American DJ S-100A User Instructions

American DJ
S-100A
ST R OBE
C a u t i o n !
Always disconnect from main
power before replacing lamps or servicing unit.
Remember to always replace with same lamps
and fuses.
S-100A™
Model:

SPECIFICATIONS:

Lamp: ZB-45
Power: 110V/60Hz
Working Position: Any
Weight: 7 lbs.
Size: 9" x 9 " x 9"
®
American DJ®
User Instructions
™
Th a nk y ou f or p u rc ha si ng t hi s
Ame rican DJ® product. For your
convenience this strobe light has
been lamped and is ready to be used,
t h e re is no a sse m bl y re q u i re d .
Ple as e re ad
i n s t ructio ns b efo re i nst alli ng or
using your new unit.

Operating Instructions:

Unit is ready to be hung or set on the ground.
After plugging in unit, the light can be controlled by
the strobe flash adjustment pot on the rear of the
strobe. The S-100A™ is a 45W strobe, including
mounting bracket and control signal input and
output for linking up to four S-100A's. For use with
the S-10A™, S-4A™, or the S-2A™ remote
controls. To link strobes use a 1/4" to 1/4" mono
cable.
To replace lamp; Unplug unit. Unscrew front two
screws and remove front plastic. Take out lamp,
replace with a new lamp, then reassemble. Do not
take the metal housing apart, strobes retain HIGH
VOLTAGE inside. There are no serviceable parts
inside.
For service contact you local American DJ ®
Dealer.
LOS ANGELES, CA. 90058
t he f o ll owi ng
