REFRIGERATOR
For the latest parts information, Please access to our service web site (http://itself.sec.samsung.co.kr)
REFRIGERATOR
Model Name : RB195/215B*
(Model Code)
PRODUCT FEATURE
Reversible Door
Auto Ice-Maker
Fridge Wire Box
