IMPORTANT INSTRUCTIONS -
Models: AKF50LS, AKF80LS,
AKF100LS
READ AND SAVE THESE INSTRUCTIONS
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED.
PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE TO COMPLY WITH
INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE!

GENERAL SAFETY INFORMATION

electric shock and injury to person, including the following:
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK
AND INJURY TO PERSON, OBSERVE THE FOLLOWING:
a) Use this unit only in the manner intended by the manufacturer.If you
have questions, contact the manufacturer.
b) Before servicing or cleaning the unit, switch power off at
service panel and lock the service disconnecting means to
prevent power from being switched on accidentally. When the
service disconnecting means cannot be locked, securely fasten
a prominent warning device, such as a tag, to the service panel.
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK
AND INJURY TO PERSON, OBSERVE THE FOLLOWING:
a) Installation work and electrical wiring must be done by qualified
person(s) in accordance with all applicable codes and standards,
including fire-related construction.
b) Sufficient air is needed for proper combustion and exhausting
of gases through the flue (chimney) of fuel burning equipment to
prevent back drafting. Follow the heating equipment manufacturer's
guideline and safety standards such as those published by the
National Fire Protection Association (NFPA) and the American
Society for Heating, Refrigeration, and Air Conditioning Engineers
(ASHRAE), and the local code authorities.
c) When cutting or drilling into wall or ceiling, do not damage electrical
wiring and other hidden utilities.
210572203 Rev. C 3-10
OPERATING MANUAL
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
When using electrical appliances, basic precautions
should always be followed to reduce the risk of fire,
SAVE THESE INSTRUCTIONS
CAUTION:
TO EXHAUST HAZARDOUS OR EXPLOSIVE MATERIALS AND VAPORS.
d) Ducted fans must always be vented to the outdoors.
e) This unit must be grounded.
f) To avoid motor bearing damage and noisy and/or unbalanced
impellers, keep drywall spray, construction dust, etc. off power unit.
g) Read all instructions before installing or using exhaust fan.
WARNING:
NOT USE THIS FAN WITH ANY SOLID-STATE SPEED CONTROL DEVICE.
a) Acceptable for use over a bathtub or shower when installed
in a GFCI protected branch circuit.
b) NEVER place a switch where it can be reached from a tub or
shower.
WARNING:
www.airkinglimited.com
Exhaust Fan with Light
FOR GENERAL VENTILATING USE ONLY. DO NOT USE
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, DO
DO NOT USE IN KITCHENS.
1 of 12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AKF100LS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Air King AKF100LS

  • Page 1: General Safety Information

    IMPORTANT INSTRUCTIONS - OPERATING MANUAL Models: AKF50LS, AKF80LS, Exhaust Fan with Light AKF100LS READ AND SAVE THESE INSTRUCTIONS READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED. PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE! RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
  • Page 2: Installation Instructions

    SECTION 4 INSTALLATION INSTRUCTIONS Ducting CAUTION: MAKE SURE POWER IS SWITCHED OFF AT SERVICE PANEL CAUTION: BEFORE STARTING INSTALLATION. ALL DUCTING MUST COMPLY WITH LOCAL AND NATIONAL BUILDING CODES. SECTION 1 1. Connect the ducting to the fan’s duct collar (Figure 4). Secure in place using tape Preparing the Exhaust Fan or screw clamp. Always duct the fan to the outside through a wall or roof cap. 1. Unpack fan from the carton and confirm that all pieces are present. In addition to the exhaust fan you should have: Ducting 1 - Grill...
  • Page 3 3. Install the included 26 watt fluorescent lamp into the lamp holder by lining up the NOTE: If the fan motor plug is Wire Screw connected to the fan housing pins on the lamp base to the socket of the lamp holder and pressing towards the Compartment receptacle, unplug so the lamp holder until the lamp snaps into place and is firmly seated in the lamp holder. Cover blower assembly can be Install a 4 watt maximum type C7 (candelabra base) night light (not included) into completely removed. the side lamp holder (Figure 10). Night Light Figure 7 Socket 2. Run wiring from an approved wall switch carrying the appropriate rating. One neutral (White), one ground (green or bare copper), and three hot (Black, Purple, Yellow leads connected to the switch, one for each function). Secure the electrical wires to the housing with an approved electrical connector. Make sure you leave enough wiring in the box to make the connection to the fan’s receptacle. 3. From where you have chosen to access the fan’s junction box, connect the White wire from the house to the two White wires from the fan. Connect one Hot (Black) Lamp wire from the wall switch to the Black wire from the fan (this is the fan control). Lamp Holder Connect second Hot (Purple) wire from the wall switch to the Purple wire from the fan (this is the night light control). Connect the third Hot (Yellow) wire from the wall Figure 10 switch to the Yellow wire from the fan (this is the main light control). Connect the ground wire (green or bare copper) from the house to the Green wire from the fan 4. Install the grill by squeezing the two ends of the springs together and installing them (Figure 8). Use approved methods for all connections.
  • Page 4: Troubleshooting Guide

    DATE OF ORIGINAL PURCHASE OR UNTIL THE ORIGINAL PURCHASER OF THE PRODUCT SELLS OR TRANSFERS THE PRODUCT, WHICHEVER FIRST OCCURS AND IN NO EVENT SHALL AIR KING’S LIABILITY UNDER ANY EXPRESS OR IMPLIED WARRANTY INCLUDE (I) INCIDENTAL OR CONSEQUENTIAL DAMAGES FROM ANY CAUSE WHATSOEVER, OR (II) REPLACMENT OR REPAIR OF ANY HOUSE FUSES, CIRCUIT BREAKERS OR RECEPTACLES.
  • Page 5: Replacement Parts Diagram

    REPLACEMENT PARTS DIAGRAM # Qty. Description Replacement Part # # Qty. Description Replacement Part # 1 1 Fan Housing 5S1202033 20 1 Reflector Support Bracket 5S1202036 2 4 Mounting Rails 5S1299002 21 1 Blower Wheel 5S2202003 3 1 External Wire Cover 5S1202007 22 2 Screw 5S2202002 4 1...
  • Page 6 NOTES 210572203 Rev. C 3-10 www.airkinglimited.com 6 of 12...
  • Page 7: Instructions Générales De Sécurité

    INSTRUCTIONS IMPORTANTES – MANUEL D’OPÉRATION Ventilateur combiner, comprend Modèles: AKF50LS, AKF80LS, lumière et ventilation AKF100LS LIRE ET CONSERVER CES INSTRUCTIONS LIRE SOIGNEUSEMENT AVANT DE TENTER D’ASSEMBLER, INSTALLER, OPÉRER OU DE RÉPARER LE PRODUIT DÉCRIT. PRO- TÉGEZ VOUS-MÊME ET LES AUTRES EN OBSERVANT TOUTE L’INFORMATION DE SÉCURITÉ. FAILLIR À SE CONFORMER AUX INSTRUCTIONS PEUT RÉSULTER EN BLESSURE PERSONNELLE GRAVE ET/OU EN DOMMAGE À...
  • Page 8: Instructions D'installation

    SECTION 4 INSTRUCTIONS D’INSTALLATION Conduits AVERTISSEMENT : VOUS ASSURER QUE L’ALIMENTATION EST AVERTISSEMENT : COUPÉE AU PANNEAU DE SERVICE AVANT DE COMMENCER L’INSTALLATION. TOUS LES CONDUITS DOIVENT ÊTRE CONFORMES AUX CODES DU BÂTIMENT LOCAUX ET NATIONAUX. SECTION 1 1. Raccorder le conduit au collet de conduit du ventilateur (Figure 4). Fixer en place Préparation du Ventilateur d’évacuation à l’aide de ruban ou de serre-joint. Toujours évacuer le ventilateur vers l’extérieur 1. Sortir le ventilateur de sa boite et confirmer que toutes les pièces sont présentes.
  • Page 9 3. Installer le ampoule fluorescent incluses de 26 watts dans le socle de la lampe en REMARQUE : si le raccord du moteur de Couvercle du ventilateur est raccordé au réceptacle alignant le tige sur la base de l’ampoule au socle du support de lampe en pressant Compartiment du châssis, le débrancher afin que vers le support de lampe jusqu’à ce que l’ampoule se mette en place et qu’il soit l’assemblage de la soufflante soit fermement appuyé dans le socle du support de lampe. Installer une ampoule de de Câblage complètement enlevé. type C7 d’un maximum de 4 watts (culot de type candélabre) de la lumière de nuit (non-comprise) dans le support de lampe latéral (Figure 10). Lumière de Nuit Figure 7 Socle 2. Courir le câblage à partir d’un commutateur mural approuvé et de capacité appropriée. Un fil de neutre (blanc), un fil de mise à la terre (vert ou cuivre nu), et trois fils vivants (les fils noir, violet et jaune raccordés à l’interrupteur, un pour chaque fonction). Fixer les câbles électriques au châssis à l’aide de connecteur électrique approuvé. Vous assurer que vous laissez suffisamment de câble dans la boîte pour permettre le raccordement au réceptacle du ventilateur. 3. Par là où vous avez choisi d’accéder à la boîte de jonction du ventilateur, raccorder Tige un fil Blanc de la maison aux deux fils Blancs du ventilateur. Raccorder un fil vivant (Noir) du commutateur mural au fil Noir du ventilateur (celui-ci est pour le contrôle Ampoule du ventilateur). Raccorder le second fil vivant (violet) du commutateur mural au Socle de Lampe fil Violet du ventilateur (celui-ci pour le contrôle de la lumière de nuit). Raccorder Figure 10 un troisième fil vivant (Jaune) du commutateur mural au fil Jaune du ventilateur (celui-ci est pour le contrôle de la lumière principale). Raccorder le fil de mise à la 4. Installer la grille en pressant ensemble les deux extrémités des ressorts et en les terre (vert ou cuivre nu) de la maison au fil Vert du ventilateur (Figure 8). Utiliser des...
  • Page 10: Guide De Dépannage

    AN DE LA DATE DE L’ACHAT ORIGINAL OU JUSQU’À CE QUE L’ACHETEUR ORIGINAL DU PRODUIT VEND OU TRANSFÈRE LE PRODUIT, CELUI QUI SE PRODUIT EN PREMIER ET DANS AUCUN CAS AIR KING N’ASSUME AUCUNE RESPONSABILITÉ EXPRESSE OU TACITE POUR (I) DES DOMMAGES ACCIDENTELS OU INDIRECTS DE N’IMPORTE QUELLE CAUSE, OU (II) LE REPLACEMENT OU LA RÉPARATION DE TOUS FUSIBLES, DISJONCTEURS OU RÉCEPTACLES DE MAISON.
  • Page 11 DIAGRAMME DES PIÈCES DE REMPLACEMENT # de pièce # de pièce # Qty. Description de remplacement # Qte. Description de remplacement 1 1 Cabinet du ventilateur 5S1202033 20 1 Griffe de Support du Réflecteur 5S1202036 2 4 Traverses de Montage 5S1299002 21 1 Roue de la Soufflante 5S2202003 3 1 Couvercle de Câble Externe 5S1202007 22 2...
  • Page 12 REMARQUE 210572203 Rev. C 3-10 www.airkinglimited.com 12 of 12...
