play (For DVD, Super VCD, VCD, CD, CD-G, HD-CD, Digital Audio /JPEG discs, DMP and USB) • For DVD disc, press PLAY button from root or title menu; while playing the DVD, you may play your favorite title directly with title selection by pressing the TITLE button. •... - Page 18 4. Slow motion (For DVD, Super VCD & VCD discs, DMP and USB) While playing the disc, you may use the slow motion function. • There are 6 speeds for slow motion. Press SLOW button to toggle between different speeds in sequence. (SF1/2 – SF1/3 – SF1/4– SF1/5 – SF1/6 – SF1/7 – Play) •...
- Page 19 8. Goto (For DVD, Super VCD, VCD, CD, CD-G, HD-CD, Digital Audio /JPEG discs, DMP and USB) This function allow you to play your favorite Title / Chapter / track. Press GOTO button to activate the on screen scroll-down menu for edit. According to the highlighted area, input your favorite Title / chapter / Track number by numeric buttons or input the playback time.
-
Page 20: Digital Audio /Jpeg Playback
14. Mute (For DVD, Super VCD, VCD, CD, CD-G, HD-CD, Digital Audio /JPEG discs, DMP and USB) • Press MUTE button to mute the audio output. There will be an on screen symbol to indicate “MUTE”. • Press again to cancel, or Press VOL + / VOL – to cancel and adjust the volume. •... -
Page 21: Function Settings
Using the navigation buttons to check you favorite folder and playback the first file or move to the your favorite file. Note: • Press ◄ ► buttons to move the highlight to folders, documents or mode selection. • Press numeric buttons to select the contents directly. For number over 10, press -/-- button first. - Page 22 ․ Press ◄ / ► button to move and highlight between different sub-menu. Press ▲ / ▼ ENTER button to enter the highlighted sub-menu. ․ Press DVD-SETUP button to exit the OSD menu, or move the highlight to EXIT SETUP then press ENTER button to exit.
- Page 23 4:3PS : suitable for normal TV, when playback wide screen movie, the left and right of the screen will be cropped. 4:3LB : suitable for normal TV, when playback wide screen movie, the top and bottom will have a black border. 16:9 : suitable for Wide Screen Movies.
- Page 24 Default Settings Press ENTER button to restore factory defaults. 3. Language Setup Press DVD-setup button to enter the DVD OSD menu. OSD Language Use navigation buttons to select the OSD LANGAUGE setup icon, press ENTER button to confirm. There are 6 languages for you selection, press ▲ & ▼ buttons to toggle between different languages.
- Page 25 Use navigation buttons to select the AUDIO LANG setup icon, press ENTER button to confirm. There are 7 languages for you selection, press ▲ & ▼ buttons to toggle between different languages. (ENGLISH – GERMAN – SPANISH - FRENCH – PORTUGESE –...
- Page 26 4. Audio Setup Audio Output, Use navigation buttons to select the AUDIO OUT setup icon, press ENTER button to confirm. There are 3 modes for your selection; use navigation buttons to select different modes, press ENTER button to confirm. (SPDIF / OFF – SPDIF / original code – SPDIF / PCM) SPDIF / OFF: Coaxial output off.
- Page 27 You can select four different audio outputs, STEREO, MONO L, MONO R, MIX MONO. Page 26...
-
Page 28: Disc Handling And Care
Page 27... -
Page 29: User Help Guide
11 User Help Guide If for some reason your LCD/DVD TV fails to operate, or has other difficulties, please consult the guide below before calling the “Customer Help Centre” Symptom Possible Cause Remedy Ensure all the connections Dead. No led lit No power to the Tv have been made firmly and the power is turned on. -
Page 30: Specifications
12 Specifications. Rf input 40 dbuV-80 dbuV. Frequency. Band 1 Ch 2 – Ch 4 Band 3 CH 5 – Ch 12 CH 21 – CH 69 Inputs. Scart. RGB, Composite, Audio, Pin 8 switching 1V PP composite video S-Video 1V PP Composite, 200mv Chroma, PC VGA Analog RGB...
