Do you have a question about the SD-3950 and is the answer not in the manual?

Questions and answers

Greg
May 14, 2025

What are the color cable to be place in recorder

2 comments:
Mr. Anderson
May 21, 2025

The Toshiba SD-3950 uses the following color-coded cables for connection:

- Video output (B/PB and R/PR): 0.7 V (p-p), 75Ω, pin jacks x 2 – typically color-coded as blue and red.
- Audio output (Analog, L and R): 2.0 V (rms), 680Ω, pin jacks x 1 – typically color-coded as white (left) and red (right).
- Audio output (Coaxial digital): 0.5 V (p-p), 75Ω, pin jack x 1 – typically color-coded as orange.

These standard color codes help identify the correct connection for each signal type.

This answer is automatically generated

Laurie
July 17, 2025

@Greg Can you show a picture of the back of the dvd player with cables plugged in. I can’t get the picture on my tv

User image 687940fc8b8bf
Debbie Martin
May 20, 2025

How do I set up the TV so I can play a video on my Toshiba DVD Video Player SD 3950?

1 comments:
Mr. Anderson
May 24, 2025

To set up your Toshiba SD-3950 DVD Video Player to play a video:

1. Plug in the player and connect it to your TV using either composite or S-video cables.
2. Insert a DVD into the player.
3. The player features auto-play, so it should start playing the DVD automatically.
4. If needed, use the remote control to navigate menus or adjust settings.

No special setup is required beyond connecting the cables and inserting a disc.

This answer is automatically generated
