Page 1: Table Of Contents
TABLE OF CONTENTS SAFETY PRECAUTIONS IMPORTANT SAFETY INSTRUCTIONS NOTICE ACCESSORIES and FRONT PANEL CONTROL and BASIC CONNECTION BASIC CONNECTION REMOTE CONTROL BASIC PLAYBACK ADVANCED PLAYBACK SPECIAL FUNCTION PLAYBACK SYSTEM SETUP TROUBLE SHOOTING SPECIFICATIONS... -
Page 2: Safety Precautions
SAFETY PRECAUTIONS The lightning flash with arrowhead symbol, within an equila- teral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage " within the product's en- closure that may be of sufficient magnitude to constitute a risk of electric shock to persons. - Page 3 SAFETY PRECAUTIONS This product incorporates copyright protection technology that is protected by method claims of certain U. S. Patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation.
-
Page 4: Important Safety Instructions
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. -
Page 6: Accessories And Front Panel
ACCESSORIES and FRONT PANEL ACCESSORIES Audio/Video cable ....1 Remote control ......1 Owner's manual ......1 Batteries........2 V.MODE SUBTITLE SEARCH TITLE REPEAT A-B RPT CLEAR PAL/NTSC SETUP MENU OWNER'S MANUAL ZOOM PROG F.REV F.FWD PREV NEXT PAUSE STEP STOP AUDIO MUTE... -
Page 7: Control And Basic Connection
CONTROL and BASIC CONNECTION REAR PANEL OUTPUT S/N: A003249XXXXXX CLASS 1 LASER PRODUCT DVD62 Manufactured under Apparatus SCART OUTPUT license from Dolby Claims of U.S. AC 230V-240V~ 50Hz Laboratories. "Dolby" Patent Nos. 4, and the double-D 631,603;4,577, CR / PR symbol are trademarks 216;4,819,098 CB / PB... -
Page 8: Basic Connection
BASIC CONNECTION Connecting to a audio system and TV equipped with YUV video input CR / PR CB / PB COAXIAL VIDEO S-VIDEO 2-CH AUDIO OUT DIGITAL AUDIO OUT / VIDEO OUT To CR/PR video input To CB/PB video input To audio inputs of the amplifier To Y video input Connecting to an amplifier equipped with a digital audio input and TV... -
Page 9: Remote Control
REMOTE CONTROL REMOTE CONTROL Function Function 1. OPEN/CLOSE DISC TRAY 16. MUTE V.MODE 2. V.MODE 17. ANGLE SUBTITLE 3. OSD (On Screen Display) 18. STANBY SEARCH TITLE 4. SUBTITLE 19. DIGITS AND 10+ BUTTONS REPEAT A-B RPT CLEAR PAL/NTSC 5. TITLE 20. -
Page 10: Basic Playback
BASIC PLAYBACK Preparations Fast forward and Fast reverse When you want to view a disc, turn on the TV and 1. Press F.FWD to fast forward through the disc. select the video input connected to the DVD player. Each time the F.FWD button is pressed, the fast forward motion speed changes. -
Page 11: Advanced Playback
ADVANCED PLAYBACK TITLE MENU Press this button and the screen will display " Root According to some DVD discs, press this button will Menu ", select item according to your preference. display "Title Menu", the unit will play from the disc (This key is valid to DVD disc possessing multi-layer head or you can use digits to select tracks preferred. -
Page 12: Special Function Playback
SPECIAL FUNCTION PLAYBACK AUDIO CD PLAYBACK When playing Audio CD disc, a navigation menu will be displayed 00:00 00:00 automatically if the disc is loaded in succession. 001/010 In the menu, use UP or DOWN button in the cursors to select the file, then press "ENTER/PLAY"... -
Page 13: System Setup
SYSTEM SETUP When you press SETUP key on the remote control, 1.2 ANGLE MARK the setup menu will be displayed. 1.Within the setup menu, you can use UP, DOWN, ANGLE MARK: Users can select a particular camera LEFT and RIGHT buttons on the remote control angle when playing a DVD that offers multiple angles. - Page 14 SYSTEM SETUP 2.1.1 DOWNMlX SETUP 3. DOLBY DIGITAL SETUP PAGE DOWNMIX MODE: Sets front speakers to LT/RT STEREO. The first 2 settings (LT/RT, STEREO) downmix Dolby General Audio Video Preference the sound Signal for 2-Speakers. This setting Dolby Digital Setup allows you to enjoy a surround sound effect with Dual Mono onIy two speakers.
- Page 15 SYSTEM SETUP 4.2 TV MODE SETUP PAGE TV MODE: Sets the scan mode to same of your TV. If there are picture interferences or no picture, please press "V.MODE" to correct it. he component option must select YUV , the TV MODE option is valid.
-
Page 16: Trouble Shooting
TROUBLE SHOOTING Please check the following guide for the possible cause and solution for a problem before contacting the nearest service center or dealer for repairs. SYMPTOMS AND CORRECTIONS SYMPTOMS CORRECTIONS Check to make sure that the power connection is secure. No power Make sure the connection between the player and the TV is secure. -
Page 17: Specifications
SPECIFICATIONS System and Outputs VF Signal NTSC/PAL system CD: 20Hz-20KHz(EIAJ) Frequence DVD: 20Hz-44KHz(96KHz)(Sample result) response 20Hz-22KHz(48KHz)(Sample result) Audio S/N ratio > 90 dB MPEG1 V2.0; MPEG2 Video/Picture Audio MPEG LAYER2 standard Audio output Electric level output: 1.8 0.2V Resistance: 10KS (analog audio) Audio output Electric level output: 0.5Vp--p...
