- Page 1 NS-16T01FS 16-Port 10/100Mbps Fast Ethernet Smart Switch User’s Guide...
-
Page 3: Ce Mark Warning
FCC Warning This equipment has been tested and found to comply with the regulations for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 4 UL Warning a) Elevated Operating Ambient Temperature- If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer's maximum rated ambient temperature (Tmra).
-
Page 5: Table Of Contents
A B L E O F O N T E N T S ABOUT THIS GUIDE... 1 ... 1 URPOSE ... 1 ERMS SAGE INTRODUCTION ... 3 THERNET ECHNOLOGY ... 4 WITCHING ECHNOLOGY VLAN (V IRTUAL OCAL ... 6 EATURES UNPACKING AND INSTALLATION ... - Page 6 CONFIGURATION... 15 (RS-232 DCE)... 15 ONSOLE ... 18 ONFIGURING THE WITCH ... 19 OGIN ... 20 ONFIGURING ETUP ETTING ONFIGURING YSTEM ETTING ... 26 ONFIGURING ETTING ... 27 TATISTICS TECHNICAL SPECIFICATIONS ... 29 ... 21 ... 25...
-
Page 7: About This Guide
B O U T H I S U I D E Congratulations on your purchase of your Alloy 16-Port 10/100Mbps Fast Ethernet Smart Switch. This device integrates 100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities in a highly flexible package. Purpose This guide discusses how to install your 16-Port 10/100Mbps Fast Ethernet Smart Switch. -
Page 9: Introduction
N T R O D U C T I O N This chapter describes the features of the 16-Port 10/100Mbps Fast Ethernet Smart Switch and some background information about Ethernet/Fast Ethernet and Switching technology. Fast Ethernet Technology The growing importance of LANs and the increasing complexity of desktop computing applications are fueling the need for high performance networks. -
Page 10: Switching Technology
Switching Technology Another approach to pushing beyond the limits of Ethernet technology is the development of switching technology. A switch bridges Ethernet packets at the MAC address level of the Ethernet protocol transmitting among connected Ethernet or Fast Ethernet LAN segments. Switching is a cost-effective way of increasing the total network capacity available to users on a local area network. -
Page 11: Vlan (Virtual Local Area Network)
VLAN (Virtual Local Area Network) A VLAN is a group of end-stations that are not constrained by their physical location and can communicate as if in a common broadcast domain, a LAN. The primary utility of using VLAN is to reduce latency and need for routers, using faster switching instead. -
Page 12: Features
Features 16×10/100Mbps Auto-negotiation Ethernet ports All ports support auto MDI/MDIX, so there is no need to use cross-over cables or an up-link port Full/half duplex transfer mode for each port Wire speed reception and transmission Store-and-Forward switching scheme with capability to support rate adaptation and ensure data integrity Broadcast storm protection Up to 4K unicast address entities per device, self-... -
Page 13: Unpacking And Installation
N P A C K I N G A N D This chapter provides unpacking and setup information for the Switch. Unpacking Open the shipping carton of the Switch and carefully unpack its contents. The carton should contain the following items: One 16-Port 10/100Mbps Fast Ethernet Smart Switch One AC power cord, suitable for your area’s electrical power connections... -
Page 14: Installation
Installation The site where you install the hub stack may greatly affect its performance. When installing, consider the following pointers: Install the Switch in a fairly cool and dry place. See Technical Specifications for the acceptable temperature and humidity operating ranges. Install the Switch in a site free from strong electromagnetic field generators (such as motors), vibration, dust, and direct exposure to sunlight. -
Page 15: Rack Mounting
Rack Mounting The switch can be mounted in an EIA standard-size, 19-inch rack, which can be placed in a wiring closet with other equipment. Attach the mounting brackets at the switch’s front panel (one each side), and secure them with the screws provided. Figure 1. -
Page 16: Connecting Network Cable
Connecting Network Cable The Switch supports 10Mbps Ethernet or 100Mbps Fast Ethernet and it runs both in half and full duplex modes. The Switch ports are Auto-MDI types. The Switch can automatically change all ports between MDI-II & MDI-X types alleviating any worry about using standard or crossover type cables. -
Page 17: Identifying External Components
D E N T I F Y I N G X T E R N A L This chapter describes the front panel, rear panel, and LED indicators of the Switch. Front Panel The figure below shows the front panels of the Switch. Figure 3. -
Page 18: Rear Panel
Rear Panel AC Power Connector Figure 4. Rear panel of the Switch AC Power Connector This is a three-pronged (IEC) connector that supports the power cord. Plug the female connector of the provided power cord into this connector, and the male into a power outlet. Supported input voltages range from 100~240V AC at 50~60Hz. -
Page 19: Understanding Led Indicators
N D E R S T A N D I N G The front panel LEDs provide instant status feedback, and help monitor and troubleshoot when needed. 16-Port 10/100Mbps Ethernet Smart Switch POWER Link/ACT SYSTEM Figure 5. LED indicators of the Switch Power and System LEDs POWER : Power Indicator : When the Power LED lights on, the Switch is receiving... -
Page 20: Ports 1~16 Status Leds
Ports 1~16 Status LEDs Link/ACT : When the Link/ACT LED lights on, the respective port is successfully connected to an Ethernet network. Blinking : When the Link/ACT LED is blinking, the port is transmitting or receiving data on the Ethernet network. : No link. -
Page 21: C Onsole P Ort (Rs-232 Dce)
ONFIGURATION This Switch is an unmanaged, but “smart” Switch because programmable administration parameters make it operate more effectively than regular unmanaged (dumb) switches. This chapter describes how to configure the Switch. Console Port (RS-232 DCE) The console configuration requires connecting a terminal, such as a Workstation or a PC running a terminal emulation program (such as HyperTerminal, which is automatically installed with Microsoft Windows) to the RS-232 DCE console port of the... - Page 22 Figure 6. Start Hyper Terminal function Step 2. Enter a name in the blank to set up a new connection, and then press OK. Figure 7. Connection Description...
- Page 23 Step 3. The Connect To screen will appear as below. Pull down the Connect using and choose the COM port that the Switch has been connected to, then press OK. Figure 8. Connect To Step 4. Make sure the Switch serial port parameters have been set as per the factory default settings (Figure 9).
-
Page 24: Configuring The Switch
Configuring the Switch The 16-Port 10/100Mbps Fast Ethernet Smart Switch has a menu-driven console interface for smart switch configuration. The Switch can be configured through the serial port. A network administrator can manage, control and monitor the switch from the console program. This section indicates how to configure the Switch to enable its smart functions including: Setup There are two items, Port Configuration and VLAN, shown in the... -
Page 25: Login
Login First execute the terminal emulation program on the remote workstation, and turn on the Switch. When logging into the Switch, the following screen (Figure 10) prompt appears: Password: Figure 10. Login Insert the password into the blank space and then press Enter to log in to the Main Menu. -
Page 26: Main Menu
Main Menu The main menu appears, as shown in Figure 11. Note the console keys in the lower part of the display. Move to highlight a desired option by using Up Arrow, Down Arrow and Tab keys, and then press the Enter key to confirm. There are four options: Setup, System, File, and Statistics, shown in the Main Menu screen. -
Page 27: Port Configuration
Configuring Setup Menu Note that there are two items, Port Configuration and VLAN, in Setup menu as shown in Figure 12. Figure 12. Setup Menu Port Configuration In the Port Configuration menu (Figure 13), each port’s (inc. port 17: Fibre port) Speed, Flow Control, and QoS can be controlled. Link Status is automatically determined by the Switch and can’t be shifted. - Page 28 Figure 13. Port Configuration (1) Speed There are five modes— Auto, 100M Full, 100M Half, 10M Full, and 10M Half—for speed selections. To change the speed setting, highlight Port and enter the port number to select the desired port, next highlight Speed, click Enter, and use Space Bar to switch between the five different options.
- Page 29 High and Low. The default setting for QoS on all ports is High. To change the QoS setting, highlight Port and enter the port number to select the desired port. Set QoS as required to determine which ports will always transfer their data first. (4) Link Status This value is automatically determined by the Switch and can’t be changed.
- Page 30 For example, there are five computers (PC1~PC5) connected to the Switch’s port 1~5. They had been divided into two VLAN groups: VLAN1 (PC1~PC4) and VLAN2 (PC2~PC5). There is no way to connect PC1 and PC5, as shown in Figure 15. If PC1 has to connect to PC5, it should with it in the same VLAN.
- Page 31 Configuring System Setting The System Configuration Menu screen (shown in Figure 17) indicates the following information: Factory Reset: Press to revert to factory settings if the configuration becomes corrupt. Change Password: Change the input password. Confirm Password: Confirm the new input password. Refresh Time: Set the refresh time of the device for Statistics.
- Page 32 Configuring File Setting The Switch can have its configuration files uploaded or downloaded by using the File screen shown in Figure 18. Upload Configuration: Select this for uploading the configuration file to the device. Download Configuration: Select this for backing up the current configuration to another device.
-
Page 33: S Tatistics
Statistics Statistics Menu In the Statistics menu screen, shown in Figure 19, the transmit (Tx) and receive (Rx) status summaries can be viewed. Figure 19. Statistics Statistics Detail... - Page 34 Highlight Port and enter port number to view the statistics details (see Figure 20). Figure 20. Statistics Detail...
- Page 35 E C H N I C A L P E C I F I C A T I O N S IEEE 802.3 10BASE-T Ethernet Standards IEEE 802.3u 100 BASE-TX, 100BASE-FX Fast Ethernet CSMA/CD Protocol Ethernet: 10Mbps (half duplex), 20Mbps (full duplex) Data Transfer Fast Ethernet: 100Mbps (half duplex), 200Mbps (full...
- Page 36 Physical and Environmental AC input: Power Consumption: Temperature: Humidity: Dimensions: Weight: Emissions: Safety: Performance Transmits Method: RAM Buffer: Filtering Address Table: Packet Filtering/Forwarding Rate: MAC Address Learning: 100~240V AC, 50/60 Hz internal universal power supply 12 watts. (max.) Operating: 0°~40°C, Storage: -10°~70°C Operating: 10%~90% RH, Storage: 5%~90% RH...
- Page 37 Alloy Computer Products Aust. Pty. Ltd. Postal Address: PO Box 15, Mulgrave, Vic, 3170 Unit 4, 585 Blackburn Road, Notting Hill, Victoria, 3168, Australia Phone: 03 9574 9891, Fax: 03 9561 7412, World Wide Web: www.alloy.com.au...
