Summary of Contents for Akura AIDVD5612HD
-
Page 2: Table Of Contents
Content Introduction Safety Precautions Important Safety Instructions Caution Features Front Panel and Rear Panel Illustration Remote Control Connections Analog Audio Digital Audio Advanced Features Function Operation MP3/WMA/MPEG4 playing Picture CD playback SYSTEM setup USB/SD MMC inputs Others Troubleshooting Remote Control Preparation About DVD... -
Page 6: Introduction
Features Introduction Disc formats supported by this player: MPEG4 files on discs Multi-angle Dolby Digital Subtitle choices Audio choices MP3 files on CD-R/CD-RW 16:9 LB TV Aspect Ratio modes DVD video R RESTRICTED Parental Lock This product incorporates copyright protection technology that is protected by method claims of certain U.S.patents and other intellectual property rights owned by Macrovision Corporation and other rights owners.Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intendedfor home and other limited viewing uses only unless otherwise authorized... -
Page 7: Front Panel And Rear Panel Illustration
Pr/Cr VIDEO Pb/Cb COAXIAL S-VIDEO HDMI OUT HDMI OUT 5.1 CH AUDIO OUT VIDEO OUT COMPONENT COAXIAL... -
Page 8: Remote Control
Introduction Remote Control Remote Control PAUSE... - Page 9 Remote Control Preparation Other Battery installation Battery installation Using the remote Using the remote 1.Open the cover 1.Open the cover Point the remote control at the remote sensor. (The pictures below are for reference only.) 2.Install batteries 2.Install batteries 3.Close the cover 3.Close the cover...
-
Page 10: Connections
Connections CONNECT DVD PLAYER TO TV SET BY AV CABLE Connect the DVD player s FR and FL jack the audio input jack on the TV VIDEO AUDIO Audio cable Video cable Pr/Cr VIDEO Pb/Cb COAXIAL S-VIDEO 5.1 CH AUDIO OUT VIDEO OUT COMPONENT COAXIAL... - Page 11 Connections CONNECT DVD PLAYER TO TV SET WITH SCART SOCKET Use the SCART cable (not supplied) to connect DVD player and your TV. Set the [Video Type] to [TV-RGB]. VIDEO AUDIO Scart Pr/Cr VIDEO S-VIDEO Pb/Cb COAXIAL 5.1 CH AUDIO OUT VIDEO OUT COMPONENT COAXIAL...
-
Page 12: Analog Audio
Connecting to an AV Amplifier with 5.1 Channel Analog Audio Input Connections CVBS SCART OUT S-VIDEO SCART OUT 5.1 CH AUDIO OUT 5.1 CH AUDIO OUT VIDEO OUT VIDEO OUT COMPONENT COMPONENT COAXIAL COAXIAL HDMI OUT HDMI OUT VIDEO HDMI WHITE Amplifier VOLUME... -
Page 13: Digital Audio
Connecting to an AV Amplifier with Digital Audio Input Connections Pr/Cr VIDEO S-VIDEO Pb/Cb COAXIAL 5.1 CH AUDIO OUT VIDEO OUT COMPONENT COAXIAL HDMI OUT HDMI OUT Coaxial Digital Amplifier VOLUME INPUT SELECTOR POWER BYPASS PRO LOGIC 3 STEREO MODE TEST CHANNEL KARAOKE... -
Page 14: Function Operation
FUNCTION OPERATION Function Buttons STANDBY Press the button to switch the power between normal work mode and standby mode.. OPEN/CLOSE To open the disc tray, press OPEN/CLOSE; To close the disc tray, press OPEN /CLOSE again. SUBTITLE Press the button to choose different captions(Requires support from disc) GOTO For DVD discs, press the button to choose the desired title and chapter and search the desired title time and chapter time. - Page 15 FUNCTION OPERATION DISPLAY Press the button to show the information of the current playing disc. TITLE Press the button to enter the appointed title.(Requires disc support) Direction key(UP/DOWN.RIGHT/LEFT) Press the keys to move the highlighted bar or cursor on any menu to your selection.
- Page 16 FUNCTION OPERATION VOLUME+/- Press VOL+ to increase volume and press VOL- to decrease volume. REPEAT Each press of the REPEAT button will change the repeat mode. During VCD, CD playback, there are three modes: repeat Single, repeat ALL and Off. During DVD, playback, there are three modes: Repeat Chapter, Repeat Title and OFF.
- Page 17 FUNCTION OPERATION...
-
Page 18: Mp3/Wma/Mpeg4 Playing
MP3/WMA/MPEG4 PLAYING Filter Repeat off Mode Normal Photo JPEG Preview XVID 00:00:15 Photo Filter Repeat off Mode Normal JPEG Preview... - Page 19 MP3/WMA/MPEG4 PLAYING Mode: Select different playing mode Normal: Shuffle mode is cancelled Shuffle: Shuffle mode enabled. When playback reaches the end of the current chapter/track, playback jumps to a random chapter/track. As the end of each chapter/track is reached, another random chapter/track will be played until all tracks/chapters have been played or the Shuffle mode is cancelled by toggling to a different Mode Option.
-
Page 20: Picture Cd Playback
PICTURE CD PLAYBACK Photo Filter Repeat off Mode Normal JPEG Preview Filter Repeat off Mode Normal JPEG Preview... -
Page 21: System Setup
SYSTEM SETUP Language OSD Language English Subtitle German Video MPEG4 Subtitle Czech Audio Polish Audio DVD Menu Hungarian Slovakian Rating Misc Subtitle This option provides the preset subtitle language. Follow the operating instructions stated in DVD MENU SETUP In combination with the desired option. - Page 22 SYSTEM SETUP Language OSD Language Subtitle Video MPEG4 Subtitle ASCII Audio Unicode Central European Audio DVD Menu Rating Misc Audio Follow the operating instructions stated in DVD MENU SETUP Combination with the desired option. This option provides the built-in disc dubbing language options. English Language OSD Language...
- Page 23 SYSTEM SETUP Language 4:3LB Aspect Ratio 4:3PS TV System Video 16:9 Video Out Smart Picture Audio HD Resolution Rating Misc Notes: The image display ratio is related to the recorded disc format. Some disc can not display images in the aspect ratio you choose. If you play a disc recorded in 4:3 format on a wide screen TV, black bars will appear on the left and right side of the screen.
- Page 24 SYSTEM SETUP Language Aspect Ratio TV System Video Video Out S-Video Smart Picture Component Audio HD Resolution P-scan Rating Misc Smart picture Adjust display effect for video output: Standard: default effect. Bright: internal setting for bright view effect. Soft: internal setting for soft view effect. Dynamic: user adjust brightness, contrast, color etc.
- Page 25 SYSTEM SETUP Audio setup Select Audio in the setup menu, and display the Audio submenu. Analog output Analog out select 5.1CH or 2.0 CH(select down mix) audio output. Analog output 5.1 CH Language Digital Output 2 CH Video Test Tones Down sampling Audio Smart sound...
- Page 26 SYSTEM SETUP Analog output Language Digital Output Video Test Tones Down sampling Left Audio Smart sound Right Center Rating Left surr. Right surr. Misc Subwoofer Analog output Language Digital Output Video Test Tones Down sampling Audio Smart sound Rating Misc Analog output Language Digital Output...
- Page 27 SYSTEM SETUP RATING SETUP Select Rating in the setup menu, and display the Rating submenu: Note: Not all DVD support ratings. Parental Control Selecting a Rating allows the user to set the parental control feature of the player Select Parental Control, and press ENTER to change the different mode. Note: Unlock the password before setting Parental Control Language Parental Control...
- Page 28 SYSTEM SETUP MISC SETUP Select MISC in the setup menu, and display the submenu: * Use Default Settings Reset setup data to factory default and re-load disc. Language Use Default Settings Video Audio Rating Misc...
-
Page 29: Usb/Sd Mmc Inputs
Advanced Features... -
Page 32: About Dvd
Specifications Power requirements: AC 100-240 Volt, 50/60Hz Power consumption: 15W Video standard: NTSC/PAL/Multi Unit Weight: 1.7kg Disc s COMPATIBILITY: MPEG4,DVD,DVD+/-R/RW,VCD,JPEG.CD-DA,CD-R, CD-RW, USB 1.1 Video out Video out: 1.0V(p-p)/75 , sync, negative polarity, RCA pin jack x 1 S-video output connector(separate Y C signal output connector): Y output: 1.0V(p-p)/75 , sync, negative polarity C output: 0.286V(p-p)/75 Audio out...
