Summary of Contents for Antec Dark Fleet DF-35

  • Page 4 ECTION NTRODUCTION...
  • Page 5 ETTING TO KNOW YOUR CASE...
  • Page 6 PECIFICATIONS OLOR ″ ″ ″ IMENSIONS EIGHT OOLING ″ RIVE ″ XPANSION LOTS OTHERBOARD I/O P RONT ANEL...
  • Page 7 EFORE EGIN • • • • • • • •...
  • Page 8 OCATING OSITIONING OMPUTER The DF-35 comes with a top 2.5” Hot Swap drive bay. While it’s in a handy location, we do not recommend that users put any liquid-containing items (drinks, ice cream, coffee, perfume, etc.) on the drive bay. It was not designed for storage purposes.
  • Page 9 ECTION ARDWARE NSTALLATION...
  • Page 10 ETTING...
  • Page 11 A – Power supply mounts B – 5.25” drive bay area C – 3.5” drive bay area with Fleet-Swap SATA bays D – Front panel wiring E – I/O panel...
  • Page 12 OTHERBOARD NSTALLATION Make sure you have the correct I/O panel. This mismatched I/O panel can cause difficulties down the road. Installing the motherboard, step 2. Note that not all motherboards will match with all the provided holes; this is normal and won’t affect functionality.
  • Page 13 Lift your motherboard out to install the standoffs. Step 5: Screwing in the motherboard after standoffs are installed...
  • Page 14 Note: The DF-35 comes with a CPU cutout on the motherboard tray, which will allow you to change your CPU heatsink without removing the motherboard. ATX P TANDARD OWER UPPLY NSTALLATION PSU resting on the standard PSU mount.
  • Page 15 Use these screws to secure your power supply to the case. ABLE ANAGEMENT...
  • Page 16 3.5” D NTERNAL EVICE NSTALLATION ™ Opening the Fleet-Release™ access door by gently pressing the left side to release it, and then swing it open. Installing a 3.5” internal device...
  • Page 17 Make sure to install screws on the left side… …as well as the right side. 3.5” D XTERNAL EVICE NSTALLATION Remove this drive bay cover.
  • Page 18 Insert your drive as shown. ™ SING LEET Fleet-Swap™ default locations...
  • Page 19 A – Fleet-Swap™ SATA and power connectors B – Fleet-Swap™ bay screws Moving or removing a Fleet-Swap™ bay...
  • Page 20 One example of AHCI configuration – your motherboard may vary Loading a Fleet-Swap drive.
  • Page 21 Open the Fleet-Release Access Door to access the drive you want to unload. Removing a Fleet-Swap drive...
  • Page 22 2.5” H SING Using the top 2.5” hot-swap drive bay...
  • Page 23 5.25” D XTERNAL EVICE NSTALLATION The plastic drive bay faceplate should pop free. A screwdriver may be needed to remove the metal cover plate. 5.25” device installation...
  • Page 24 2. 5” D NTERNAL EVICE NSTALLATION The 2.5” mounting location Secure your 2.5” device from the bottom.
  • Page 25 ECTION RONT ORTS...
  • Page 26 USB 2.0 Signal Names Signal Names 9 10 AC’97 / HD A UDIO ORTS Signal Names Signal Names (HDA) (AC’97)
  • Page 27 LED C OWER WITCH ESET WITCH RIVE ONNECTORS Front Panel switch leads EWIRING OTHERBOARD EADER ONNECTIONS Front panel headers...
  • Page 28 ECTION OOLING YSTEM...
  • Page 29 NCLUDED FANS Standard fans on the DF-35: A –1 x 120 mm rear TwoCool™ LED fan B – 1 x 140 mm top TwoCool™ fan C – 2 x Fleet-Release access door modules w/front variable-speed 120 mm white LED fans Rear fan control panel...
  • Page 30 ™ F LED F RONT HITE Turn this knob to adjust the fan.
  • Page 31 ™ W LED F XHAUST HITE PTIONAL...
  • Page 32 ASHABLE ILTERS Removing the washable air filter. Note the filter tabs.
