American DJ Splitter User Instructions

American DJ
Splitter
C C A A U U T T I I O O N N ! ! R R e e a a d d i i n n s s t t r r u u c c t t i i o o n n s s b b e e f f o o r r e e i i n n s s t t a a l l l l i i n n g g o o r r p p l l u u g g g g i i n n g g u u n n i i t t i i n n . .
SPECIFICATIONS: MODEL - Splitter™
Weight:
Size:
Lamp:
Fuse:
Voltage:
Working Position:
Duty Cycle:
Cooling:
Optics:

Operating Instructions:

Unit is ready to be hung or set on flat surface. After plugging unit in, the outer mirror dish will react to bass
sound via the internal microphone. The internal dichoric color wheel will also rotate to sound. Adjust the sensi-
tivity knob on the bottom of the unit for sound sensitivity. Focus the front lens so the beam patterns are in focus
for the height the fixture in mounted. Be sure not to obstruct the cooling vents and keep in a well ventilated
area. For best effect, periodically clean the front focus lens and mirror with a glass cleaner.
Caution! Never open unit when in use. Always disconnect main power before serving or replacing lamp.
Remember to always replace with the same lamp and fuses, unless otherwise specified by technician.
Lamp Replacement: Open the front cover by removing the two thumb screw. Pull lamp out and remove it
from socket. Remove and replace lamp.
The American DJ Splitter
that came with your fixture to validate your warranty. For service contact American DJ.
Affordable Quality Lighting Products From American DJ® Los Angeles, CA. 90058
18lbs.
22.5"H x 6"W x 8.75"L
ZB- EHJ 24v/250w
4A GMA
120V
Any Safe position
10 min. on 10 min. off
Fan cooled
High quality glass lens
Reflective dichoric
mirror
comes with a 90 day limited warranty. We recommend filling out the warranty registration card
TM
User Instructions
®
™

HALOGEN LAMP WARNING!

This fixture is fitted with a halogen
lamp which is highly susceptible
to damage if improperly han-
dled. Never touch lamp with bare
fingers as the oil from your hands
will shorten lamp life. Also, never
move fixture until lamp has had
ample time to cool. Remember,
lamps are not covered under
warranty conditions.
