User Guide
RAID Rack
(RR2035ASDES)
www.addonics.com
v8.1.11
Technical Support
If you need any assistance to get your unit functioning properly, please have your
product information ready and contact Addonics Technical Support at:
Hours: 8:30 am - 6:00 pm PST
Phone: 408-453-6212
Email: http://www.addonics.com/support/query/
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Addonics Technologies RR2035ASDES
Summary of Contents for Addonics Technologies RR2035ASDES
- Page 1 T E C H N O L O G I E S User Guide RAID Rack (RR2035ASDES) www.addonics.com v8.1.11 Technical Support If you need any assistance to get your unit functioning properly, please have your product information ready and contact Addonics Technical Support at: Hours: 8:30 am - 6:00 pm PST Phone: 408-453-6212 Email: http://www.addonics.com/support/query/...
- Page 2 Front Power Switch POWER System Reset RESET Buzzer Reset Buzzer Back Punch out for USIB connectors Fans POWER TEMP LED Display Punch out for USIB connectors Power Supply Punch out for eSATA Punch out for port multipliers/bridges Power Switch: This is the switch to power on devices connected to the power supply.
- Page 3 Installing drives into the RAID Rack 1. Be sure the lock on each drive door is in an unlock position. If not, use the key that comes with the Disk Array to unlock the drive door. Pull on the door lever to swing open the drive door all the way.
-
Page 4: How To Remove The Top Cover
Top Cover Screws How to Remove the Top Cover: Locate the 2 screws at the back of the storage rack Turn screws counterclockwise to loosen. Lift the top cover and pull towards the rear end of the rack. To Mount Back the Top Cover: Align the top cover with the edges of the rack. -
Page 5: Dip Switch
HPM-XA Port Multiplier RAID Setting Button Dip Switch SATA Host Port (Port 5) SATA Port 2 SATA Port 1 SATA Port 0 Floppy Power Connector SATA Port 3 SATA Port 4 Drive activity LED Jumper Block (J1) Error LED Jumper Block (J3) Dip Switch Settings Raid Mode Individual Drive... -
Page 6: Error Led
Default factory DIP Switch setting: SW1 – RAID Setting DIP Switch BZS – Error buzzer function EZ – Automatic rebuilding to spare drive (one of the drives on the raid is set as a spare). If EZ is ENABLED anda drive failure occurs, the spare will automatically act as a drive replacement and rebuilding will automatically start. -
Page 7: Cable Connections
Cable Connections Attach the SATA hard drives (up to 5) to the SATA ports on the Hardware Port Multiplier (HPM) using SATA cables. It is recommended to connect drives to the SATA ports 1 to 5 successively. To provide power to the HPM, connect a 4-pin floppy power cable from the system power supply to the floppy power connector on the HPM. -
Page 8: Clone Mode
On the DIP switch, change (M0 to M2) setting to the desired RAID mode using the diagram below. All settings on the diagram shows • Error buzzer function is ENABLED • EZ function is DISABLED. RAID 0 Mode Clone Mode BZS EZ M2 M1 M0 BZS EZ M2 M1 M0 RAID 1&... - Page 9 RAID Setting Notes: When 2 drives are RAID 1& RAID 10 Mode connected to the HPM-XA, and DIP switch is set to this setting, the 2 drives will be configured as a 2-drive RAID1 array. BZS EZ M2 M1 M0 When 4 drives are connected to the HPM-XA, the 4 drives will be configured as a 4-drive RAID10 array.
- Page 10 Notes on Spare Drives using the Easy RAID Setting (EZ) When EZ function is ENABLED, the auto-rebuilding to spare drive is automatic. The degraded RAID group will start rebuilding automatically by using the existing spare drive. * Spare drive can be either plugged after RAID building or a new drive can be plug as the spare drive when RAID rebuild is required.
-
Page 11: Power Supply
RAID Rack with Port Multiplier Compatibility Note: The Port Multiplier will only work with a Port Multiplier aware host. Identify your host controller and check with its hardware manufacturer if you are unsure. Addonics offers several Port Multiplier capable host adapters. When the port multiplier (PM) is connected to a host controller with SiI3124 or SiI3132 chip, in the RAID BIOS of the host controller you will only see one drive and that is the drive connected to SATA port 1 on the Port Multiplier. - Page 12 CONTACT US www.addonics.com Phone: 408-573-8580 Fax: 408-573-8588 Email: http://www.addonics.com/sales/query/...
