Norelco XA4003/42 User Manual

ENGLISH
IMPORTANT
SAFETY
INSTRUCTIONS
When using an electric appliance, basic safety
precautions should always be followed,
including the following:
Read all instructions before using this
appliance.
DANGER
To reduce the risk of electric shock:
1. Do not reach for a corded Trimmer that has
fallen into water. Unplug immediately.
2. Use Trimmer only in a dry condition. Do not
use while bathing or in a shower.
3. Do not place or store Trimmer where it can
fall or be pulled into a tub or sink. Do not
place in or drop into water or other liquid.
4. Always unplug this Trimmer from the electri-
cal outlet immediately after (re)charging.
5. Unplug and remove power supply cord from
Trimmer before cleaning.
6. When discarding Trimmer, unplug trimmer
before removing rechargeable battery. See
Battery Removal instructions.
WARNING
To reduce the risk of burns, fire, electric
shock or injury to persons:
1. Close supervision is necessary when
this appliance is used by, on, or near children
or invalids.
2. Use this Trimmer for its intended household
use as described in this manual. Do not use
attachments not recommended by Philips
Electronics North America Corporation.
3. Never operate this Trimmer if it has a
damaged cord or plug, if it is not working
properly, if it has been dropped, damaged, or
dropped into water. For assistance call
1-800-243-3050.
4. Keep the Trimmer, cord and any attachments
away from heated surfaces.
5. Never drop or insert any object into any
opening.
6. Do not operate, charge, clean or plug in
Trimmer outdoors or where aerosol (spray)
products are being used or where oxygen is
being administered.
7. Always check cutters, cutting unit and comb
before using the Trimmer. Do not use the
Trimmer if cutters, cutting unit and comb are
damaged, as injury may occur.
8. Always attach plug to Trimmer first, then to
outlet. To disconnect, turn on/off switch to
"OFF" position, then remove plug from
outlet.
9. To prevent possible damage to the cord, do
not wrap cord around the Trimmer.
10. Never put Trimmer in direct sunlight or store
at a temperature above 140°F.
11. Never immerse the Trimmer in water or
rinse under the tap.
12. This Trimmer is for use on human hair only.
Do not use this Trimmer for any other
purpose.
13. Always store your Trimmer, attachments and
power plug in a moisture-free area. Make
sure the cord is disconnected from the
Trimmer.
14. Only use the power plug and other
accessories supplied with the appliance.
SAVE THESE
INSTRUCTIONS
Introduction
Congratulations on your purchase and welcome
to Philips Norelco!
To fully benefit from the support that Philips
Norelco offers, register your product at www.
norelco.com/register
13_XA4003.indd 1
IMPORTANT
INFORMATION
CAUTION
w The power plug contains a transformer. Do not
cut off the power plug to replace it with another
plug, as this will cause a hazardous condition.
w If cutters become damaged or worn, do not
continue using trimmer. Replace cutters
immediately.
w This Philips Norelco trimmer contains a Nickel
Metal Hydride battery which must be disposed of
properly.
w Battery should only be removed when trimmer
is to be discarded. Do not attempt to replace
battery. Insulate battery ends by covering with
tape and/or place battery in a small plastic bag.
Discard trimmer.
w Do not attempt to plug electrical cord into outlet
or recharge trimmer after battery has been
removed.
w The power plug transforms 100-240V AC to less
than 24V DC.
GENERAL
w Only use the power cord provided to charge
trimmer.
w An adaptor plug may be necessary for charging in
some foreign countries. Use an attachment plug
adaptor of the proper configuration for the power
outlet.
w Charging, recharging, storing or using at
temperatures below 40˚F or higher than 95˚F
adversely affects lifetime of battery.
w Do not leave the trimmer charging for more than
24 hours.
w Regular cleaning guarantees better trimming
results.
w Always switch trimmer OFF before cleaning.
w Do not use abrasive cleaning agents, scourers
or aggressive liquids such as alcohol, gasoline or
acetone to clean trimmer and attachments.
w This trimmer has no other user-serviceable parts.
For assistance call 1-800-243-3050.
Features
A
B
I
H
C G
D
F
E
A Trimming Comb
B Cutting Unit
C Precision Zoom Lock Adjustment Ring
D On/Off Switch
E Socket for Appliance Plug
F Cleaning Brush
G Appliance Plug
H Adapter
I Charging Light
Charging/Recharging
1 2
(Off)
w Charging requires 10 hours. The charging light
on the adaptor will light up green when trimmer
is (re)charging.
w After fully charging, the charging light will remain
lit.
w A fully charged trimmer has a cordless trimming
time of up to 35 minutes.
w Battery performance is best if you recharge only
when the battery is (almost) completely empty.
Trimming:
With beard comb
1
1 2 3
(On)
4 3 2 1
• • •
4 5 6
w Use this trimmer for its intended household
use as described in this manual.
w Always comb beard and/or moustache with a
fine comb before you start trimming.
w If you are trimming for the first time, be
careful. Do not move trimmer too fast. Make
smooth and gentle movements.
w To trim the most effective way, move trimmer
against the direction of hair growth. Make
sure the surface of the comb always stays in
contact with skin.
w If cut hairs accumulate in the comb, turn
trimmer off, remove comb and blow and/or
shake hair out of the comb.
TIP: Since all hairs do not grow in the same
direction, try different trimming positions (i.e.
upwards, downwards or across). Practice is best for
optimum results.
NOTE: Use setting 1 to obtain a 'stubble' look.
Setting Hair Length after Trimming
•
1/32 in/0.5mm
1 Stubble Length 3/64 in/1mm
•
1/16 in/1.5mm
2 5/64 in/2mm
•
3/32 in/2.5mm
3
1/8 in/3mm
•
9/64 in/3.5mm
4 5/32 in/4mm
•
11/64 in/4.5mm
3/16 in/5mm
5
•
7/32 in/5.5mm
6
1/4 in/6mm
•
17/64 in/6.5mm
7 9/32 in/7mm
•
19/64 in/7.5mm
5/16 in/8mm
8
• 21/64 in/8.5mm
3/8 in/9mm
9
•
25/64 in/9.5mm
10
13/32 in/10mm
TIP: If trimming for the first time, start by using the
comb at the maximum trimming length setting (#10)
to prevent accidentally trimming hairs too short. As
you become familiar with the settings, adjust Zoom
Lock to desired trimming length.
Trimming:
Without beard comb
1 2 3
(On)
TIP: Use trimmer without the comb to define
hairlines, trim nape of neck or remove single,
unwanted hairs. Be careful, trimmer without the
comb will remove every hair it touches.
Cleaning:
After each use
1 2 3
(Off)
Unplug
4
NOTE: After removing cutting unit from
trimmer, rinse under warm tap water or use
the brush supplied. If rinsing under tap, allow
cutting unit to air dry thoroughly.
Replacing cutting unit
1 2 3
(Off)
Unplug
4
5 6
Storage
Be sure trimmer is turned off. Remove cord
◗
from outlet and trimmer before storing in a
safe, dry location where it will not be crushed,
banged or subject to damage.
Battery Removal/Disposal
2 3
1
(Off)
Unplug
4 5 6
7
w Allow battery to run until battery is empty/
deleted before removing battery.
w D ispose of battery properly. Do not
incinerate. Battery may explode if
Overheated. Do not wrap in metal or
aluminum foil. Wrap in newspaper before
discarding.
w I t is suggested that you contact your
local town or city officials or call
1-800-8-BATTERY or www.rbrc.com to
determine proper battery drop-off locations.
Assistance
For assistance visit our
website www.philips.com/
support or call toll free:
1-800-243-3050.
www.philips.com/support

Troubleshooting

This chapter summarizes the most common
problems you could encounter with the appliance.
If you are unable to solve the problem with the
information below, visit www.philips.com/support
or call 1-800-243-3050 for assistance.
Problem Possible cause Solution
The trimmer Hairs may be Clean the trimmer
does not work stuck in the and comb (see
as well as it comb. 'Cleaning').
used to.
The cutting Replace the cutting
unit is dam- unit. Call 1-800-243-
aged or worn. 3050 for assistance.
The battery Recharge the trim-
is low. mer (see 'Charging').
The trimmer The battery is Recharge the trim-
does not go on empty. mer (see 'Charging').
when I press
the on/off
button.
The trimmer This is normal. No action required.
becomes warm
during charging
The battery Need to Let the battery run
charge doesn't optimize life of down completely
last as long as it battery at least twice a year
used to. and fully charge it
afterward.
Remove the adapter
from the outlet
when battery is fully
charged.
If trimmer hasn't
been used for a
long time, it must be
recharged for a full
10 hours.
XA4003
Rechargeable Cordless
Stubble Trimmer
Always here to help you
Question?
Question?
Contact Contact
Register your product and get support at Philips
Philips
Norelco Norelco
www.norelco.com/register
4222 002 8326 2
Our story
Get the stubble length that works best for
you - right now. This easy to use trimmer has
20 locking length settings so just choose your
favorite for a perfectly even style that will bring
you real results.
45-Day Money-Back
Guarantee
If you are not fully satisfied with your Philips Norelco
trimmer send the product back and we'll refund you the
full purchase price.
The Trimmer must be shipped prepaid by insured
mail, insurance prepaid, have the original sales
receipt, indicating purchase price and date of
purchase, and the money-back guarantee return
authorization form enclosed. We cannot be
responsible for lost mail.
The Trimmer must be postmarked no later
than 45 days after the date of purchase. Philips
Norelco reserves the right to verify the purchase
price of the product and limit refunds not to
exceed suggested retail price.
To obtain money-back guarantee return
authorization form, call 1-800-243-3050 for
assistance.
Delivery of refund check will occur 6–8 weeks AFTER
receipt of returned product.
Full Two-Year Warranty
Philips Electronics North America Corporation warrants
each new Philips product, Model XA4003 (except cutters
and comb) against defects in materials or workmanship for
a period of two years from the date of purchase, and agrees
to repair or replace any defective product without charge.
IMPORTANT: This warranty does not cover damage
resulting from accident, misuse or abuse, lack of reasonable
care, the affixing of any attachment not provided with the
product or loss of parts or subjecting the product to any
but the specified voltage.* Use of unauthorized replacement
parts will void this warranty.
PHILIPS ELECTRONICS NORTH AMERICA
CORPORATION WILL NOT PAY FOR
WARRANTY SERVICE PERFORMED BY A NON-
AUTHORIZED REPAIR SERVICE AND WILL NOT
REIMBURSE THE CONSUMER FOR DAMAGE
RESULTING FROM WARRANTY SERVICE
PERFORMED BY A NON-AUTHORIZED REPAIR
SERVICE.
NO RESPONSIBILITY IS ASSUMED FOR ANY
SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES.
In order to obtain warranty service, simply go to www.
philips.com or call 1-800-243-3050 for assistance. It is
suggested that for your protection you return shipments
of product by insured mail, insurance prepaid. Damage
occurring during shipment is not covered by this warranty.
NOTE: No other warranty, written or oral, is authorized
by Philips Electronics North America Corporation. This
warranty gives you specific legal rights, and you may also
have other rights which vary from state to state. Some
states do not allow the exclusion or limitation of incidental
or consequential damages, so the above exclusion and
limitations may not apply to you.
*Read enclosed instructions carefully.
Manufactured for:
Philips Consumer Lifestyle
A Division of Philips Electronics North America Corporation
P.O. Box 10313, Stamford, CT 06904
This symbol on the product's nameplate means it is
listed by Underwriters' Laboratories, Inc.
AXE is a trademark of Unilever PLC.
Norelco is a Registered Trademark of Philips Electronics
North America Corporation.
PHILIPS is a Registered Trademark of Koninklijke Philips Electronics N.V.
© 2013 Philips Electronics North America Corporation. All Rights Reserved.
1/29/13 9:41 AM
