Mechanical Disassembly
Evaporator Cover in Freezer
1. Remove all drawers from the freezer.
2. Remove screws (2) from the support rail.
2 screws
3. Pull down the holder of the support rail and
disconnect the wire connector to remove it.
4. Unlock the tabs around the evaporator cover
from the buttom.
③
①
①
②
②
5. Disconnect wire connector from the top-left
corner.
6. Remove 2 screws from the rear cover of the
freezer evaporator and unlock the tabs to
remove it.
