Advanced Elements STRAITEDGE AE1006 Owner's Manual page 6

3. Locate chambers 3 and 4 "floor." Make sure valve body is screwed in tightly.
Remove small cap (fig. 3) and insert Floor Valve Adaptor (fig. 4). Inflate chambers
until firm(1.0 PSI). Do not over inflate (FAQ).
CHECK
VALVE
BODY
INSERT "BOSTON
PUMP ADAPTOR"
fig. 4
4. Locate Chambers 5 and 6. Inflate Chambers 5 and 6 until firm (1.0 PSI).
5. Make sure all valves are closed tightly and properly. Check to be sure the cap tether
is not interfering with the valve seating on all chambers. Also be sure that the floor
fabric is not interfering with the seal on chambers 3 and 4.
TETHER RING
SMALL CAP
PUMP ADAPTORS
fig. 3
(FLOOR)
(PUMP HOSE)
CHECK VALVE CAP
ADVANCED ELEMENTS, INC.
(BOSTON)
SMALL CAP
